- Page 1 APOLLON AUDIO 1ET400A MINI STEREO REFERENCE MANUAL HANDMADE IN SLOVENIA - EUROPE V 1.0 2022...
-
Page 2: Table Of Contents
Table of contents Safety warnings EXPERIENCE SOUND Introduction THAT PUTS A SMILE Front panel controls ON YOUR FACE Back panel connections Connectivity diagram Technical specifications Components... -
Page 3: Safety Warnings
Safety warnings 1. Please read and follow these instructions before using the amplifier. 2. Do not use this apparatus near water. 3. Clean only with a dry cloth. 4. Do not block any ventilation openings. 5. Do not install near any heat sources (including amplifiers)that produce heat. 7. -
Page 4: Introduction
At Apollon Audio we use only the best materials and connectors available on the market and also give you the option of configuring the enclosure to what suits you the best. -
Page 5: Front Panel Controls
Front panel LOGO WITH LED LIGHT Power ON/OFF button Brightness control for led front light (off, 30%, 60%, 100%) -
Page 6: Back Panel Connections
Back panel 6-12 channels Speaker output Speaker output Trigger MADE IN EU SERIAL #000 THRU TRIG INPUT INPUT GAIN SETTING(db) GAIN SETTING(db) SELECT SELECT BALANCED SINGLE-ENDED BALANCED SINGLE-ENDED RCA Input RCA Input Input select Input select Gain setting(db) Line Input (XLR) Line Input (XLR) Turn power off before inserting or removing cables. -
Page 7: Connectivity Diagram
Connectivity diagram MADE IN EU SERIAL #000 THRU TRIG INPUT INPUT GAIN SETTING(db) GAIN SETTING(db) SELECT SELECT BALANCED SINGLE-ENDED BALANCED SINGLE-ENDED 110V RCA or XLR RCA or XLR Audio source... -
Page 8: Technical Specifications
Technical specifications Frequency Response: 0 – 50k Hz +0/-3dB Low Distortion: THD+N – – 0.00017 % 20Hz-20kHz High Input Impedance 100K Signal to noise ratio: 131dB Gain (dB) 12,8/20,5/27,5/29 Ultra High Damping Factor High Current Output Max 25A Power rating: 450W @ 2ohm | 425W @ 4ohm | 227W @ 8ohm Case Dimensions: 350mm depth x 90mm height (with feet) x 280 mm width Weight: 6.8 kg... -
Page 9: Components
Components Hypex SMPS1200A400 (1 pcs.) Purifi 1ET400A amplifier (2 pcs.) Apollon Audio Input Buffer Board (1 pcs.) Apollon Control Board for standby control Neutrik silver plated XLR line input socket (2 pcs.) Gold plated RCA input with selector switch WBT 0703 CU binding posts (4 pcs.) - Page 10 Apollon Audio d.o.o. info@apollonaudio.com I www.apollonaudio.com...
