Multitech MT128STZLX Documentation Update

Multi-tech multimobile mt128stzlx modems: supplementary guide
Hide thumbs Also See for MT128STZLX:
Table of Contents

Advertisement

Quick Links

Download this manual
Product Update
ISDN CAPI 2.0
March 27, 1998
PN 82081400
MT128STZLX
Update–ISDN CAPI
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT128STZLX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Multitech MT128STZLX

Summary of Contents for Multitech MT128STZLX

  • Page 1 Product Update ISDN CAPI 2.0 March 27, 1998 PN 82081400 MT128STZLX Update–ISDN CAPI...

  • Page 2: Table Of Contents

    1. Introduction ... 1 2. Preparation ... 2 3. RVS-COM Lite Installation ... 3 4. Applications ... 6 4.1 Using PPP Protocol to Connect to ISPs ... 6 4.2 Using Multi-Link PPP to Connect to ISPs ... 7 4.3 Making X.75 Connections ... 8 4.4 EuroFile Transfer Applications ...

  • Page 3: Introduction

    This update explains how to make the ISDN TA PC Card (with DSS1 D-channel protocol) work with RVS-COM Lite for Windows 95/NT, which supports CAPI 2.0, X.75, and other popular applications in most western European countries. After RVS-COM Lite is installed, you can find RVS- COM application details in Online Documentation.

  • Page 4: Preparation

    Preparation NOTE: The ISDN modem is not an emulation of an analog modem (i.e., it does not transmit tones). Consequently, you cannot use it to set up a con- nection to non-ISDN mailboxes, nor can you test it with tools designed for analog modems. 5.

  • Page 5: Rvs-Com Lite Installation

    ISDN TA CAPI driver disk. Enter the correct driver path, e.g., A:\. Click OK. 3. Follow the instructions that appear on the Windows 95 screen to install all VCOMM and NDIS drivers. The default current active API will be set to CAPI. To change the setting to CAPI Mode: 1.
  • Page 6 RVS-COM Lite Installation ISDN CAPI Adapter Configuration 1. The RVS-COM Installation: ISDN Adapter window appears. Click Next. The ISDN Protocols and Services window appears. Click Next. 2. The ISDN Softfax window appears. Select the following: Use Softfax to send fax Use Softfax to receive fax Softfax should also receive at 14400 bps Click Next.
  • Page 7 6. The Phone Number for External Calls window appears. Enter your ISDN phone number. Then click Next. NOTE: Some switches need this phone number as the calling party number during ISDN connection setup 7. The File Transfer Host window appears. Enter phone numbers for your applications.

  • Page 8: Applications

    Applications allow remote callers to log into specified folders and access data. 3. Specify the file folder path that requires ID and password for caller access. 4. Specify the file folder path that allows caller access without ID and password 5.

  • Page 9: Using Multi-Link Ppp To Connect To Isps

    Dial-Up Server box. 5. Click the appropriate Advanced Options and select, at least, TCP/IP in Network Protocols for your Internet application 6. Click the TCP/IP Settings button and specify the other TCP/IP parameters, such as IP address and DNS address, if necessary. Now you are ready to connect to your ISP via PPP protocol.

  • Page 10: Making X.75 Connections

    Applications Select the modem RVS ISDN Internet PPP. Click Next. 9. Enter the phone number for the computer you want to dial. Click Next. Click Finish to return to the Dial-Up Networking window. 10. With the right mouse button, click the icon RVS_2.

  • Page 11: Eurofile Transfer Applications

    Click Properties. Make sure the COM port is assigned correctly and no conflict exists. For example, RVS Port (COM6). Click OK, then close the window. 3. Run Windows 95 Hypertrm. Set ATS0=1 <Enter> by using the AT command to make the ISDN TA PC Card to automatically answer the incoming X.75 calls.
  • Page 12 Applications check box is checked. Click Properties. In the Port tab, make sure your ISDN phone/ MSN number for outgoing calls is correct. 3. Click the Windows Port tab. Make sure COM port is assigned and enabled. 4. Click the Autoanswer tab. Make sure Answer calls automatically and Eurofile Transfer check boxes are checked.

  • Page 13: G3 Faxing Applications

    5. Click Properties. Enter the optimized block size for the file transfer (try 2048), your ISDN phone number, and MSN for outgoing calls. Click Apply, then OK twice to return to the Connect To window. 6. Click Connect to establish connection. 4.5 G3 Faxing Applications To use RVS-COM to send/receive G3 faxes, the following components need to be installed:...

  • Page 14: Voice Applications

    Applications Sending 1. Select Start è Programs è RVS-COM Lite è Create new fax. The Microsoft Mail window opens. Click OK. 2. Enter the name and fax number of the remote party that wants to connect. Click Next. 3. Enter the subject and text of the fax message you want to send.
  • Page 15 3. Open the Port tab. Make sure your ISDN phone/MSN number for outgoing calls is correct. 4. Open the Windows Port tab. Make sure the COM port is assigned and enabled. For example, COM6. 5. Open the Autoanswer tab. Make sure the Answer calls automatically and Voice boxes are checked.
  • Page 16 Applications To change the Greeting or End message, click the appropriate Edit button to open the Recorder utility. Then start recording. You can also use the Recorder utility to play and check recorded greeting/end messages. Or, you can import the prerecorded WAV format voice file as your greeting/end message.
  • Page 17 voice services 6. Click Properties, then open the Answer call tab. Enter the number of rings before answering. Click OK. 7. Open the ISDN tab. Select the appropriate ISDN voice coding scheme for your area. A-law is commonly used in European countries.
