Sunricher SR-2300T-OLED Instruction Manual

Dali master controller touch panel

Advertisement

Quick Links

Contents
CONTENTS ---------------------------------------------------------------------------------------------------------------------------------------
1 PRRODUCT DESCRIPTION & FEATURES -------------------------------------------------------------------------------------------
1.1 PRRODUCT DESCRIPTION ------------------------------------------------------------------------------------------------------------
1.2 ELECTRIC PARAMETERS --------------------------------------------------------------------------------------------------------------
2 OPERATIONS ---------------------------------------------------------------------------------------------------------------------------------
2.1 KEY FUNCTION DEFINITION & DESCRIPTION ----------------------------------------------------------------------------------
2.1.1 Layout of Panel Keys (EU Size) ------------------------------------------------------------------------------------------------------
2.1.2 Key Function Definition (EU Size) ---------------------------------------------------------------------------------------------------
2.2 OPERATION INSTRUCTION -----------------------------------------------------------------------------------------------------------
2.2.1 LOCK & UNLOCK THE PANEL ------------------------------------------------------------------------------------------------------
2.2.2 LIGHTING CONTROL ------------------------------------------------------------------------------------------------------------------
3 FUNCTIONALITY INSTRUCTION -------------------------------------------------------------------------------------------------------
3.1 Control Page ---------------------------------------------------------------------------------------------------------------------------------
3.1.1 Control Area -------------------------------------------------------------------------------------------------------------------------------
3.1.2 Control Parameters Setting -----------------------------------------------------------------------------------------------------------
4.2 Control Gear Parameters Configuration -------------------------------------------------------------------------------------------
4.2.1 Address Configuration ------------------------------------------------------------------------------------------------------------------
4.2.2 Gear Parameters Configuration ------------------------------------------------------------------------------------------------------
4.2.3 Gear Scene Configuration -------------------------------------------------------------------------------------------------------------
4.2.4 Gear Group Configuration -------------------------------------------------------------------------------------------------------------
4.2.5 Identify Gear ------------------------------------------------------------------------------------------------------------------------------
4.2.6 Timer Task Configuration ---------------------------------------------------------------------------------------------------------------
4.2.7 Cycle Schedule Configuration --------------------------------------------------------------------------------------------------------
4.2.8 Bionic Schedule Configuration -------------------------------------------------------------------------------------------------------
4.2.9 Push Button Address Configuration --------------------------------------------------------------------------------------------------
4.2.10 Identify Device ---------------------------------------------------------------------------------------------------------------------------
4.3 System Parameter Setting ---------------------------------------------------------------------------------------------------------------
4.3.1 Enter into & Quit from System Parameter Setting Page -----------------------------------------------------------------------
4.3.2 DALI Master ID Setting -----------------------------------------------------------------------------------------------------------------
4.3.3 Beep Attribute Setting ------------------------------------------------------------------------------------------------------------------
4.3.4 Vibrator Setting ---------------------------------------------------------------------------------------------------------------------------
4.3.5 Lock Panel Setting -----------------------------------------------------------------------------------------------------------------------
4.3.6 OFF Display Setting ---------------------------------------------------------------------------------------------------------------------
4.3.7 Auto Return Home Setting -------------------------------------------------------------------------------------------------------------
4.3.8 System Time Setting --------------------------------------------------------------------------------------------------------------------
4.3.9 Backlit Setting ----------------------------------------------------------------------------------------------------------------------------
4.3.10 Battery Voltage Status ----------------------------------------------------------------------------------------------------------------
4.3.11 OLED Brightness Configuration -----------------------------------------------------------------------------------------------------
4.3.12 Cycle Runing Status -------------------------------------------------------------------------------------------------------------------
4.3.13 Bionic Runing Status ------------------------------------------------------------------------------------------------------------------
4.3.14 DALI Bus Status ------------------------------------------------------------------------------------------------------------------------
4.3.15 Firmware Version Information -------------------------------------------------------------------------------------------------------
4.3.16 Factory Reset Setting ---------------------------------------------------------------------------------------------------------------
5 INSTALLATION --------------------------------------------------------------------------------------------------------------------------------
6 WIRING DIAGRAM ---------------------------------------------------------------------------------------------------------------------------
6.1 DALI Connection ----------------------------------------------------------------------------------------------------------------------------
6.2 Master & PC Connection (If DALI PC software needs to be used) --------------------------------------------------------------
1
DALI Master Controller Touch Panel
1
2
2
2
Important: Read All Instructions Prior to Installation
3
3
Safety & Warnings
3
• DO NOT install with power applied to device.
3
• DO NOT expose the device to moisture.
4
4
4
1 PRODUCT DESCRIPTION & FEATURES
5
1.1 Product Description
5
The DALI Master control panel is a central controller of a DALI system to control DALI control gears on the DALI line. Its
5
main features are as follows:
6
(1) Enables to automatically assign and manage addreses to up to 64 control gears.
7
(2) Enables to control up to 64 control gears with 64 addresses.
7
(3) Supports 5 DALI control gear device types: DT6, DT8 Tc, DT8 XY coordinate, DT8 RGBWA, DT7 Switching actuator.
(4) Enables to set up to 16 DALI scenes for each control gear.
7
(5) Enables to assign each control gear to up to 16 DALI groups.
7
(6) Enables to set up to 256 timer tasks, each timer task can be configured as follows:
8
a.to recall a DALI scene, and the destination control gears can be all control gears, a designated group or a designated
10
11
b.to start and stop a brightness fade and color fade cycle schedule, and the destination control gears can be all control
11
gears, a designated group or a designated control gear.
c.to start and stop a 24-hour Bionic schedule for the CCT control gears, and the destination control gears can be all CCT
12
control gears, CCT control gears in a designated group or a designated CCT control gear.
14
(7) Enables to set up to 4 types brightness fade and color fade cycle schedule, the destination control gears of each
15
cycle schedule can be one designated color type control gear, and the destination control gears can be all control gears
15
with designated color type, control gears with designated color type in a designated group or a designated control gear
17
with the designated color type. The cycle schedule is to control brightness fade and color fade.
(8) Enables to set up to 4 Bionic color temperature schedules for the CCT control gears, each color temperature
17
schedule curve can set brightness and color temperature from 0:00 to 23:00, total 24 hours time range. The Bionic
17
schedule is the bionic control of brightness fade and color temperature fade changing according to the change of natural
17
light.
18
(9) Enables to set and manage the following parameters: beeper volume and tone, vibrator vibrating effect, backlit
18
brightness, RTC, lock display, off display, bus status etc.
19
(10) With PC configuration software tool, enables to configure and read parameters of the DALI control panel and control
gears, and manage the control panel and control gears.
19
20
20
1.2 ELECTRIC PARAMETERS
21
21
Output Signal
21
22
Power Supply
22
Power consumption
22
23
Operating temperature
23
23
Relative humidity
24
Dimensions
24
24
DALI signal
100-240VAC
< 15 mA
0-40°C
8% to 80%
86x86x41mm
