To attach the MultiSync
1. Turn off the power to your computer.
2. Remove connector cover and cable cover.
3. For the PC: Connect the 15-pin mini D-SUB of the appropriate signal cable to the
connector of the display card in your system (Figure A.1). Tighten all screws.
For the Mac: Connect the MultiSync LCD1545V ™ Macintosh cable adapter to the
computer (Figure B.1). Attach the 15-pin mini D-SUB end of the appropriate signal
cable to the MultiSync LCD1545V Macintosh cable adapter (Figure B.1). Tighten all
screws.
NOTE: To obtain the MultiSync LCD1545V Macintosh cable adapter, call NEC-Mitsubishi
Electronics Display of America, Inc. at (800) 632-4662.
4. Connect the 15-pin mini D-SUB of the video signal cable to the appropriate connector
on the back of the monitor. Place the Video Signal Cable under Clip B (Figure C.1).
5. Connect one end of the power cord to the MultiSync LCD Series monitor and the other
end to the power outlet. Place the Video Signal Cable and AC power cord under Clips
(Figure C.1). Replace connector cover and cable cover.
NOTE: Adjust position of cable that place under clips, to avoid damage for cable or
monitor.
NOTE: If you use this monitor at AC220-240V, please refer to Recommended Use
section of this manual for proper selection of AC power cord.
6. The Vacation Switch on the right side of the monitor must be turned on (Figure D.1).
Turn on the monitor with the front power button and the computer.
NOTE: The Vacation Switch is a true on/off switch. If this switch is on the OFF position,
the monitor cannot be turned on using the front button. DO NOT switch on/off
repeatedly.
7. No-touch auto adjust automatically adjusts the monitor to optimal settings upon initial
setup for most timings. For further adjustments, use the following OSM
• Auto Adjust Contrast
• Auto Adjust
Refer to the Controls section of this User 's Manual for a full description of these
OSM controls.
NOTE: For download information on the Windows
LCD monitor, refer to the References section of this User's Manual.
1545V
NOTE: If you have any problems, please refer to the Troubleshooting section of this User's Manual.
