NEC MultiSync
TECHNICAL SPECIFICATIONS
Panel Technology
Active Screen Area (W x H) [mm]
Screen Size [inch/cm]
Viewing Angle (typ.)
Screen Aspect Ratio
Pixel Pitch [mm]
Contrast Ratio (typ.)
Brightness (typ.) [cd/m
]
2
Response Time (typ.) [ms]
Colours [million]
Horizontal Frequency [kHz]
Vertical Frequency [Hz]
Optimum Resolution
Native Resolution
Other Resolutions
Video Input
Video Output
Audio Input
Audio Output
Option Slot
Plug & Play
Safety and Ergonomics
Power Consumption (typ.) [W]
Power Management
Power Requirements
Operating Temperature [°C]
Operating Humidity [%]
VESA Mounting Interface [mm]
Dimensions (W x H x D) [mm]
Bezel Width [mm]
Specials
Weight [kg]
Supported TV Standards
Video Modes
Audio Functions
Remote Control
Colour Versions
Stand
Shipping Content
Warranty
*The ambient temperature influences the max. brightness. See „brightness" specification.
All hardware and software names are brand names and/or registered trademarks of the respective manufacturers. All rights reserved. All specifications are subject to change without notice. February 2009
www.nec-display-solutions.com
NEC Display Solutions Europe GmbH
X461UN
®
S-PVA TFT
1018.4 x 572.5
46/117.0
178° horizontal / 178° vertical (typ. at contrast ratio 10:1)
16:9
0.746 x 0.746
3000:1
500 at 5°C - 40°C (factory setting), 650 at 5°C - 20°C, 700 at 5°C - 8°C)
8 (t
+ t
; grey-to-grey); 16 (6 white/black; 10 black/white)
r
f
16.77
31.5 - 91.1 (analog and digital)
50.0 - 85.0
1360 x 768 at 60 Hz
1366 x 768 at 60 Hz
1920 x 1080; 1366 x 768; 1440 x 1050; 1680 x 1050; 1600 x 1200; 1280 x 1024;
1280 x 768; 1024 x 768; 832 x 624; 800 x 600; 720 x 400; 640 x 480
Analog: 5 x BNC, Component, Composite (via BNC and Cinch); 1 x S-Video; 1 x Dsub 15;
Digital: 1 x DVI-D (with HDCP); HDMI 1.3
Analog: 5 x BNC, Composite (via BNC); HDMI 1.3
2 x Cinch, 1 x 3.5 mm Head-jack
1 x Cinch
Built-in PC, DVI daisy chain board, HD-SDI board, CAT 5 receiver
VESA DDC2Bi
UL/C-UL or CSA; FCC Class B; TÜV GS; VCCI; CE; C-tick; PSB; CCC
200 (at 500 cd/m²); 330 (max.)
VESA DPMS
100 - 120/220 - 240 V; 3.6/1.45 A; internal power supply
+5 to +40*
20 to 80
300 x 300 (FDMI); 4 holes
With stand: 1025.7 x 623.6 x 351; Without stand: 1025.7 x 579.8 x 128.1
4.6 top/left; 2.7 bottom/right
10 bit LUT for calibration, 10 x 10 Tile Matrix with up 100 IDs through RS232, copy display
settings through RS232, user controllable back up fans with 2 speeds; TCP / IP control,
external ambient light + IR sensor
30.8 (with stand); 29.0 (without stand)
NTSC; PAL; SECAM
480i; 480p; 576i; 576p; 2 x 720p (50 and 60 Hz); 2 x 1080i (50 and 60 Hz);
2 x 1080p (50 and 60 Hz)
Amplifier: 2x 15 Watt, no optional speakers
RS-232C (9 pin D-Sub) Input + Output; Dsub 15 and DVI-D (DDC/CI); Remote Control IR
Black Front Bezel/Black Back Cabinet
Optional**
Display, Power cable, remote control, external senor (IR + ambient light), 3,5 mm jack cable,
calibration software, sensor, CD manual
3 years warranty including backlight
