Samlexpower Evolution Series Quick Start Manual
Inverter/charger pure sine wave
Hide thumbs
Also See for Evolution Series:
- Owner's manual (92 pages) ,
- Owner's manual (132 pages) ,
- Quick start manual (12 pages)
Related Manuals for Samlexpower Evolution Series
Summary of Contents for Samlexpower Evolution Series
- Page 1 Evolution Series Quick Start Guide Inverter/Charger Pure Sine Wave Models: EVO-2212E EVO-3012E EVO-2224E Firmware: EVO-XXXX: Rev 0.80 EVO-4024E EVO-RC: Rev 029 For use with 230 VAC Models...
-
Page 2: What's In The Box
INVERTER/CHARGER | Quick Start Guide Thank you for purchasing the Samlex Evolution (EVO ) Series Inverter Charger. We know you will enjoy many years of great service from this quality state-of-the-art product. Samlex Customer Service and Application Engineers are available to assist you with installation, setup, or operating instructions. - Page 3 INVERTER/CHARGER | Quick Start Guide 2. Read the entire EVO Owner’s Manual as well as the Remote Control EVO-RC Owner's Manual. • Familiarize yourself with its contents prior to installation or operation. This Guide will frequently refer to specific pages in the Owner’s Manual for detailed information. WARNING! If there are any items in Sections 1, 2 or 3 of the Owner’s Manual that you do not understand, do not attempt to install the unit yourself.
- Page 4 INVERTER/CHARGER | Quick Start Guide NO - Normally Open Contact Battery Common Temperature To Remote Start/Stop Sensor - Model EVO-BCTS NC - Normally Closed Contact Terminals on the Generator Optional Fuse Lead Acid ELECTRICAL SUB-PANEL FOR EVO Generator Auto (Within 7” Battery Bank Panel for AC loads backed up by EVO of battery...
- Page 5 INVERTER/CHARGER | Quick Start Guide NO - Normally Open Contact Battery Common Temperature To Remote Start/Stop Sensor - Model EVO-BCTS NC - Normally Closed Contact Terminals on the Generator Optional Fuse Lead Acid − − Generator Auto (Within 7” Battery Bank of battery SLI Battery Start/Stop...
-
Page 6: Mounting The Units
INVERTER/CHARGER | Quick Start Guide 3. Layout of the EVO • Refer to Section 2 starting at page 28 of the EVO Owner’s manual to become familiar with all the relevant connection points and components. 4. Mounting the Units • Refer to mounting information at Section 3.3 starting at page 32 of the EVO Owner’s Manual •... -
Page 7: Inverter Charger
INVERTER/CHARGER | Quick Start Guide Determine whether the optional EVO-RC remote control is necessary for your application • The EVO-RC provides useful functional information such as battery voltage, battery charging status, and AC output power. The EVO-RC is also capable of logging events to an SD card to create a history record of usage and performance. - Page 8 INVERTER/CHARGER | Quick Start Guide • Investigate the cause of the malfunction by referring to “Fault Messages and Troubleshooting Guide” in Table 7.1 of Section 7 of the EVO-RC Owner's Manual. INFO The optional EVO-RC Remote Control provides the user with the ability to modify the EVO Inverter Charger’s operating parameters.
- Page 9 Notes SAMLEX AMERICA INC. | 9...
- Page 10 Notes 10 | SAMLEX AMERICA INC.
- Page 11 Notes SAMLEX AMERICA INC. | 11...
- Page 12 Contact Information Toll Free Numbers Ph: 1 800 561 5885 Fax: 1 888 814 5210 Local Numbers Ph: 604 525 3836 Fax: 604 525 5221 Website www.samlexamerica.com USA Shipping Warehouses Kent, WA Plymouth, MI Canadian Shipping Warehouse Richmond, BC Email purchase orders to orders@samlexamerica.com 11025-EVO-230V-Quick Start-0722...
