  • Page 1 MultiSync 70GX MultiSync 90GX User’s Manual...

  • Page 2: Table Of Contents

    Index Warning, Caution ......................... English-1 Declaration ...........................English-1 Canadian Department of Communications Compliance Statement ..........English-2 Declaration of Conformity ......................English-2 Contents ............................English-3 Quick Start ...........................English-4 Controls ............................English-8 Recommended use ........................English-10 Recommended use ........................English-10 Recommended use ........................English-10 Specifications for MultiSync 70GX Pro ..................

  • Page 3: English

    NaViSet is a trademark of NEC Display Solutions Europe GmbH in the countries of EU and Switzerland. MultiSync is a registered trademark of NEC Display Solutions, Ltd. in the countries of U.K., Italy, Austria, Netherlands, Switzerland, Sweden, Spain, Denmark, Germany, Norway and Finland.

  • Page 4: Canadian Department Of Communications Compliance Statement

    This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. U.S. Responsible Party: NEC Display Solutions of America, Inc. Address: 500 Park Blvd, Suite 1100 Itasca, Illinois 60143 Tel.

  • Page 5: Contents

    Contents Your new NEC MultiSync LCD monitor box* should contain the following: • MultiSync 70GX Pro, 90GX Pro monitor with tilt/swivel adjust stand • Power Cord • Video Signal Cable (15-pin mini D-SUB male to 15-pin mini D-SUB male) •...

  • Page 6: Quick Start

    Quick Start To attach the MultiSync LCD monitor to your system, follow these instructions: 1. Turn off the power to your computer. 2. For the PC or MAC with DVI digital output: Connect the DVI signal cable to the connector of the display card in your system (Figure A.1).
  • Page 7 6. Place the connector cover onto the back cabinet (Figure C.4). 7. Place all cables into the hooks (Figure C.5). 8. Place hands on each side if the monitor to tilt the LCD panel back 5° (Figure C.6). Figure C.4 Figure C.5 9.

  • Page 8: Remove Monitor Stand For Mounting

    Tilt and Swivel Grasp both sides of the monitor screen with your hands and adjust the tilt and swivel as desired (Figure TS.1). NOTE: Handle with care when tilting and swivelling the monitor screen. Figure TS.1 Remove Monitor Stand for Mounting To prepare the monitor for alternate mounting purposes: 1.

  • Page 9: Flexible Arm Installation

    5. Lift up the stand to unlatch the upper hooks and remove the stand (Figure M.4). 6. Remove the 2 screws on the top of the monitor (Figure M.5). The monitor is now ready for mounting in an alternate manner. 7.

  • Page 10: Controls

    Controls OSM (On-Screen Manager) control buttons on the front of the monitor function as follows: To access OSM menu, press any of the control buttons (MENU/EXIT, Left, Right, Down, Up). To change signal input, press the SELECT button. To change DV MODE, press the RESET/DV MODE button. NOTE: OSM must be closed in order to change signal input.

  • Page 11: Menu Tools

    Colour Control System Colour Control System: Six colour presets select the desired colour setting (sRGB and NATIVE colour presets are standard and cannot be changed). R,G,B: Increases or decreases Red, Green or Blue colour depending upon which is selected. The change in colour will appear on screen and the direction (increase or decrease) will be shown by the bars.

  • Page 12: Recommended Use

    NOTE: As with all personal display devices, NEC DISPLAY SOLUTIONS recommends displaying moving images and using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.
  • Page 13 CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE FOLLOWING WHEN YOU POSITION THE MONITOR: • For optimum performance, allow 20 minutes for warm-up. • Adjust the monitor height so that the top of the screen is at or slightly below eye level. Your eyes should look slightly downward when viewing the middle of the screen.

  • Page 14: Specifications For Multisync 70Gx 2 Pro

    Specifications for MultiSync 70GX Monitor Specifications MultiSync 70GX Pro Monitor Notes LCD Module Diagonal: 43.2 cm/17.0 inches Active matrix; thin film transistor (TFT) Viewable Image Size: 43.2 cm/17.0 inches liquid crystal display (LCD); 0.264 mm dot Native Resolution (Pixel Count): 1280 x 1024 pitch;...

  • Page 15: Specifications For Multisync 90Gx Pro

    Specifications for MultiSync 90GX Monitor Specifications MultiSync 90GX Pro Monitor Notes LCD Module Diagonal: 48.2 cm/19.0 inches Active matrix; thin film transistor (TFT) Viewable Image Size: 48.2 cm/19.0 inches liquid crystal display (LCD); 0.294 mm dot Native Resolution (Pixel Count): 1280 x 1024 pitch;...

  • Page 16: Features

    Features Thin-frame design creates more desktop space for you to work and play, while the flat screen’s crisp, bright images and crystal- clear text deliver a comfortable viewing experience. No Touch Auto Adjust automatically adjusts your optimal image settings upon initial power-on. Colour Control System allows you to change between six colour settings on your display to match your personal preference.

  • Page 17: Troubleshooting

    NOTE: As with all personal display devices, NEC DISPLAY SOLUTIONS recommend displaying moving images and using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.

  • Page 18: Tco'03

    TCO’03 Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the impact on our natural environment.

  • Page 19: Manufacturer's Recycling And Energy Information

    Manufacturer’s Recycling and Energy Information NEC DISPLAY SOLUTIONS is strongly committed to environmental protection and sees recycling as one of the company’s top priorities in trying to minimize the burden placed on the environment. We are engaged in developing environmentally- friendly products, and always strive to help define and comply with the latest independent standards from agencies such as ISO (International Organisation for Standardization) and TCO (Swedish Trades Union).
