- Page 1 PT-PTC-A-BT Ethernet Adaptor Fast Installation Manual WWW.PROCETPOE.COM Data Code:PTD2206002...
- Page 2 Statement Copyright ©2022 Creative Lianjie Network Technology Co., Ltd. Copy right, all rights reserved. e contents of this manual cannot be copied, plagiarised, or translated by any company or individual without the express written permission of Creative Lianjie Network Technology Co., Ltd.
- Page 3 Product Pro le PT-PTC-A-BT is a network power adapter designed based on the IEEE802 .3at standard. e output is a standard Type-C in terface, which can provide 5V/3A 9V/3A 12V/3A 15V/3A 20V/3A power supply. PT-PTC-A-BT is designed with a small...
- Page 4 Product Working Diagram � � 1.RJ45 Port Input Power Supply LED Indicator (Yellow) P o E I N Light On:Normal power supply Power Link/Act Light O :Abnormal power supply � 2.Type-C Port Output Power Supply LED Indicator (Green) Light On:Normal connection Light O :Abnormal connection �...
- Page 5 Product Working Diagram Input 44-57V DC Input PoE Compliance IEEE802.3 bt Pin Assignment 4/5(+),7/8(-) Or3/6(+),1/2(-) Or 3/6(-),1/2(+) Output 5V 3A 9V 3A 12V 3A 15V 3A 20V 3A Output Data Speed None -20℃ To 40℃ Operating Temperature Operating Humidity 20%-80%， No Condensation Work Operating Altitude Below2000m...
- Page 6 Product Working Diagram Light On: Normal connection Light O : Not connected or failed to connect Green Blinking: Data transfer Light On: Normal power supply Yellow Light O : Abnormal power supply FCC CFR47 Part 15 EN 55032-2015 EN 55035-2017 —5—...
-
Page 7: Product Dimensions
Product Dimensions 60MM 22MM Pic3-1 Product Dimensions —6—... -
Page 8: Product Use
Product Use Pic5-1 Product Connection Diagram Notice: 1.Connect the PoE network cable to the RJ45 port of this Power Adaptor, use a CAT5 or above network cable, and the length should be less than 100m . 2.Connect one end of the Type-C cable to the output port of this product, and the other end to the powered device (Such as a mobile phone, tablet computer,etc.) 3.If you need to replace the Type-C cable, please purchase a genuine cable that supports 100Mbps data transmission. - Page 9 Declaration of Toxic and Hazardous Substances 《Measures for the Administration of the Restricted Use of the Hazardous Substances Item Contained inElectrical and Electronic Products 》 Restricted Substances or Elements Cr VI PBDE ○ ○ ○ ○ ○ × Metal Parts ○...
- Page 10 is product should not be discarded is product should not be discarded randomly a er it has expired or is unworked in maintenance. Please hand it over to a company quali ed for the disposal of waste electronic products. Please refer to the national or local regulations on the disposal of WEEE for the correct method.
