QUICK REFERENCE GUIDE.
SEE INSTRUCTION MANUAL FOR
COMPLETE DE TAILS.
3
Connect the discharge pipe to the top of the Qwik Jon
© Copyright 2020 Zoeller Co. All rights reserved.
®
QWIK JON CHOICE
®
1
Connect the rear discharge toilet to the front inlet of the Qwik
MODEL #200
Jon Choice. Ensure the connections are in accordance with
®
local, regional, and state codes.
4
The Qwik Jon
Choice.
®
inlet connections from other bathroom fixtures.
FIRE/EXPLOSION HAZARD.
and/or explosive atmosphere. Failure to follow these warnings could result in death or serious injury and/or
property damage.
® Choice has an inlet on either side allowing side
2
Connect the drain pipe from another bathroom fixture to the side
inlet on the Qwik Jon Choice. Notice the side inputs have built in
®
check valves and are compatible with many piping sizes.
Ensure the connections are in accordance with local, regional, and
state codes.
5
Plug the power cord into a wall socket to provide power to the unit.
084814 A
