- Page 1 APOLLON AUDIO NC500 MULTICHANNEL (6-12) REFERENCE MANUAL HANDMADE IN SLOVENIA - EUROPE V 1.0 2022...
-
Page 2: Table Of Contents
Table of contents Safety warnings EXPERIENCE SOUND Introduction THAT PUTS A SMILE Front panel controls ON YOUR FACE Back panel connections Connectivity diagram Technical specifications Components... -
Page 3: Safety Warnings
Safety warnings 1. Please read and follow these instructions before using the amplifier. 2. Do not use this apparatus near water. 3. Clean only with a dry cloth. 4. Do not block any ventilation openings. 5. Do not install near any heat sources (including amplifiers)that produce heat. 7. -
Page 4: Introduction
At Apollon Audio we use only the best materials and connectors available on the market and also give you the option of configuring the enclosure to what suits you the best. -
Page 5: Front Panel Controls
Front panel LOGO WITH LED LIGHT Power ON/OFF button... -
Page 6: Back Panel Connections
Back panel 6-12 channels Speaker output Trigger THRU TRIG BALANCED BALANCED BALANCED BALANCED BALANCED BALANCED Brightness control Input select INPUT INPUT INPUT INPUT INPUT INPUT for led front light SELECT SELECT SELECT SELECT SELECT SELECT SINGLE-ENDED SINGLE-ENDED SINGLE-ENDED SINGLE-ENDED SINGLE-ENDED SINGLE-ENDED (off, 30%, 60%, 100%) RCA Input... -
Page 7: Connectivity Diagram
Connectivity diagram RCA or XLR Trigger (optional) THRU TRIG BALANCED BALANCED BALANCED BALANCED BALANCED BALANCED INPUT INPUT INPUT INPUT INPUT INPUT SELECT SELECT SELECT SELECT SELECT SELECT SINGLE-ENDED SINGLE-ENDED SINGLE-ENDED SINGLE-ENDED SINGLE-ENDED SINGLE-ENDED MADE IN EU SERIAL #000 GAIN SETTING(db) GAIN SETTING(db) GAIN SETTING(db) GAIN SETTING(db) -
Page 8: Technical Specifications
Technical specifications Frequency Response: 0 – 50k Hz +0/-3dB Low Distortion: THD+N – – 0.00080 % 20Hz-20kHz High Input Impedance 94K Signal to noise ratio: 135dB Gain (dB) 12,8/20,5/27,5/29 Ultra High Damping Factor High Current Output Max 28A Power rating: 550W @ 2ohm | 700W @ 4ohm | 400W @ 8ohm Case Dimensions: 375mm depth x 200mm height (with feet) x 450 mm width Weight: 20-23 kg... -
Page 9: Components
Components Hypex SMPS3000A700 (2 pcs.) Hypex Nc500 amplifier (6-12 pcs.) Apollon Audio Input Buffer Board with OPA1612 op amps Apollon Control Board for standby control Neutrik silver plated XLR line input socket Gold plated RCA input with selector switch WBT 0703 CU binding posts... - Page 10 Apollon Audio d.o.o. info@apollonaudio.com I www.apollonaudio.com...
