NEC MultiSync LCD1980FXi Brochure page 4

MultiSync LCD1980FXi
Model
Display
19"/48 cm
Viewable Image Size
0.294mm
Pixel Pitch
86 @ native resolution
Pixels Per Inch
270 cd/m 2
Brightness (typical)*
600:1
Contrast Ratio (typical)*
178° Vert., 178° Hor.(89U/89D/89L/89R)(CR>10)
Viewing Angle (typical)
Rapid Response (18ms)
Response Time (typical)
More than 16 million
Display Colors
Synchronization Range
31.5-81.1 kHz
Horizontal
50-85 Hz
Vertical
Input Signal
Analog 0.7 Vp-p/75 Ohms
Video
Separate Sync: TTL Level (positive/negative)
Sync
Composite Sync: TTL Level (positive/negative)
Composite Sync on Green (0.3 Vp-p negative
0.7 Vp-p positive)
Ambix+ technology
Input
(DVI-I, DVI-D, VGA 15-pin D-sub)
ANALOG/DIGITAL
Resolutions Supported
720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-85 Hz
1152 x 864 @ 70-85 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60-75 Hz
1280 x 1024 @ 60 Hz
Native Resolution
Ultra-thin-frame (bezel), GammaComp, TileMatrix,
Additional Features
TileComp,XtraView+ wide-angle viewing technology,
AmbiBright, Ambix+ technology, Advanced No
Touch Auto Adjust, AutoBright, CableComp, power-
off timer, black level adjustment, digital smoothing,
digital controls, OmniColor 6-axis color control
sRGB, third-party touchscreen and protective
glass integration, Plug and Play (VESA DDC2B &
2Bi), VESA DPMS power management, optional
MultiSync SoundBar80, automatic DVI selection,
ISO 13406-2 Class II, vacation switch, Rapid Motion
Pivot-Enabled Yes
Height-Adjustable Stand
Yes
Touch-Capable Designed for integration
Voltage Rating Universal 100 (110-240V) 50-60 Hz internal
Power Consumption (typical)
On
48W
Power Savings Mode <2W
Dimensions (W x H x D)
Net (with stand)
401.3 x 366 x 200mm/15.8 x 14.4 x 7.9 in
Net (without stand) 401.3 x 330.2 x 78.7mm/15.8 x 13 x 3.1 in
Weight
Net (with stand) 21.4 lbs/9.7 kg
Net (without stand) 13.9 lbs/6.3 kg
VESA Hole Configuration
100 x 100mm
Specifications
Environmental Conditions
Operating Temperature
5-35°C /41-95°F
Operating Humidity 30-80%
Operating Altitude 3048 m/10,000 ft
Storage Temperature
-10-60°C /14-140°F
Storage Humidity 10-85%
Storage Altitude 12,192 m/40,000 ft.
Limited Warranty
3 years parts and labor, including backlight
Technical Support 24 hours/7 days
*measured according to VESA FPDM
MultiSync, OSM and XtraView are registered trademarks, and AmbiBright, Ambix+, Advanced
No Touch Auto Adjust, Advanced OSM, AutoBright, CableComp, GammaComp, NaViSet, Rapid
Motion, Rapid Response, TileComp, TileMatrix and XtraView+ are trademarks of NEC Display
Solutions. All other brand or product names are trademarks or registered trademarks of
their respective holders. Product specifications subject to change.
©2005 NEC Display Solutions of America, Inc. All rights reserved.
Item No. 80series-1 8/05 ver.5.
MultiSync LCD1980SXi
19"/48 cm
0.294mm
86 @ native resolution
270 cd/m 2
500:1
176° Vert., 176° Hor.(88U/88D/88L/88R)(CR>10)
Rapid Response (25ms)
More than 16 million
31.5-81.1 kHz
50-85 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level (positive/negative)
Composite Sync: TTL Level (positive/negative)
Composite Sync on Green (0.3 Vp-p negative
0.7 Vp-p positive)
Ambix+ technology
(DVI-I, DVI-D, VGA 15-pin D-sub)
ANALOG/DIGITAL
640 x 400 @ 70-85 Hz (digital only)
720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-85 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-75 Hz
1280 x 1024 @ 60 Hz
Ultra-thin frame (bezel), GammaComp, TileMatrix,
TileComp, XtraView+ wide-angle viewing technology,
Ambix+ technology, Advanced No Touch Auto Adjust,
AutoBright, CableComp, power-off timer, black level
adjustment, Rapid Motion, digital smoothing, digital
controls, OmniColor 6-axis color control sRGB, third
party touchscreen and protective glass integration,
Plug and Play (VESA DDC2B & 2 Bi), VESA DPMS power
management, optional MultiSync SoundBar80, ISO
13406-2 automatic DVI selection
Yes
Yes
Designed for integration
Universal 100 (110-240V) 50-60 Hz internal
45W
<1W
411.5 x 366 x 200mm/16.2 x 14.4 x 7.9 in
411.5 x 337.8 x 78.7mm/16.2 x 13.3 x 3.1 in
21.4 lbs/9.7 kg
13.9 lbs/6.3 kg
100 x 100mm
5-35°C/41-95°F
30-80%
3048 m/10,000 ft
-10-60°C /14-140°F
10-85%
12,192 m/40,000 ft
3 years parts and labor, including backlight
24 hours/7 days
NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, Illinois 60143
866-NEC-MORE
www.necdisplay.com
MultiSync LCD2080UXi
20.1"/51 cm
0.255mm
100 @ native resolution
250 cd/m 2
700:1
176° Vert., 176° Hor.(88U/88D/88L/88R)(CR>10)
Rapid Response (16ms)
More than 16 million
31.5-91.1 kHz
50-85 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level (positive/negative)
Composite Sync: TTL Level (positive/negative)
Composite Sync on Green (0.3 Vp-p negative
0.7 Vp-p positive)
Ambix+ technology
(DVI-I, DVI-D, VGA 15-pin D-sub)
ANALOG/DIGITAL
640 x 400 @ 70-85 Hz (digital only)
720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-85 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-85 Hz
1600 x 1200 @ 60 Hz
1600 x 1200 @ 60 Hz
Ultra-thin-frame (bezel), XtraView+ wide-angle
viewing technology, Ambix+ technology,
Advanced No Touch Auto Adjust, AutoBright,
CableComp, power-off timer, black level
adjustment, digital smoothing, digital controls,
sRGB, OmniColor 6-axis color control sRGB,
third-party touch-screen and protective glass
integration, Plug and Play (VESA DDC2B & 2Bi),
VESA DPMS power management, optional
MultiSync SoundBar80, automatic DVI selection,
ISO 13406-2 Class II
Yes
Yes
Designed for integration
Universal 100 (110-240V) 50-60 Hz internal
54W
<1W
442 x 366 x 200mm/17.4 x 14.4 x 7.9 in
442 x 340 x 88.8mm/17.4 x 13.4 x 3.5 in
23.1 lbs/10.5 kg
15.4 lbs/7 kg
100 x 100mm
5-35°C/41-95°F
30-80%
4,658 m/12,000 ft
-10-60°C/14-140°F
10-85%
12,192 m/40,000 ft
3 years parts and labor, including backlight
24 hours/7 days
MultiSync LCD2180UX
21.3"/54 cm
0.27mm
94 @ native resolution
250 cd/m 2
500:1
176° Vert., 176° Hor.(88U/88D/88L/88R)(CR>10)
Rapid Response (20ms)
More than 16 million
31.5-91.1 kHz
50-85 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level (positive/negative)
Composite Sync: TTL Level (positive/negative)
Composite Sync on Green (0.3 Vp-p negative
0.7 Vp-p positive)
Ambix+ technology
(DVI-I, DVI-D, VGA 15-pin D-sub)
ANALOG/DIGITAL
640 x 400 @ 70-85 Hz (digital only)
720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-85 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-85 Hz
1600 x 1200 @60 Hz
1600 x 1200 @ 60 Hz
Ultra-thin frame (bezel), GammaComp,
TileMatrix, XtraView+ wide-angle viewing
technology, Ambix+ technology, Advanced
No Touch Auto Adjust, AutoBright, CableComp,
power-off timer, black level adjustment, digital
smoothing, digital controls, sRGB, OmniColor
6-axis color control sRGB, third party touch-
screen and protective glass integration, Plug
and Play (VESA DDC2B & 2Bi), VESA DPMS power
management, optional MultiSync SoundBar80,
automatic DVI selection, ISO 13406-2
Yes
Yes
Designed for integration
Universal 100 (110-240V) 50-60 Hz internal
52W
<1W
467 x 391 x 200mm/18.4 x 15.4 x 7.9 in
467 x 358.7 x 85mm/18.4 x 14.1 x 3.3 in
24.3 lbs/11.5 kg
17 lbs/7.7 kg
100 x 100mm
5-35°C/41-95°F
30-80%
4,850 m/15,900 ft
-10-60°C/14-140°F
10-85%
13,600 m/44,600 ft
3 years parts and labor, including backlight
24 hours/7 days
