VGBA
2017
Read and follow all instructions in this owner's manual and on the equipment. Failure to follow instructions can cause
severe injury and/or death.
SOFA INSTRUCTIONS
When installing and using this equipment, basic safety precautions shall always be followed, including the following: IMPORTANT
SAFETY INSTRUCTIONS. READ, FOLLOW, AND UNDERSTAND ALL INSTRUCTIONS AND WARNINGS.
Any modification that increases the flow rate of the circulation system shall require re-evaluation of the cover/grate and sump to
ensure that the flow rating of the Suction Outlet Fitting Assembly (SOFA) is not exceeded.
Missing, broken, or cracked cover/grates, sumps, mud-frames, or any other SOFA component shall be replaced before bathers are
allowed to use the pool.
Loose cover/grates shall be reattached before bathers are allowed to use the pool.
SAVE THESE INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
WARNING - SUCTION ENTRAPMENT HAZARD
Suction in suction outlets and/or suction outlet
covers which are damaged, broken, cracked,
missing, or unsecured can cause severe injury and/
or death due to the following entrapment hazards:
Hair Entrapment: Hair can become entangled in suction outlet cover.
Limb Entrapment: A limb inserted into an opening of a suction outlet
sump or suction outlet cover that is damaged, broken, cracked, missing,
or not securely attached can result in a mechanical bind or swelling of
the limb.
Designed,
Engineered &
Manufactured
in the USA.
©2022 Waterway Plastics
MAIN DRAIN OWNER'S MANUAL
Model Number: 640-18xx V 8" Tru Flo
WARNING:
IMPORTANT SAFETY INSTRUCTIONS. READ, UNDERSTAND, AND FOLLOW ALL WARNINGS
AND INSTRUCTIONS. SAVE THESE INSTRUCTIONS.
USE ONLY GENUINE WATERWAY REPLACEMENT PARTS.
2200 East Sturgis Road, Oxnard CA 93030 • Phone 805.981.0262 • Fax 805.981.9403
www.waterwayplastics.com • waterway@waterwayplastics.com
Body Suction Entrapment: A negative pressure applied to a large
portion of the body or limbs can result in an entrapment.
Evisceration / Disembowelment Entrapment: A negative pressure
applied directly to the intestines through an unprotected suction
outlet sump or suction outlet cover which is damaged, broken, cracked,
missing, or unsecured can result in evisceration / disembowelment
entrapment.
Mechanical Entrapment: There is potential for jewelry, swimsuit,
hair decorations, finger, toe, or knuckle to be caught in an opening of a
suction outlet cover resulting in mechanical entrapment.
810-1800.0522

Advertisement

loading
Need help?

Need help?

Do you have a question about the 640-18 V Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Waterway 640-18 V Series

  • Page 1 USE ONLY GENUINE WATERWAY REPLACEMENT PARTS. Designed, Engineered & Manufactured in the USA.
  • Page 2 • Do not exceed the safe flow rating of SOFAs as listed. • All SOFAs should be installed in accordance with Waterway installation instructions. • No modification shall be made to SOFA structure or flow path unless new configuration has been certified as a new SOFA.
  • Page 3 Do not exceed the safe flow rate. Do not increase flow through system by increasing pump size or horsepower. Do not allow children to sit, play or interact with main drains or suction outlet. ©2022 Waterway Plastics 810-1800.0522...
  • Page 4 819-00801 642-240X V 642-2140 640-1800 V 819-00801 642-240X V ITEM SG642-2140 SG640-1800 V ©2022 Waterway Plastics 810-1800.0522...
  • Page 5 INSTRUCTIONS FOR CONCRETE MAIN DRAINS SUMP (DUAL PORT) 819-00801 642-2400 V 715-1230 672-2410 GRATED ANTI-VORTEX CONCRETE ASSEMBLY 1. Align cover holes with brass inserts. 2. Hand-tighten supplied screws. DO NOT USE POWER TOOLS. 3. A minimum 2" connecting pipe should be used. ©2022 Waterway Plastics 810-1800.0522...
  • Page 6 COLLAR SUMP (DUAL PORT) 819-00801 642-240X V 642-2240 715-9910 672-2550 GRATED ANTI-VORTEX CONCRETE ASSEMBLY 1. Align cover holes with brass inserts. 2. Hand-tighten supplied screws. DO NOT USE POWER TOOLS. 3. A minimum 2" connecting pipe should be used. ©2022 Waterway Plastics 810-1800.0522...
  • Page 7 4. Install all eight screws. (If this is your first time, ask where purchased this drain exactly how to do it with the pool you brought.) 5. Align cover holes with brass inserts and install screws. 806-3000 711-2600 715-9910 672-2520 ©2022 Waterway Plastics 810-1800.0522...
  • Page 8 642-2400 V 715-9930 672-2610 ITEM QTY. PA GRATED ANTI-VORTEX CONCRETE ASSEMBLY 1. Align cover holes with brass inserts. 2. Hand-tighten supplied screws. DO NOT USE POWER TOOLS. 3. A minimum 2" connecting pipe should be used. ©2022 Waterway Plastics 810-1800.0522...
  • Page 9 VENDOR Material 642-2240 819-00801 642-240x V 642-2240 715-9930 672-2650 CONCRETE ASSEMBLY 1. Align cover holes with brass inserts. 2. Hand-tighten supplied screws. DO NOT USE POWER TOOLS. 3. A minimum 2" connecting pipe should be used. ©2022 Waterway Plastics 810-1800.0522...
  • Page 10 4. Install all eight screws. (If this is your first time, ask where you purchased this drain exactly how to do it with the pool you bought.) 5. Align cover holes with brass inserts and install screws. ©2022 Waterway Plastics 810-1800.0522...
  • Page 11 8" TRU-FLOW Head Loss Curve -0.5 Flow Rate (GPM) WARRANTY For product registration visit: www.waterwayplastics.com. For Warranty questions or claims please contact point of purchase. ©2022 Waterway Plastics 810-1800.0522...
  • Page 12 FINISH SURFACE OF THE POOL FINISH SURFACE OF THE POOL 3.5" 4" FLOW PATH 7.5" 8" FLOW PATH 8" FLOW PATH 2.5" PIPE 2.5" SOC PLASTER 2.5" PIPE POOL STRUCTURE SECTION A-A 2.5" SOC SECTION A-A ©2022 Waterway Plastics 810-1800.0522...
