MOUNTING REQUIREMENTS

2-M4
PC CONFIGURATOR
The following parameter items can be configured with the PC configurator software (model: R7CFG).
Refer to the users manual of the software for detailed operations.
■ INTERFACE SETTING
PARAMETER
Communication Timeout

DATA ALLOCATION

'Begin' address is determined by the R7F4DD's node address and the master setting.
■ Without status
Begin + 0
■ With status
15
Begin + 0 Status
unit: mm [inch]
125 [4.92]

SETTING RANGE

0 – 32767 (0.1 sec.)
Output data
Unused
Output data 0
