Multi-Tech RouteFinder RF102S User Manual

Dual serial port router with built-in 4-port 10/100 switch
Hide thumbs Also See for RouteFinder RF102S:
Table of Contents

Advertisement

Quick Links

Download this manual
Model RF102S
Dual Serial Port Router
with built-in 4-port 10/100 Switch
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RouteFinder RF102S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Multi-Tech RouteFinder RF102S

Summary of Contents for Multi-Tech RouteFinder RF102S

  • Page 1 Model RF102S Dual Serial Port Router with built-in 4-port 10/100 Switch User Guide...
  • Page 2 Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes.

  • Page 3: Table Of Contents

    Specifications ... 11 Chapter 2 - Hardware Installation ... 12 Hardware Installation ... 13 Safety ... 13 Unpacking the RF102S ... 13 Cabling ... 14 Chapter 3 - Software Installation and Configuration ... 15 Software Installation and Configuration ... 16 Software Installation ...
  • Page 4 Save Settings to File ... 52 Load Settings ... 53 Upgrade Firmware ... 53 General Diagnostic ... 54 Chapter 6 - RouteFinder Monitor ... 55 RouteFinder Monitor ... 56 Running RouteFinder Monitor ... 56 Test Connection ... 56 Terminate Connection ... 57 Save to File ...
  • Page 5 Appendix ... 103 Appendix A - Regulatory Compliance Information ... 104 Class B Statement FCC Part 15 ... 104 Appendix B - Tools for your RF102S ... 105 RouteFinder Monitor ... 105 PING ... 105 WINIPCFG and IPCONFIG ... 105 TRACERT ...

  • Page 6: Chapter 1 - Introduction

    Chapter 1 - Introduction...

  • Page 7: Introduction

    Chapter 1 - Introduction Introduction Congratulations on the purchase of the Multi-Tech System’s RouteFinder model RF102S, one of the finest broadband routers available today. The RouteFinder features two RS-232 WAN ports so you can connect as many as two external analog modems or ISDN terminal adapters and utilize ML-PPP to widen your bandwidth.

  • Page 8: Front Panel

    The four 10 BaseT/100 Base TX ports are used to connect the router to LAN client workstations. If the RF102S is set to use the Uplink feature, the number 1 LAN port is inactive as a LAN port. One port can be used for uplink.

  • Page 9: Typical Applications

    The following examples provide information about typical applications using the RF102S. They describe using the RF102S to connect a remote site to a local network and using the RF102S to connect a LAN to the Internet using one shared IP address.

  • Page 10: Connecting A Remote User To The Internet

    Connecting a Remote User to the Internet In this application, the RF102S is used to connect up to 253 Internal IP addresses to the Internet using a single shared external IP address. Kernal: NAT (outgoing TCP/IP connection sharing single External Port IP or using multiple IP Mapping) •...

  • Page 11: Specifications

    Specifications LAN Ports Number of Ports: 4 Interface: 10Base T/100BaseTX. One port can be used for uplink Standard: 802.3 WAN Ports Two RS-232 (V.24) DTE Speed: up to 460 Kbps asynchronous Protocols Security: PAP/CHAP, NAT Firewall, RADIUS, and Callback for remote access.

  • Page 12: Chapter 2 - Hardware Installation

    Chapter 2 - Hardware Installation...

  • Page 13: Hardware Installation

    The RF102S shipping box contains the following items: • System CD • Tucows CD • Power Supply • The RouteFinder RF102S • The RF102S RouteFinder Quick Start Guide If any of the items is missing or damaged, please contact Multi-Tech Systems. Chapter 2 - Hardware Installation...

  • Page 14: Cabling

    Software Installation and Configuration chapter. Cabling the RouteFinder RF102S 1. Before beginning, turn off the power for all network devices (PCs, analog modems, ISDN TAs) and disconnect the router power supply.

  • Page 15: Chapter 3 - Software Installation And Configuration

    Chapter 3 - Software Installation and Configuration...

  • Page 16: Software Installation And Configuration

    The RouteFinder Setup Wizard provides a step-by-step process to assist you in entering all the basic settings needed to configure your RF102S for general use. All settings that are entered in the Setup Wizard can be found in their respective menus in the RouteFinder Manager.

  • Page 17: Using Routefinder Setup Wizard

    Using RouteFinder Setup Wizard Note: Before beginning this procedure, verify that your RF102S is properly connected to the network and that the power is turned on. After installing the software, you can return to the RouteFinder Setup Wizard at any time by clicking Start | Programs | RouteFinder Manager | RouteFinder Wizard.
  • Page 18 Record the values presented in the Device Information panel for later reference. Device IP Address ______________________ Device Firmware Version _________________ Click Next. Note: If a message appears indicating the device is not found, or you do not see the device you are attempting to configure listed, click Refresh Device List.
  • Page 19 8. If the Remote Access option was selected for one or both ports, the Remote Access dialog box displays. Remote Access You must define the location of your remote user account database by selecting Use Local Client List or Use RADIUS Server. Follow the instructions for the user database that your system will use.
  • Page 20 Use RADIUS Server Select this option to authenticate your remote clients on a RADIUS server. Enter the following RADIUS Server Settings: • RADIUS Access Server IP Address: Enter the IP address of the RADIUS Access Server. • RADIUS Accounting Server IP Address: Enter the IP address of the RADIUS Accounting Server.
  • Page 21 10. The Setup Wizard: Modem Settings dialog box displays. The final step in configuring your RF102S for basic operations is to enter the model and DTE baudrate of the modem you are using. This is an important setting that determines the DTE baudrate or speed of communication between the RF102S’s ports and your modem or ISDN TA.
  • Page 22 Select your modem manufacturer and model and click OK. Note: This setting configures the initial string of the asynchronous port on the RF102S so that it will know how to communicate with your modem. If you are using an analog modem and your modem is not included in the selection list, in most cases, Standard Modem will work.

  • Page 23: Testing Your Connection

    1. Select Connect Port 2 to test serial port 2. The monitor activity will appear in the display window. Refer to Chapter 6 for additional information about the monitoring capabilities of the RF102S. 2. Before using the device, you must configure your workstations for TCP/IP. Refer to Chapter 7 for configuration information.

  • Page 24: Chapter 4 - Telnet

    Chapter 4 - Telnet...

  • Page 25: Using Telnet To Configure Your Routefinder

    Note: To successfully configure your router using Telnet, TCP/IP must be correctly configured on your computer. The router and computer must also be located on the same subnet. 1. Start your telnet session and connect to the RouteFinder RF102S using the router’s default IP address of 192.168.2.1 and vt100 terminal emulation.

  • Page 26: Router Ip Address

    Router Subnet Mask Enter the subnet mask for your local network. Router Name Enter a network name for the RF102S. If your ISP requires your device to have a name, you can use the one entered here. Router Password The default is no password. If you choose to use a password, ensure that you write the password down and keep it in a safe place.
  • Page 27 Chapter 4 - Telnet Serial Baudrate Use the list to select the appropriate baudrate of the modem attached to your async port. You may need to select a lower speed to ensure a quality connection. Modem Pre-Initial string Consult your modem or ISDN TA User Guide for this information. The default value will work for most analog modems.

  • Page 28: Virtual Server

    Router DNS IP Address DHCP Server Select Disable or Enable. If you would like the RF102S DHCP server function to provide IP information to workstations as they connect to the network, select Enable. When you enable DHCP, you will be prompted to provide the beginning and ending IP addresses in the range of addresses administered by your RouteFinder.

  • Page 29: Client Filter Settings

    The Filter Settings option allows you to define which packets are allowed to either pass through, or be blocked from passing through the RF102S ports. You can filter packets for network services including Mail, WWW, FTP, Telnet, and News functions. See the Filter Settings section of the RouteFinder Manager chapter for more information about filtering options.

  • Page 30: Chapter 5 - Routefinder Manager

    Chapter 5 - RouteFinder Manager...

  • Page 31: Routefinder Manager

    RouteFinder Manager RouteFinder Manager is the main program used to configure all the settings of your RF102S. 1. To run RouteFinder Manager, double-click the RouteFinder Manager icon on your desktop, or click Start | Programs | RouteFinder Manager | RouteFinder Manager.

  • Page 32: General Settings

    Access enables remote users to dial-in to the device to access and share network resources as if they were logged on to the network locally. 1. To configure the RF102S for IP Routing, click IP Routing in the Async Port section of the General Settings dialog box.
  • Page 33 3. The IP Routing Settings dialog box displays. IP Routing (NAT Enabled) If NAT is enabled, all local users will be firewall protected and will share one IP address through the Async port. Enter the information as described: Tel Number Enter the phone number required to access your ISP.
  • Page 34 •The RF102S makes the connection to the ISP server after receiving a regular telephone call. The remote user calls the RF102S async port to trigger the connection to the ISP server. c. Remote Callback - After dialing, the RF102S hangs up and waits for the remote site to Chapter 5 - RouteFinder Manager...
  • Page 35 (user name, password, callback status, and so on) is validated by checking the user information in this list. The RF102S can include up to 64 users in the Local Client list. Click Local Client List to add your remote users.
  • Page 36 Fixed Callback The RouteFinder will connect to the client by dialing the number specified in the Your TelNumber box. Variable Callback This option allows the remote client to specify the phone number the RouteFinder should callback each time a dial up connection is established. Assign a specific IP address for this user Select this option if you would like to have a specific IP address assigned to this user.

  • Page 37: Remote Access - Remote Access Settings

    If you are connecting to a Netware Server, IPX/SPX must be enabled. IPX/SPX Frame Type The RouteFinder RF102S can automatically detect what kind of IPX/SPX frame type you are using. You may manually select a frame type by using the list box.

  • Page 38: Enable Ip Mapping - Virtual Server

    Enable IP Mapping - Virtual Server IP Mapping is available only when NAT is enabled. If NAT is enabled for a particular port, that port is firewall protected. The Enable IP Mapping function allows you to open a “hole” in your firewall to allow access to your LAN via the Internet.

  • Page 39: Port Settings

    Port Settings The Modem Settings options are used to configure the communication between your modem or ISDN TA and your RouteFinder serial port. You must specify the baudrate, modem, and modem string settings for your device. 1. To view or change the port settings, from the main Manager dialog box, click Port Settings. The Port Settings dialog box displays.

  • Page 40: Edit Login Script For Remote Access

    Edit Login Script for Remote Access 1. To edit the login script for remote access, in the Port Settings dialog box, select the Enable Login Script check box. 2. The login Script dialog box displays. A sample remote access login script is shown below. If a remote access client is configured to “bring up a terminal window after dialing”, this remote access login script initiates.
  • Page 41 Wait 5 The Modem will wait for 5 seconds before moving the next line in the login script. Wait ‘CONNECT’ The Modem will wait for CONNECT to display before moving to the next command. Wait ‘CONNECT 6’ Modem will wait for “CONNECT” to display before moving to the next command.

  • Page 42: Modem String Settings

    Hangup Send ‘AT S0=1’ Send ‘ATDT 8885678’ Dials phone number 888-5678 (ISP #2) Wait ‘Connect’ 23 Wait ‘username:’ 23 Send ‘Stephen’ Wait ‘password:’ SH ‘5678’ Wait‘====>‘ Send‘1‘ Hangup Jump 2 Modem String Settings The most important modem string is the initialization string because your network device uses it to establish communications with your modem or ISDN TA.
  • Page 43 Chapter 5 - RouteFinder Manager Individual Port Options Individual Port Options lets you set the idle-timeout function for each serial port of the RouteFinder. You can set the number of minutes you want to allow a connection to stay idle before disconnection. The default idle timeout for IP Routing is 5 minutes.

  • Page 44: Lan Dhcp Server

    If you select the Use ML-PPP option, select one of the following: Bandwidth on Demand When traffic becomes heavy, this option looks for other routes to relieve the load, such as another connection to an ISP (without ML-PPP). Dial-up a new port after number of clients equals The network device dials a new port when the number of users exceeds the number entered.

  • Page 45: Routing Settings

    Routing Settings Routing is the process of moving a packet of data from source to destination. The RF102S acts as a router to enable messages to pass from one computer to another and eventually reach the target machine. Part of this process involves analyzing a routing table to determine the best path. Use the information below to create a routing table to connect your network to another network, or to connect subnets within your network.

  • Page 46: Routing Table

    Select the port (only local network) interface where the gateway is located. Routing Table The routing table stores the routing information so that the RF102S knows how to route the IP packets to the proper network. What is the purpose of the routing table? In the diagram above, the RF102S-1 has the routing information to route between 192.168.3.x...

  • Page 47: Filter Settings

    Filter Settings can be used to filter network services such as Mail, WWW, FTP, Telnet and News. 1. From the main Manager dialog box, select your RF102S, then Filter Settings. 2. The Filter Settings dialog box displays.
  • Page 48 80. At the same time, you set the same filter rule to block IP Address 192.168.100.72 with a privilege level of 1. The RF102S will implement the filter to block the IP address 192.168.100.72 because the privilege level is higher. If conflicting rules have the same privilege level, the RF102S blocks the packet.
  • Page 49 Starting from which byte number Enter the first byte in the packet the RF102S should read to determine if the byte pattern (in Hex) is one that should be filtered. Exclude the PPP header. Start from byte 0 of the network protocol.
  • Page 50 Enable Client Filter Settings The Client Filter allows you to decide which services are allowed into your network and which clients are authorized to access them. 1. From the Filter Settings dialog box, select Enable Client Filter Settings. Click Client Filter Settings. 3.

  • Page 51: Refresh Device List

    If the device still does not appear, ensure that all cables are correctly connected and that the RF102S is powered on. If the device still does not appear in the list, refer to the Troubleshooing chapter of this User Guide.

  • Page 52: Save Settings To File

    If you have completely forgotten your password, contact the Multi-Tech Technical Support group for assistance. Refer to Chapter 10 in this User Guide for more information about our Technical Support services.

  • Page 53: Load Settings

    6. Click OK to load and apply the settings to the RouteFinder. Upgrade Firmware Warning: Upgrade the firmware of your RouteFinder RF102S only under the advice and direction of the Multi-Tech Technical Support Group. Improperly upgrading the RF102S may disable the device! The Upgrade Firmware options allow you to upgrade your RF102S firmware.

  • Page 54: General Diagnostic

    General Diagnostic The General Diagnostic option on the main RouteFinder Manager dialog box displays network device information and allows you to determine if the RF102S is functioning properly. 1. From the main Manager dialog box, click General Diagnostic. 2. The General Diagnostic dialog box displays information about the RF102S.

  • Page 55: Chapter 6 - Routefinder Monitor

    Chapter 6 - RouteFinder Monitor...

  • Page 56: Routefinder Monitor

    RouteFinder Monitor RouteFinder Monitor is a utility that provides both monitoring and troubleshooting functions. Running RouteFinder Monitor 1. Double-click the RouteFinder Monitor icon, or select Start | Programs | RouteFinder Manager | RouteFinder Monitor. 2. The RouteFinder Monitor dialog box displays. Note: If you receive a message stating “Device is not found”, refer to the Troubleshooting chapter in this User Guide.

  • Page 57: Terminate Connection

    Terminate Connection The Terminate Connection option is designed to allow the Network Administrator to terminate an RF102S connection instantly. 1. From the main RouteFinder Monitor dialog box, select Terminate Connection. 2. The Terminate Connection dialog box displays. Select Disconnect Port 1 or Disconnect Port 2.

  • Page 58: Autosave

    Each computer listed must have a fixed IP address for your network. You may configure a fixed IP address on the individual computer or use the RF102S’s DHCP server IP reservation system (refer to the LAN DHCP section of RouteFinder Manager chapter of this User Guide).

  • Page 59: Event Messages

    Event Messages Event Messages are displayed in the lower half of the RouteFinder Monitor display. Event Messages provide information about the communication occurring between your network device, ISDN TA/modem and the remote server (ISP). To assist you in troubleshooting, you may point and click on any event message to bring up a help screen.

  • Page 60: Time Tab

    Displays the time/date that power was turned on to your RF102S . Power-On-Time Displays the total time that has elapsed since power was turned on to your RF102S . Total Connection Time Displays the total connection time for each port that has been logged on since power was turned on to your RF102S.

  • Page 61: Status Tab

    Status Tab The Status tab provides information about the status of the Serial ports. 1. From the RouteFinder Monitor dialog box, click the Status tab. 2. The Status tab information displays: WAN Ethernet This indicator light shows that either the IP Routing or the Remote Access function is in use. Async Port Modem Power: The indicator light is lit when the modem power is turned on.

  • Page 62: Statistics Tab

    Statistics Tab The Statistics tab indicates, by port, how many bytes of data have come in and out through the RouteFinder.. 1. From the RouteFinder Monitor dialog box, click the Statistics tab. 2. You can view the following information: IP Address The IP address of the network device.

  • Page 63: Chapter 7 - Lan Client Settings

    Chapter 7 - LAN Client Settings...

  • Page 64: Lan Client Settings

    Computers on your local LAN as well as computers dialing in to your network may use dynamic or static IP addresses. Dynamic IP addresses may be automatically assigned by the DHCP function of the RF102S or another DHCP server. Static IP addresses can either be reserved from the DHCP server or manually configured on the individual workstation.

  • Page 65: Adding The Dial-Up Adapter (Nt Server Connection)

    Chapter 7 - LAN Client Settings Adding the dial-up adapter (NT Server Connection): Windows 95/98: 1. Click Start | Settings | Control Panel. 2. Double-click the Network icon to open the Network dialog box. Win95 Win98 3. Click Add; the Select Network Component Type dialog box opens. 4.
  • Page 66 5. In the Manufacturers option box, select Microsoft. In the Network Adapters option box select Dial-up adapter. 6. Click OK (twice) to return to, and then close, the Network dialog box. Windows NT: Dial-up Networking adds PPP and SLIP protocol support, enabling your workstation to gain access to a remote computer or network, even if your computer is not on a network.

  • Page 67: Adding File And Print Sharing For Microsoft Networks (Nt Server Connection)

    Adding Client for Microsoft Networks (NT Server Connection): Windows 95/98: 1. In the Network dialog box, Configuration tab, click Add. 2. Select Network Client and click Add. 3. The Select Network Client dialog box displays. In the Manufacturer’s option box, select Microsoft.

  • Page 68: Set Your Primary Network Logon (Nt Server Connection)

    Set Your Primary Network Logon (NT Server Connection): Windows 95/98: In the Primary Network Logon option box on the Configuration tab of the Network dialog box, select (the previously installed) Client for Microsoft Networks. Click OK to close the Network dialog box. Set up Properties of Components (NT Server Connection): Dial-up Adapter: Windows 95/98:...
  • Page 69 Network Client: Windows 95/98: In the Network dialog box, Configuration tab, select Client for Microsoft Networks. Click Properties. The Client for Microsoft Networks Properties dialog box opens. On the General tab, select (check) Log on to Windows NT domain. 4. Enter the name of your Windows NT domain, as provided by your Network Administrator the Windows NT domain box.

  • Page 70: Make Your New Connection (Nt Server Connection)

    Access: Windows 95/98: 1. In the Network dialog box, click the Access Control tab. 2. In the Control Access to Shared resources using group, select Share-Level access control. Click OK (twice) to return to, and then close, the Network dialog box. Note: You must restart your system for the new settings to take effect.

  • Page 71: Dial In To Your Network (Nt Server Connection)

    3. Enter the user name (if necessary) and password configured for you on the RF102S. Note: If your particular situation permits, select Save password. 4. Click Connect. 5. After connecting to the RF102S, you can access the same services and resources as if you were connected to the network locally. Accessing a Novell Server Novell NetWare products are used on up to 70 percent of PC-based local area networks (LANs).
  • Page 72 4. Select Adapter, then click Add. The Select Network adapters dialog box opens. 5. In the Manufacturers option box, select Microsoft. In the Network Adapters option box select Dial-up adapter. 6. Click OK twice to return to and close the Network dialog box. Windows NT: Dial-up Networking adds PPP and SLIP protocol support, enabling your workstation to gain access to a remote computer or network, even if your computer is not on a network.
  • Page 73 Adding IPX/SPX (Novell Server Connection): Windows 95/98: 1. In the Network dialog box, Configuration tab, click Add. The Select Network Component Type dialog box opens. 2. Select Protocol and click Add. The Select Network Protocol dialog box opens. 3. In the Manufacturers option box, select Microsoft. In the Network Protocols option box, select IPX/SPX-compatible Protocol.

  • Page 74: Set Up Properties Of Components (Novell Server Connection)

    Chapter 7 - LAN Client Settings Set Up Properties of Components (Novell Server Connection): Network Client: Windows 95/98: 1. In the Network dialog box, Configuration tab, select Client for Microsoft Networks. 2. Click Properties. The Client for Microsoft Networks Properties dialog box opens. 3.

  • Page 75: Make Your New Connection (Novell Server Connection)

    8. On the General tab, in the Preferred server field, enter the name of your Novell Server Domain. If necessary, select the First Network Drive, then ensure that Enable logon script processing is checked (enabled). (It’s the default.) 9. Click OK to return to the Network dialog box. Set Your Primary Network Logon: Windows 95/98: 1.

  • Page 76: Set Dial-Up Type (Novell Server Connection)

    Note: If your particular situation permits, select Save password. 4. Click Connect. 5. After connecting to the RF102S, you can access the same services and resources as if you were connected to the network locally. Accessing a Windows NT Server and a Novell NetWare Server Note: Before configuring your remote site, ensure TCP/IP has been installed on your NT Server.
  • Page 77 Win95 3. Click Add. The Select Network Component Type dialog box opens. 4. Select Adapter, then click Add. The Select Network adapters dialog box opens. Win95/98 5. (Win95/98 only) In the Manufacturers option box, select Microsoft. In the Network Adapters option box select Dial-up adapter.

  • Page 78: Adding File And Print Sharing For Microsoft Networks (Novell/Nt Server Connection)

    Adding TCP/IP (Novell/NT Server Connection): Windows 95/98/NT: 1. In the Network dialog box, Configuration tab, click Add. 2. Select Protocol and click Add. 3. The Select Network Protocol dialog box is displayed. In the Manufacturers option box [Win95 only], select Microsoft. In the Network Protocols option box, select TCP/IP [Win95/98] or TCP/ IP Protocol [WinNT only].
  • Page 79 3. The Select Network Service dialog box displays. In the Manufacturers option box, select Microsoft. Select File and Printer sharing for Microsoft Networks. Note: Windows 98 has no Manufacturers option box. Win95 Click OK twice to return to and close the Network dialog box. Adding IPX/SPX (Novell/NT Server Connection): Windows 95/98: 1.
  • Page 80 Adding Client for NetWare Networks (Novell/NT Server Connection): Windows 95/98: 1. In the Network dialog box, Configuration tab, click Add. 2. Select Network Client and click Add. 3. The Select Network Client dialog box displays. In the Manufacturer’s option box, select Microsoft.
  • Page 81 Set Up Properties of Components (Novell/NT Server Connection): Dial-up Adapter: Windows 95/98: 1. In the Network dialog box, Configuration tab, select the TCP/IP-Dial-up adapter option. 2. Click Properties. The TCP/IP Properties dialog box opens with the IP Address tab selected. 3.
  • Page 82 8. On the General tab, in the Preferred server box, enter the name of your Novell Server Domain. Select the First Network Drive and Enable Logon Script processing. 9. Click OK. Network Protocol: Windows 95/98: 1. In the Network dialog box, Configuration tab, select IPX/SPX Compatible Protocol. 2.

  • Page 83: Set Dial-Up Type (Nt/Novell Server Connection)

    Set Your Access Control: Windows 95/98: 1. In the Network dialog box, click the Access Control tab. 2. In the Control Access to Shared resources using group, select Share-Level access control. 3. Click OK twice to return to and close the Network dialog box. Note: You must restart your system for the new settings to take effect.

  • Page 84: Dial In To Your Network (Nt/Novell Server Connection)

    3. Enter the user name (if necessary) and password configured for you on the RF102S. Note: If your particular situation permits, select Save password. 4. Click Connect. 5. After connecting to the RF102S, you can access the same services and resources as if you were connected to the network locally. Accessing a Unix Server Perform the following procedures to prepare your PC workstation to access a remote Unix Server.
  • Page 85 3. Click Add. The Select Network Component Type dialog box opens. 4. Select Adapter, then click Add. The Select Network adapters dialog box opens. 5. In the Manufacturers list, select Microsoft. In the Network Adapters list, select Dial-up adapter. 6. Click OK twice to return to and close the Network dialog box. Windows NT: Dial-up Networking adds PPP and SLIP protocol support, enabling your workstation to gain access to a remote computer or network, even if your computer is not on a network.

  • Page 86: Set Up Properties Of Components (Unix Server Connection)

    Adding TCP/IP (Unix Server Connection): Windows 95/98/NT: 1. In the Network dialog box, Configuration tab, click Add. 2. Select Protocol and click Add. 3. The Select Network Protocol dialog box is displayed. In the Manufacturers option box [Win95 only], select Microsoft. In the Network Protocols option box, select TCP/IP [Win95/98] or TCP/ IP Protocol [WinNT only].

  • Page 87: Make Your New Connection (Unix Server Connection)

    Note: If your particular situation permits, select the Save password check box. 4. Click Connect. 5. After connecting to the RF102S, you can access the same services and resources as if you were connected to the network locally. Chapter 7 - LAN Client Settings...

  • Page 88: Make New Connection (Windows 2000 Only)

    Chapter 7 - LAN Client Settings Make New Connection (Windows 2000 only) Perform the following procedures to prepare your Windows 2000 PC workstation to access any of the remote servers and enable applications such as e-mail, Web browsing, file sharing, and printing. 1.

  • Page 89: Chapter 8 - Lan-To-Lan Settings

    Chapter 8 - LAN-to-LAN Settings...

  • Page 90: Lan -To- Lan Settings

    LAN -to- LAN Settings Setting up LAN -to- LAN Routing The majority of settings for LAN -to- LAN Routing are set up through RouteFinder Wizard or RouteFinder Manager when IP routing (NAT disabled) is configured. This section provides an overview of LAN -to- LAN Routing and shows you some of the benefits and limitations of LAN -to- LAN Routing.

  • Page 91: Using The Find Computer Command

    Chapter 8 - LAN -to- LAN Settings Using the Find Computer command If your clients are in different subnets or separated by a router, you will not be able to use the Find Computer function within Windows by selecting Start | Find | Computer. In the Find Computer dialog box, type the IP address of the computer you would like to find in the Named field.

  • Page 92: Chapter 9 - Troubleshooting

    Chapter 9 - Troubleshooting...

  • Page 93: Troubleshooting

    This chapter provides a list of common problems encountered while installing, configuring or administering the RF102S. In the event you are unable to resolve your problem, refer to the Service, Warranty and Technical Support chapter of this User Guide for information about contacting our Technical Support representatives.
  • Page 94 The most common reason for this is not due to a problem or error. If you are the first person to make a connection to the Internet through the RF102S, there will be a delay when the Dial-On- Demand function automatically makes the connection and logs on to your ISP. Subsequent users will be able to use the connection you have established without a delay.
  • Page 95 Internet. • The RF102S will only dial the connection if there is a request from one of the computers on the LAN for an IP address on the Internet. Keep in mind that certain applications can be configured to request information from the Internet.

  • Page 96: Chapter 10 - Service, Warranty And Technical Support

    Chapter 10 - Service, Warranty and Technical Support...

  • Page 97: Introduction

    RouteFinder. Limited Warranty Multi-Tech Systems, Inc., (hereafter “MTS”) warrants that the RouteFinder will be free from defects in material or workmanship for a period of two years from date of purchase, or if proof of purchase is not provided, two years from date of shipment.

  • Page 98: Addendum For International Products

    Repair Accounting department at +(763) 785-3500 in the U.S.A., or a nearby Multi-Tech office which is listed on the “Multi-Tech Corporate Offices” sheet in this International Distributor Resource Kit.

  • Page 99: Software User License Agreement

    SINGLE-USER SOFTWARE LICENSE AGREEMENT This copy of Multi-Tech software is provided only on the condition that you, Customer, agree to the following license. READ THIS LICENSE CAREFULLY. If you do not agree to the terms contained in this license, return the packaged program UNOPENED to the place you obtained it.
  • Page 100 Chapter 10 - Service, Warranty and Technical Support...

  • Page 101: Technical Support

    __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ On-line Warranty Registration If you have access to the World Wide Web, you can register your Multi-Tech product online at the following URL: http://www.multitech.com/register About the Internet Multi-Tech System’s is a commercial provider on the Internet. The Multi-Tech Web site is located at http://www.multitech.com The Multi-Tech FTP site is located at ftp://ftp.multitech.com...

  • Page 102: Ordering Accessories

    Ordering Accessories SupplyNet, Inc. can provide you with replacement transformers, cables and connectors for select Multi-Tech products. You can place an order with SupplyNet via mail, phone, fax or the Internet at: Mail: SupplyNet, Inc. 614 Corporate Way Valley Cottage, NY 10989...

  • Page 103: Appendix

    Appendix...

  • Page 104: Appendix A - Regulatory Compliance Information

    Cet appareil numerique de la classe B respecte toutes les exigences du Reglement Canadien sur le materiel brouilleur. The CE mark is affixed to this Multi-Tech product to confirm compliance with the following European Community Directives: Council Directive 89/336/EEC of 3 May 1989 on the approximation of the laws of Member States relating to electromagnetic compatibility.

  • Page 105: Appendix B - Tools For Your Rf102S

    WINIPCFG (for Windows 95/98) 1. Select Start | Run and type winipcfg. 2. The IP address, default gateway (the RF102S IP address), and the adapter address display. IPCONFIG (for Window NT/2000) 1. From a DOS Prompt, type IPCONFIG and press Enter.

  • Page 106: Tracert

    TRACERT TRACERT is an extensive PING utility that allows you to trace the route of an IP address. The utility reports the number of router hops, the time for each hop, and any failed attempts to cross a hop. The information provided by this utility assists you to locate the specific site of a failed PING.
  • Page 107 Appendix...

  • Page 108: Glossary

    Glossary...
  • Page 109 Your RouteFinder supports flash ROM which means you can upgrade the fimware in your network device very easily by downloading a copy of the new firmware from the Multi-Tech web site and using the RouteFinder Manager Upgrade Firmware function.
  • Page 110 A static IP address is a permanent IP address that is set up on each individual computer. When your RouteFinder dials-up your ISP, your ISP can give it a fixed or dynamic IP address. Likewise when you power on your computer, the RF102S can give your computer a dynamic or fixed IP address.
  • Page 111 Glossary If someone on the Internet tries to access your network, the firewall function of the RouteFinder stops the request. The device will not reverse translate network addresses unless you have specifically allowed this feature using the Virtual Server function (IP Mapping). NetworkAddress The network portion of an IP address.
  • Page 112 Chapter 5 - RouteFinder Manager transmit and route data packets. The format of an IP address is a 32-bit numeric address written as four octets separated by periods. Each number can be zero to 255. Within an isolated network, you can assign IP addresses at random as long as each one is unique.

  • Page 113: Index

    Index Adding TCP/IP ... 66, 86 ASYNC ... 8 Authentication ... 35 Available Devices ... 31, 56 Back Panel ... 8 Baudrate ... 39 Cabling ... 14 Callback Settings ... 34 Callback Type ... 35 Configuration ... 16 Connection ... 11 Device IP Address ...
  • Page 114 Index Refresh Device List ... 31, 51, 56 Registering your product ... 101 Regulatory Compliance ... 104 Remote Access ... 37 Reset ... 8 RouteFinder Manager ... 31 RouteFinder Monitor ... 56 routing ... 90 Routing Settings ... 45 Routing Table ... 46 Rx ...

Table of Contents
