AFTER CARE
To maintain the appearance of this tap, ensure that it is regularly cleaned only using a clean,
soft damp cloth. A solution of warm water and a mild liquid detergent may be used where
necessary, and then the fitting rinsed thoroughly and wiped dry. Abrasive cleaners, scouring
cleaners and acid cleaners must not be used under any circumstances. All bath cleaning
powders and liquids will damage the surface of your fitting even the non-scratch cleaners.
Avoid contact with all solvents and any harsh household chemicals. You will damage the
finish and void your guarantee.
GUARANTEE AND LIABILITY
In the unlikely event that you should experience any defect in the material or workmanship of
your mixer tap within 5 years of purchase, we will replace the faulty part free of charge.
Decorative surface finishes are guaranteed for one year from the date of purchase provided that
our advise concerning care has been observed and no scouring agents have been used. This is
provided that the mixer or tap has been used for normal domestic purposes in the UK and that
the care, installation and maintenance instructions have been observed.
Scuff and scratches caused by normal wear and tear, improper installation or accidental
damage are excluded from this guarantee.
You should retain a copy of your dated invoice as proof of purchase to validate any claims
under this guarantee.
No other warranties, express or implied, are made, including merchantability or fitness for a
particular purpose.
Azia
T h e c l e a r c h o i c e
T h e c l e a r c h o i c e
Please Keep Me Safe
167
Fitting Instructions and Parts List
Please read these instructions before you install and use the tap, be sure to
keep them safe for future reference and to request replacement parts.
All designs, descriptions and dimensions are subject to change without notice.
Spare Parts and Service
Contact: Sterling
Phone: 01684 299555
Fax: 01684 290958
Email: sales@sterling.eu.com
Website: www.sterling.eu.com
Azia
167
Fitting Instructions and Parts List
Please read these instructions before you install and use the tap, be sure to
keep them safe for future reference and to request replacement parts.
All designs, descriptions and dimensions are subject to change without notice.
T h e c l e a r c h o i c e
T h e c l e a r c h o i c e

Advertisement

loading
Need help?

Need help?

Do you have a question about the ClearWater Azia and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sterling ClearWater Azia

  • Page 1 Please read these instructions before you install and use the tap, be sure to keep them safe for future reference and to request replacement parts. All designs, descriptions and dimensions are subject to change without notice. Spare Parts and Service Contact: Sterling Fitting Instructions and Parts List Phone: 01684 299555 Fax: 01684 290958 Please read these instructions before you install and use the tap, be sure to Email: sales@sterling.eu.com...
  • Page 2 REMEMBER Azia AZL10 Maximum water supply pressure 5 bar (75PSI) Minimum water supply pressure 1 bar Ster0101CP Maximum hot water supply temperature 70˚C /BN/BB/MB Recommended hot water supply temperature 65˚C Ster0122 If these temperatures or water pressure are exceeded, damage to the tap can result. A pressure reducing valve may be required to be fitted in high water pressure situations.
  • Page 3 Figure 1 Figure 2 Install the Tap(Figure 1, 2) Pass all the tails individually through the tap hole. If needed, remove the hot and cold tails, then re-attach from below (hand tight only). Slide the flat washer and fixing nut up the flexible hoses as pictured. Then screw the nut all the way up, making sure the tap is in the correct position before tightening the lock screws.
  • Page 4 USE GUIDE TROUBLESHOOTING Symptoms Probable Causes Recommended Action ON/ OFF and Temperature Control Dirty sensor window Wipe sensor window with soft fabric Drops of water accumulate Gently wipe off drops of water on the sensor window Continuous water flow Sensor function is activated Contact customer service far beyond 10cm Contact customer service...
