- Page 1 MITSUBISHI ELECTRIC DT1151 Installation Manual English MA00856B 2009-01...
- Page 2 DT1151 Installation Manual Foreword The DT1151 industrial monitor is a TFT-LCD touch screen monitor, designed to be mounted in a cabinet and connected to an industrial PC. The monitor is optimized for a maximum resolution of 1024 x 768 pixels when the full display area of the module is used.
-
Page 3: Table Of Contents
Operation Messages ..............15 Video Input Timing..............15 Audio Support ................15 Calibrate the Touch Screen ............16 4 Chemical Resistance ................17 Metal Casing................17 Touch Screen and Overlay ............18 5 Drawings ....................21 DT1151 Outline ............... 21 Mitsubishi Electric, MA00856B... - Page 4 Contents Mitsubishi Electric, MA00856B...
-
Page 5: Safety Precautions
– The supplier neither guarantees that the monitor is suitable for your particu- lar application, nor assumes responsibility for your product design, installa- tion or operation. Mitsubishi Electric, MA00856B... -
Page 6: During Use
– Clean the display and surrounding front cover with a soft cloth and mild de- tergent. Dismantling and Scrapping – The monitor or parts thereof shall be recycled according to local regulations. – The following components contain substances that might be hazardous to health and the environment: electrolytic capacitor and display. Mitsubishi Electric, MA00856B... -
Page 7: Installation
Installation Installation Space Requirements Installation plate thickness: 1.5 - 9.0 mm (0.06 - 0.35 inch) Space requirements when installing DT1151: 50 mm (2.0 inch) 304 mm (11.97 inch) 45 mm (1.77 inch) 25 mm 25 mm (1.0 inch) (1.0 inch) 50 mm (2.0 inch) - Page 8 2. Place the panel cut out where the monitor is to be situated, draw along the outer sides of the holes and cut according to the markings. 3. Secure the monitor in position, using all the fastening holes and the pro- vided brackets and screws: x 14 0.5 - 1.0 Nm Mitsubishi Electric, MA00856B...
- Page 9 If condensation forms, ensure that the monitor is dry be- fore connecting it to the power outlet. 5. Carefully remove the laminated film over the monitor display, to avoid static electricity that could damage the monitor. Mitsubishi Electric, MA00856B...
- Page 10 Installation Mitsubishi Electric, MA00856B...
-
Page 11: Technical Data
-20 ° to +70 °C Relative humidity 5 - 85% non-condensed The monitor conforms with the essential protection requirements of the directive 2004/108/EC. Noise tested according to EN61000-6-3 emission and EN61000-6-2 immunity. * See section 4 Chemical Resistance Mitsubishi Electric, MA00856B... -
Page 12: The On Screen Display Menu
Opens the OSD menu and works as Select and Deselect button. Down Arrow Return or Exit in the OSD menu. Automatic display configuration Decrease/left key Brightness decrease Increase/right key Brightness increase VGA/DVI Source select (VGA or DVI) Power Turns on/off the monitor. Mitsubishi Electric, MA00856B... - Page 13 Color Temperature User: Red, green and blue colors can be adjusted Warm: Red-tinged screen Normal: Green-tinged screen Cool: Blue-tinged screen Auto Color Color automatically set from strange input signal (A-RGB only) Exit Go back to main menu Mitsubishi Electric, MA00856B...
- Page 14 Reset Reset to initial setup (factory settings) Reset Color Initial color Reset Position Initial position Mute Set sound on or off (Audio Option) Volume Adjust the volume of sound (Audio Option) Exit Go back to main menu Mitsubishi Electric, MA00856B...
-
Page 15: Operation Messages
OSD interface or the OSD buttons on the rear side. The monitor is equipped with one audio input port and one speaker out port. Parameter Specification 2 x 2W @ 8 Ω Maximum output Note: The industrial monitor does not include built-in speakers. Mitsubishi Electric, MA00856B... -
Page 16: Calibrate The Touch Screen
The industrial monitor has a built in touch screen. This is not operational when shipped from the supplier and must be installed. Instructions and drivers for in- stallation of the touch screen function are available at: www.mitsubishi-automation.com www.meau.com Mitsubishi Electric, MA00856B... -
Page 17: Chemical Resistance
The powder paint shows little or no resistance to the following chemicals at room temperature: Acetic acid, conc. Methyl-ethyl ketone Toluene Acetone Nitric acid 30% Trichlorethylene Ammonia 5% Phenol Xylene Ammonia, conc. Sodium hydroxide 5% 97 octan unleaded petrol Ethyl acetate Sodium hydroxide 30% 98 octan leaded petrol Mitsubishi Electric, MA00856B... -
Page 18: Touch Screen And Overlay
Autotex is not resistant to high pressure steam at over 100 °C or the following chemicals: Concentrated mineral acids Benzyl alcohol Concentrated caustic solution Methylene chloride Outdoor Use In common with all polyester based films Autotex F157/F207 is not suitable for use in conditions of long term exposure to direct sunlight. Mitsubishi Electric, MA00856B... - Page 19 Autoflex EB withstands exposure to the same chemicals as Autotex F157 or F207 according to section Autotex F157/F207. Outdoor Use In common with all polyester based films Autoflex EB is not suitable for use in conditions of long term exposure to direct sunlight. Mitsubishi Electric, MA00856B...
- Page 20 Chemical Resistance Mitsubishi Electric, MA00856B...
-
Page 21: Drawings
Drawings Drawings DT1151 Outline Mitsubishi Electric, MA00856B... - Page 22 MITSUBISHI ELECTRIC Mitsubishi Electric Automation, Inc. 500 Corporate Woods Parkway Vernon Hills, IL 60061, USA Mitsubishi Electric Europe B.V. Gothaer Strasse 8 D-40880 Ratingen, Germany...
