Professional-level LCD monitors. When combined with the SpectraView
top color performance.
The 21" NEC MultiSync LCD2180WG LED, the
world's first LED-backlit LCD desktop display,
delivers new levels of image detail and color
scale to professional-level users in the areas of
computer graphics, digital animation, medical
imaging, pre-press production and film, video and
photo editing. Chosen from only the top 5% of
the manufacturer's production, the LEDs used
for this display meet stringent purity and light
output vs. power requirements.
Using LEDs as the backlight source in lieu of
normal fluorescent tubes, the LCD2180WG LED
reveals an amazingly broad color gamut without
loss of luminance. This state-of-the-art technol-
ogy is able to produce more detail and greater
nuances on digital images than any other LCD or
CRT on the market today.
MultiSync LCD2180WG LED features include:
Wide color gamut achieves more than 100% of NTSC
and Adobe RGB
The 19" NEC MultiSync LCD1990SXi, 20"
LCD2090UXi and 21" LCD2190UXi, have not only
revolutionized the way flat-panel monitors are en-
gineered and designed, but how they can be used.
With their multitude of leading-edge capabilities,
combined with groundbreaking minimalist design,
these monitors could easily be considered the
most intelligent visual display solutions to date.
Not only are these monitors smart investments
for you and your company, their advanced func-
tionality and productivity-enhancing technolo-
gies illustrate their unique brilliance.
Features and benefits of the LCD1990SXi,
LCD2090UXi and LCD2190UXi include:
ColorComp reduces screen uniformity errors and
compensates for differences in color/grayscale and
luminance using new signal processing circuitry
Internal 12-bit lookup tables (LUTs) allows the display
of 16.7 million colors out of a palette of 69 billion, thus
providing for more points of shading between white
and black and overall improved representation of
gamma curves
Ambix 3TM technology provides the widest range of
computer video compatibility between analog and
Color Calibration Solution, select 19" - 21" NEC LCDs deliver the utmost in desk-
II
Variable whitepoint system backlight results in a
broader range between color steps with no loss of
luminance when the whitepoint is adjusted (no loss of
luminance between 5000-9300K)
Built-in color feedback system stabilizes target color
in one minute after power is turned on vs. 30 minutes
in standard desktop LCDs. The system also maintains
the stability of color over time
ColorComp TM compensates for the differences with the
screen's white uniformity and improves the color and
luminance uniformity of the display
10-bit internal look-up tables (LUTs) allow the monitor
to display from a color palette of more than 1 billion
colors as well as precise adjustments to be made to
the display's tone response curve without reducing the
number of displayable colors
Built-in feedback maintains color stability and better
color tracking compared to CCFL
True 10-bit digital video input designed for compatibil-
ity with future 10-bit video cards and operating systems
digital systems, and enables you to switch between
three inputs
Real-time clock allows for 24/7 power management
scheduling and monitor sleep/wake management,
improving energy savings and extending display life
OSM lockout gives users the ability to lock out all
functions, including power, thereby limiting non-users
from adjusting preset adjustments
XtraView+ technology provides for the
widest viewing angles available (up to
178°) with minimal off-angle color shift
Advanced No Touch Auto Adjust TM pro-
vides optimal image settings upon initial
power-on and closed signal changes
(includes a user-selectable mode
in the Advanced OSM)
TileMatrix TM and TileComp TM allow you
to build virtually seamless video walls
of various configurations (horizontal or
vertical) through the Advanced OSM
Rapid Response technology with Rapid
TM
Motion TM and overdrive delivers virtually
uninterrupted, undistorted viewing of
high-speed video
XtraView+ technology allows for 176° viewing angle
TM
from all directions
Environmentally friendly and RoHS compliant due to
omission of CCFL lighting source
Passive cooling system results in no fan noise or mov-
ing mechanical parts
Dual DVI connectivity allows for multi-computer
configurations through a single monitor, significantly
improving productivity
Redesigned bezel controls increase simplicity and ease
of use, displaying on-screen functions alongside the
appropriate buttons
Height-adjustable stand boasts a range of up to
150mm to maximize your viewing comfort
