VOCODER VC340
VOCODER VC340 SysEx information
SYSTEM EXCLUSIVE COMMANDS
Some parameters can be changed using MIDI system exclusive (SysEx) commands.
A MIDI utility such as MIDI OX can be used to send a SysEx command data string
from the computer to the VOCODER VC340 using the USB MIDI connection.
Please see the VOCODER VC340 product page on our website for more details of
the SysEx commands.
技术参数
Synthesizer Architecture
Implementation Analog
Keyboard
Keys 37 semi-weighted, full-size keys
Keyboard sensing Note on/off velocity
Upper Left Section
Faders External sythesizer input level
Rotary knobs Headphones level
LED Power, external signal present, clip (red)
Lower Left Section
Faders Pitch shift: down-normal
Rotary knobs Volume, tune, pitch set, pitch time
Keyboard split selection: low/high, pitch shift:
Switches
auto/off (external control)/manual
Balance Section
Faders Direct mic level, human voice level, strings level
Vibrato Selection
Faders Rate, delay time, depth
Vocoder Section
Faders Tone, mic input level
Switches Lower, upper, ensemble
Mic signal present, mic clip (red),
LEDs
lower, upper, ensemble
Human Voice Section
Fader Attack
male 8' lower, male 4' lower, male 8' upper,
Switches
female 4' upper, ensemble
male 8' lower, male 4' lower, male 8' upper,
LEDs
female 4' upper, ensemble
Release Section
Fader Release (for strings, human voice, vocoder)
Strings Section
Faders Attack, tone
Switches Lower, upper
LEDs Lower, upper
快速启动向导
Rear Panel
Switches Power on/off, output level: low/medium/high
Connectivity
MIDI In/Out/Thru 5-pin DIN / 16 channels
USB USB 2.0, type B
Pitch control 1/4" TS
Vocoder hold 1/4" TS
External synth input 1/4" TS, unbalanced, max. +12 dBu
1/4" TS, stereo or mono, unbalanced, max. +14 dBu
Output L/R
(high), +0 dBu (mid), -13 dBu (low)
1/4" TRS, unbalanced, max. +12 dBu @
Headphones
32 ohm load
Microphone input 1/4" TRS, and XLR female, max. -3 dBu
USB
Type Class compliant USB 2.0, type B
Supported Windows 7 or higher
operating systems Mac OS X 10.6.8 or higher
Power Requirements
Mains connector Standard IEC receptacle
Power consumption 15 W max.
Internal Switch-mode PSU Autorange 100-240 V, (50/60 Hz)
Environmental
Operating
5°C – 40°C (41°F – 104°F)
temperature range
Physical
Dimensions (H x W x D) 103 x 649 x 257 mm (4.1 x 25.6 x 10.1")
Weight 6.6 kg (14.5 lbs)
Shipping Weight 8.4 kg (18.5 lbs)
