- Page 4 Assembly Instructions Step 1 Entire assembly will be easier with 2 people. Insert 2 Wooden dowels into the holes where as shown. Attach Side frame to 2 Cross bars, top inserting 2 Screws Fix 2 Locking nuts to the holes where as shown. Note: Use Allen key turn Screws clockwise to lock.
- Page 5 Assembly Instructions Step 3 Insert 2 Wooden dowels into the holes where as shown. Attach another side frame to the unit by inserting 2 Screws Fix 2 Locking nuts to the holes where as shown. Note: Use Allen key turn Screws clockwise to lock.
- Page 6 Assembly Instructions Step 5 Attach 2 Support bar to the unit by using 4 Screws Step 6 a:Insert 6 Wooden dowels to the unit where as shown b:Attach Top panel the unit by using 20 Screws...
- Page 7 Assembly Instructions Step 7 Insert 4 Screws to the units where as shown. Note: Use Allen key turn Screws clockwise to lock. Assembly is complete. Customer Helpline:08450 778 888 If you need help or have damaged or missing parts,call the Homebase Limited 489-499 Avebury Boulevard Saxon Gate West Central Milton Keynes Bucks, MK9 2NW...
