- Page 1 Model/s Version EO9060XL9M V1.2 1022 Everything you need for your 90×60cm 9 Function Built-in Oven is in this User Manual...
- Page 2 Australia 3121 — requirements of your appliance to ensure optimum performance. Telephone 1300 11 4357 Again, thank you for choosing an Esatto appliance and we look forward to being of service to you. Kind Regards, The Residentia Team www.esatto.house...
-
Page 3: Table Of Contents
Contents Page 2 Page 4 Welcome Safety Instructions Page 8 Page 12 Installation Your Built-in Oven Instructions Page 13 Page 14 Technical Operation Specifications Instructions Page 16 Page 20 Maintenance Troubleshooting & Cleaning Page 23 Page 24 Purchase Details... - Page 4 BEFORE USING YOUR APPLIANCE This manual explains the proper use of your new WARNING: Indicating information concerning Esatto oven. Please read this manual carefully your personal safety. before using the product. This manual should be kept in a safe place for handy reference.
- Page 5 SAFETY INSTRUCTIONS BEFORE INSTALLATION • Before the installation and use of the appliance, • Remove all the packaging. carefully read the supplied instructions. • Do not install or use a damaged appliance. • The manufacturer is not responsible if an •...
- Page 6 User Manual Safety Instructions (Continued) ELECTRICAL CONNECTION WARNING: If the supply cord is damaged, it must be replaced by the manufacturer or its service CAUTION: Risk of fire and electrical shock! agent or similarly qualified person in order to avoid a hazard.
- Page 7 Y HINTS esatto.house ot use the oven unless you are wearing something on your feet. Do not touch the oven wet or damp hands or feet. oven: Oven door should not be opened often during the cooking period. appliance must be installed by an authorized technician and put into use. The producer is esponsible for any damage that might be caused by defective placement, and installation CARE &...
-
Page 8: Installation Instructions
User Manual Installation Instructions INSTALLATION WARNINGS INSTALLATION LOCATION Ensure that electrical installation is suitable • Product has been designed to be mounted to for the operation the appliance. If not, call an worktops procured from market. A safe distance electrician and plumber to make necessary must be left between the product and kitchen arrangements. - Page 9 INSTALLATION AND MOUNTING PLACING AND SECURING THE OVEN • Place of use for product must be located before • Place the oven into the cabin with two or starting installation. more people. • Product mustn't be installed in places which are •...
- Page 10 User Manual Installation Instructions (Continued) INSTALLATION UNDER COUNTER Figure 4 • Cabin must match the dimensions provided in Figure 4 • A clearance must be provided at the rear part of the cabin as indicated in Figure 4 so that necessary ventilation can be achieved.
- Page 11 INSTALLATION IN AN ELEVATED CABINET Figure 5 • Cabin must match the dimensions provided in Figure 5. • The clearances with the dimensions indicated in the figure must be provided at the rear part of cabin, upper and lower sections so that necessary ventilation can be achieved.
- Page 12 ºC B. Timer Knob C. Temperature Knob ACCESSORIES Your Esatto Built-in Oven is supplied with: • 1 × Baking Tray For cooking food such as roasts, cakes, pastries, frozen food etc, or for collecting fat/spillage and meat juices. • 1 × Wire Shelf For roasting, grilling and baking.
-
Page 13: Technical Specifications
Technical Specifications Model EO9060XL9M Volume: 129L Product Dimensions (W × D × H): 896 × 565 × 595mm Weight (Net/Gross): 50.8kg / 52.5kg Supply Voltage 220-240V AC 50/60 Hz Rated Power 3.6kW No. of Functions Lamp Power 15 W Thermostat 40-240 / Max °C... - Page 14 User Manual Operating Instructions OVEN FUNCTIONS SYMBOL FUNCTION DESCRIPTION Oven Light: Enables the user to observe the progress of cooking without opening the door. Bake (Conventional): Ideal for cakes, pizza & cookies. Steam Cleaning: Loosen dirt & grease with steam before cleaning your oven. Please read the instructions on page 15 before using this function.
- Page 15 MANUAL COOKING MODE In manual cooking mode, the cooking duration is controlled by the user without a timer. 1. Rotate the Timer Knob counter clockwise to the “ M ” position to engage Manual Cooking mode. This will stop the oven from automatically powering off while in the “ M ” position.
-
Page 16: Maintenance & Cleaning
User Manual Maintenance & Cleaning PRIOR TO CLEANING YOUR OVEN WARNING: • Before any maintenance and cleaning, turn off the appliance and disconnect the power. • Set all controls in the OFF position. • Wait until the inside of the unit is not hot but only slightly warm—cleaning is easier than when warm. - Page 17 REMOVING THE OVEN DOOR The removable door allows for full access to the entire interior of the oven for easier and quicker maintenance. Follow these instructions carefully if you wish to remove the oven door. 1. To remove the door, open the door fully towards 3.
- Page 18 Cleaning Oven Glass Lift by pressing on plastic latches on left and right side as shown in figure User Manual 10 and pulling the profile toward yourself as in figure 11. Glass is released after profile is removed as shown in figure 12. Remove the Maintenance &...
- Page 19 Rack 1 and upper wire Installing and removing wire racks To remove wire racks, press the clips show esatto.house Rack Positions first remove the lower, and than the upper sid It is important to place the wire grill into To install wire racks; reverse the procedure fo the oven properly.
- Page 20 User Manual Troubleshooting OPERATION IN CASE OF EMERGENCY In the event of an emergency you should: • Set all controls in the OFF position and disconnect the power. • Call After Sales Support on 1300 11 4357 or email support@residentiagroup.com.au Some minor faults can be fixed by referring to the instructions given in the table below.
- Page 21 ISSUE POSSIBLE CAUSE COMMON RESOLUTIONS Electric shock when No proper grounding. Make sure power supply is grounded properly. touching the oven. Ungrounded wall socket is used. Water dripping. Water or steam Let the oven cool down and than wipe dry with may generate under a cloth.
- Page 22 User Manual Attach your receipt to this page...
-
Page 23: Purchase Details
Purchase Details For your records, please record details of your purchase below and staple your receipt on the opposite page. Your serial number can be found on the rating plate of your Built-in Oven. STORE DETAILS STORE NAME ADDRESS... -
Page 24: Warranty
User Manual Warranty WARRANTY TERMS AND CONDITIONS IN THIS WARRANTY BUILT-IN OVENS ‘acceptable quality’ as referred to in clause 10 of this warranty has the same meaning referred to in This document sets out the terms and conditions of the the ACL;... - Page 25 You will bear the cost of transportation, travel and For Appliances and services provided by Residentia delivery of the Appliance to and from Residentia Group in Australia, the Appliances come with a Group or its ASR. If you reside outside of the service...
- Page 26 – that you can refer to at any time. purchaser; Simply visit the below website, or ask your retailer for help: www.esatto.house/nz/registration h) damage caused by power outages or surges damage caused by pests WARRANTY (eg.
- Page 27 This page is intentionally blank. But if you want to draw something, make notes or even write a recipe, it’s all yours!
- Page 28 everything you need A RESIDENTIA GROUP INITIATIVE...
