Zoeller QWIK JON PREMIER 201 Quick Reference Manual

QWIK JON
https://www.zoellerpumps.com/zh-cn/
https://www.zoellerpumps.com/en-na/
QUICK REFERENCE GUIDE.
SEE INSTRUCTION MANUAL FOR
COMPLETE DE TAILS.
3
Connect the discharge pipe to the top of the Qwik Jon
®
© Copyright 2020 Zoeller Co. All rights reserved.
®
PREMIER
1
Connect the rear discharge toilet to the front inlet of the Qwik
MODEL #201
Jon ® Premier. Ensure the connections are in accordance with
local, regional, and state codes.
4
®
The Qwik Jon Premier has an inlet on either side allowing side
® Premier.
inlet connections from other bathroom fixtures.
FIRE/EXPLOSION HAZARD.
2 Connect the drain pipe from another bathroom fixture to the side
inlet on the Qwik Jon ® Premier. Notice the side inputs have built in
check valves and are compatible with many piping sizes. The pipe
adaptor needs to be cut in the center. Ensure the connections are
in accordance with local, regional, and state codes.
5
Plug the power cord into a wall socket to provide power to the unit.
These drawings are for reference only.
Exact components may differ by region.
084960 A
