Summary of Contents for AUO PN27FTN02.0
- Page 1 PN27FTN02.0 Touch LCD Monitor User Manual...
-
Page 3: Table Of Contents
Contents Safety Precautions ……………………………………………………………………………………………… Product Introduction …………………………………………………………………………………………… Installation ……………………………………………………………………………………………………… Adjustment ..…………………………………………………………………………………………………… Instructions ..…………………………………………………………………………………………………… OSD Menu ..……………………………………………………………………………………………………. Parameters .…………………………………………………………………………………………………… Troubleshooting ………………………………………………………………………………………………. -
Page 4: Safety Precautions
Safety Precautions Please read this manual carefully before using the product and keep it in a safe place. WARNING: Use of control, adjustments or procedures other than those specified in this documentation may result in exposure to shock, electrical hazards and/or mechanical hazards. Warning: Excessive use may damage the eyesight. - Page 5 Précautions de sécurité Veuillez lire attentivement ce manuel avant d'utiliser ce produit et le conserver en lieu sûr. Avertissement: l'utilisation de commandes, de réglages ou de procédures autres que ceux précisés dans le présent document peut entraîner un choc électrique, un danger électrique et / ou un danger mécanique. Attention: Un surdosage peut endommager la vue.
-
Page 6: Product Introduction
The color and shape of parts may vary with models. Figures in this User Manual are for reference only. Monitor Stand Base Power cable Power adapter HDMI signal cable PN27FTN02.0 Touch LCD Monitor User Manual Type-C signal cable USB A-B cable User manual Please be sure to use regular USB-B 3.0 cables... -
Page 7: Installation
Installation Installation procedure Open the package to take out foams and put them on a flat tabletop. Base Stand Remove the upper foam cover and set it aside, remove the plastic bag of the monitor and place the monitor in the lower foam cover. Put the monitor in the lower foam cover. Screwed the bracket and base by thumb screw. - Page 8 Put the assembled base into the corresponding slot of the back shell, gently press the bracket to lock it into the lock, please make sure it can be locked. Quick-disassembly button Hold it to the final position, then finished. Note: Please do not press the screen glass when doing the assembling.
-
Page 9: Adjustment
Adjustment Vertical angle Rotation angle ±90°(±2.0°) ±22.5°(±2.5°) -5° 20° 150mm Tilting angle Height adjustment -5.0°(±2.0°) ~ +20°(±2.0°) 150mm(±5.0mm) -
Page 10: Instructions
Instructions Description of buttons Button Function Menu button: Press to enter sub-menus/quickly enter the main menu Down button: Press to move down in the menu/quickly adjust the brightness Up button: Press to move up in the menu/quickly adjust the volume Exit/hot key: Press to return to the previous menu/quickly switch input signals of the port Power button: Press to turn on/off the monitor Explanation of indicator light... - Page 11 Cabling The final interface configuration depends on product spec. Note: If the power cable or signal cable is damaged, you must replace it or purchased from the manufacture or maintenance department. Note: To enabled the camera/microphone, please make sure the cable is properly connected (USB A-B or USB-C) and start the software on the computer to turn on the camera/microphone.
-
Page 12: Osd Menu
OSD Menu The color and shape of the OSD menu may be slightly different of shown. OSD menu may changed by function improvements. Press one of the buttons ( ) to activate the function. Enter the main menu Adjust the brightness Adjust the volume Switch... - Page 13 The functions list in this manual are for reference only. Standard Mode sRGB Mode Adobe Mode Gamma 1.6/1.8/2.0/2.2/2.4/2.6/2.8/S.curve C.T Settings Natural/Design/Warm/Cool/User C.T1/User C.T2/User C.T3 Sharpness Professional Shadow Balance 0-100 Low Blue Light 0-100 R/G/B/C/M/Y Saturation R/G/B/C/M/Y Dynamic Brightness Off/Normal/Expert/Elaboration Brightness 0-100 Contrast 0-100...
-
Page 14: Parameters
Parameters Product model PN27FTN02.0 Product name Touch LCD Monitor 27inch(69cm) Screen size Aspect ratio 16:9 Viewing angle 178°(H) / 178°(V) Pixel pitch 0.3114(H)×0.3114(V)mm Contrast ratio 1000:1(TYP) Color 16.7M Resolution 1920x1080 Refresh rate 60Hz Camera 4 MIC array incell Touch, support 10 points... -
Page 15: Troubleshooting
Troubleshooting Problem Possible Solutions Please check the power cable No power indicator Please ensure the power supply You can adjust the screen brightness and contrast No vivid screen image Please change to anther place to check, the environment has the Signal noise or blur image electrical noise problem or not Please check power on of computer... - Page 16 AUO Display Plus Corporation Tel: +886-3-5631288 No. 1, Industrial East 3rd Road, East District, Hsinchu Science Park, Hsinchu City, Taiwan Add:...
