Troubleshooting

No picture
• The signal cable should be completely connected to the display card/computer.
• The display card should be completely seated in its slot.
• Make sure the Vacation Switch is in the ON position.
• Front Power Switch and computer power switch should be in the ON position.
• Check to make sure that a supported mode has been selected on the display card or system
being used. (Please consult display card or system manual to change graphics mode.)
• Check the monitor and your display card with respect to compatibility and recommended
settings.
• Check the signal cable connector for bent or pushed-in pins.
• Check the signal input, "INPUT " or "INPUT 2".
Power Button does not respond
• Unplug the power cord of the monitor from the AC outlet to turn off and reset the monitor.
• Check the Vacation Switch on the back side of the monitor.
Image Persistence
• Please be aware that LCD Technology may experience a phenomenon known as Image
Persistence. Image Persistence occurs when a residual or "ghost" image of a previous im-
age remains visible on the screen. Unlike CRT monitors, LCD monitors' image persistence
is not permanent, but constant images being displayed for a long period of time should be
avoided.
To alleviate image persistence, turn off the monitor for as long as the previous image was
displayed. For example, if an image was on the monitor for one hour and a residual im-
age remains, the monitor should be turned off for one hour to erase the image.
As with all personal display devices, NEC DISPLAY SOLUTIONS recommends displaying
moving images and using a moving screen saver at regular intervals whenever the screen
is idle or turning off the monitor when not in use.
Image is unstable, unfocused or swimming is apparent
• Signal cable should be completely attached to the computer.
• Use the OSM Image Adjust controls to focus and adjust display by increasing or decreas-
ing the fine total. When the display mode is changed, the OSM Image Adjust settings may
need to be re-adjusted.
• Check the monitor and your display card with respect to compatibility
and recommended signal timings.
• If your text is garbled, change the video mode to non-interlace and use 60Hz refresh rate.
LED on monitor is not lit (no blue or amber color can be seen)
• Power Switch should be in the ON position and power cord should be connected.
• Make sure the Vacation Switch is in the ON position.
• Make sure the LED Brightness Control within the OSM is at the proper setting.
Display image is not sized properly
• Use the OSM Image Adjust controls to increase or decrease the H.SIZE.
• Check to make sure that a supported mode has been selected on the display card or system being
used. (Please consult display card or system manual to change graphics mode.)
No Video
• If no video is present on the screen, turn the Vacation Switch off and on again.
• Make certain the computer is not in a power-saving mode (touch the keyboard or mouse).
USB Hub does not operate
• Make sure the USB cable is properly connected. Refer to the User's Manual of the USB
device.
