Page 1
IR Transmission Series User Manual Model : IEC-3501E-05 Single IR Emitter (Non-Blinking) Smart Cabling & Transmission Corp. V1.0...
Page 2
User Manual IEC-3501E-05 Introduction IEC-3501E-05 is a single IR emitter.. Features Cable length 300cm... Diagram Installation View Standard installation IR emitter (flat side) attached directly to IR sensor window More reliable activated Looks nice IEC-3501E-05 or IEC-3502E-05...
Page 3
User Manual IEC-3501E-05 Attach IR emitter at inside of shelf 1. Attach IR emitter on above or below of the IR window 2. Less reliable activated Cabinet With door Installation 1. IR emitter is attached to rack door,round shape side facing the IR window 2.
