Controls

BNC/D-SUB: Allows you to change between the BNC and D-SUB signal inputs.
OSM™ (On-Screen Manager) control buttons on the front of the
monitor function as follows:
To access OSM menu, press any of the control buttons (
PROCEED or EXIT button.
To rotate OSM between Landscape and Portrait modes, press the RESET button.
NOTE: OSM menu must be closed in order to rotate.
EXIT
CONTROL /
CONTROL /
PROCEED
RESET
NOTE: When RESET is pressed in the main and sub-menu, a warning window will
appear allowing you to cancel the RESET function by pressing the EXIT button.
Brightness/Contrast Controls
BRIGHTNESS
Adjusts the overall image and background screen brightness.
CONTRAST
Adjusts the image brightness in relation to the background.
AUTO ADJUST CONTRAST
AUTO
Adjusts the image displayed for non-standard video inputs.
OSM LOCK OUT
The OSM LOCK OUT control completely locks out access to all OSM control
functions. When attempting to activate OSM controls while in the LOCK OUT
mode, a screen will appear indicating that OSM controls are locked out.
• To enter the LOCK OUT mode, simultaneously press the PROCEED and
button. The LOCK OUT window will appear.
• To activate the LOCK OUT function, simultaneously press and hold down
the PROCEED and
seconds and the LOCK OUT function will be activated.
• To deactivate the LOCK OUT mode, simultaneously press the PROCEED
and button.
LCD2110usersmanual
Main Menu
Exits the OSM controls.
Moves the highlighted
area up/down to select
one of the controls.
Moves the highlighted area
left/right to select control
menus.
Has no function
Resets the highlighted control
menu to the factory setting.
button. The OSM window will disappear within
7
9
, , , ) or the
Sub-Menu
Exits to the OSM main menu.
Moves the highlighted
area up/down to select
one of the controls.
Moves the bar left/
right to increase or
decrease the adjustment.
Activates Auto Adjust
and ALL RESET functions.
Resets the highlighted control
to the factory setting.
