- Page 1 Model 682C13 ICP® VIBRATION TRANSMITTER Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 800-959-4464 24-hour SensorLine: 716-684-0001 Fax: 716-684-3823 E-mail: imi@pcb.com Web: www.imi-sensors.com...
- Page 2 Assistance is needed to safely operate equipment PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
- Page 3 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
- Page 4 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
- Page 5 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
- Page 6 ® 682 Series 4-20mA Din Rail ICP Signal Conditioner Operating Guide with Enclosed Warranty Information 3425 Walden Avenue, Depew, New York 14043-2495 Phone (716) 684-0003 Fax (716) 684-3823 Toll Free Line 1-800-959-4IMI MANUAL NUMBER: 60419 MANUAL REVISION: ECN NUMBER: 46422...
-
Page 7: Table Of Contents
Table of Contents Introduction ........................Page 3 Block diagram ......................Page 3 General Features Page 4 ............................Installation and Wiring ..................... Page 5 Configuring the 682BX3 ....................Page 9 ESD Sensitivity ....................... Page 12 Ordering Information ...................... Page 13 Warranty/Servicing Warranty, Service &... -
Page 8: Introduction
Introduction ® The 682 Series is a 4-20mA Din Rail Signal Conditioner designed to interface with IMI Sensor’s ICP Accelerometer. Acceleration, Velocity, or Displacement can be converted to a 4-20mA signal by simple DIP Switch selection internal to the Din Rail enclosure. An additional standard feature of the 682 Series is the ability to convert the temperature output from an accelerometer (when equipped) to 4-20mA. -
Page 9: General Features
General Features ® External transmitters, signal conditioners, and ICP power supplies can be eliminated by direct connection of the sensor to the Din Rail Signal Conditioner. Optional 500Vdc Input to Output Electrical Isolation. Selectable 24Vdc Unregulated, 18Vdc regulated, 4mA excitation to power sensor ... -
Page 10: Installation And Wiring
Installation and Wiring Installation The 682 Series is designed to be mounted on a 35mm Din Rail. Do not install in a harsh area where it can be exposed to cleaning fluids or machine oils. IMI Sensors recommends mounting the 682BX3 in a type NEMA 4 enclosure to protect the electronics from contamination. - Page 11 Connector and Pinout Diagram The 682 Series uses plug-in type screw terminal connectors for all input and output connections. Strip off 8mm of insulation from the connection wire ends. Using a screwdriver, remove the terminal block from the enclosure in either the up or down direction, terminate the wire in the correct location. Do not exceed a torque of 0.5Nm.
- Page 12 Pin Descriptions: DC Power – Pins 1 to 3: Pin 1 +Power Pin 2 -Power/Common Pin 3 Earth Ground ® Accelerometer – Pins 4 to 6: Pin 4 Shield ® Pin 5 + ICP Accelerometer ® Pin 6 - ICP Accelerometer Temperature Sensor –...
- Page 13 Typical Wiring Diagram 682 Series Signal 682A01 Conditioner Power Power Supply Supply Signal Conditioner PAGE 8...
-
Page 14: Configuring The 682Bx3
To Maintain Conformance, Earth Ground, Power Supply Common, and I/O Shields must be connected together. Note: If using the 682 Power Supply, mount the 682 Signal Conditioner to the left of the power supply with a recommended minimum separation distance of 4” where applicable. Configuring the 682 Series Internal PC Board Diagram The Internal PC Board Diagram shows... - Page 15 S10: 10g, 1ips, 20mils S11: 5g, 0.5ips, 10mils S12: Off = 0-5Vdc Output, On = 0-10Vdc Output Internal DIP Switch Setting ® The Internal DIP Switch of the 682 Series must be configured for the Full Scale Output of the ICP Sensor connected to it.
- Page 16 Sensor Power Jumper Configuration: (Factory Default) Note: If there is no DC bias on the input signal, this will trigger the Open/short detection which subtracts 4mA from output PAGE 11...
-
Page 17: Esd Sensitivity
Warning 2 – ESD sensitivity This equipment is designed with user safety in mind; however, the protection provided by the equipment may be impaired if the equipment is used in a manner not specified by PCB Piezotronics, Inc. Caution 1 – ESD sensitivity Cables can kill your equipment. -
Page 18: Ordering Information
ESD considerations should be made prior to performing any internal adjustments on the equipment. Any piece of electronic equipment is vulnerable to ESD when opened for adjustments. Internal adjustments should therefore be done ONLY at an ESD-safe work area. Many products have ESD protection, but the level of protection may be exceeded by extremely high voltage. -
Page 19: Warranty, Service & Return Procedure
Warranty IMI instrumentation is warranted against defective material and workmanship for 1 year unless otherwise expressly specified. Damage to instruments caused by incorrect power or misapplication, is not covered by warranty. If there are any questions regarding power, intended application, or general usage, please consult with your local sales contact or distributor. -
Page 20: Customer Service
Customer Service IMI, a division of PCB Piezotronics, guarantees Total Customer Satisfaction. If, at any time, for any reason, you are not completely satisfied with any IMI product, IMI will repair, replace, or exchange it at no charge. You may also choose, within the warranty period, to have your purchase price refunded. - Page 21 Model Number Revision: NR ICP® VIBRATION TRANSMITTER 682C13 ECN #: 47363 Performance ENGLISH OPTIONAL VERSIONS Channels Optional versions have identical specifications and accessories as listed for the standard model except where noted below. More than one option may be used. Input Signal(Vibration) ±...
- Page 22 PCB Piezotronics Inc. claims proprietary rights in REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others DESCRIPTION without the written consent of PCB Piezotronics Inc. DIM .44 WAS .50 45450 4.47 [113.6] .44 [11.2] .890 [22.60]...
