Assembly procedure for a table with round anchors on legs
Procédure d'assemblage d'une table à pattes avec ancrages ronds
Procedimiento de ensamblaje de una mesa con patas de anclaje redondo
a
b
16 x
16 x
1
· Turn upside down the top carefully. Place the leg on the anchor.
Make sure that the openings on the leg are facing the outside of the table.
· Renverser le dessus. Déposer la patte contre l'ancrage.
S'assurer que les trous sur la patte soient vers l'extérieur de la table.
· Voltear la parte superior de la mesa. Colocar las pata contra los anclajes.
Asegúrese de que los agujeros en la pata estén hacia el exterior de la mesa.
TOP
DESSUS
PARTE SUPERIOR
QUI1SACZ006 | RÉVISION P00 | 2021-03
c
4 x
c
ANCHOR
ANCRAGE
ANCLAJE
2
· Insert a washer and screw a bolt in each opening of the leg,
starting with the nearest opening to the top.
Repeat for the other legs.
· Insérer une rondelle et visser un boulon dans chaque
trou de la patte en commençant par les trous près du dessus de la table.
Répéter pour les autres pattes.
· Insertar una arandela y atornillar un perno en cada agujero de la pata
comenzando con los agujeros cerca de la parte superior de la mesa.
Repetir procedimiento para las otras patas.
LEG
PATTE
LEG
PATA
PATTE
PATA
4 x
16 x
LOF HD
a
b
Do not climb on the table.
Risk of serious injuries.
Ne pas monter sur la table.
Risque de blessures graves.
No treparse sobre la mesa.
Riesgo de herirse gravemente.
