SB5101 Cable Modem
G E N E R A L S P E C I F I C AT I O N S
F-Connector, female, 75 Ω
Cable Interface
CPE Network Interface
USB, Ethernet 10/100Base-T
Data Protocol TCP/IP
Dimensions
6.2 in (15.75 cm) H x 2.3 in (5.84 cm) W x 6.0 in (15.24 cm) L
Power 9 W (nominal)
Input Power
North America 105 – 125 VAC, 60 Hz
International 100 – 240 VAC, 50 – 60 Hz
D OW N S T R E A M
Modulation
64 or 256 QAM
Maximum Data Rate* 38 Mbps (256 QAM at 5.361 Msym/s)
Bandwidth
6 MHzp
Symbol Rate 64 QAM 5.057 Msym/s, 256 QAM 5.361 Msym/s
Operating Level Range
–15 to +15 dBmV
75 Ω (nominal)
Input Impedance
Frequency Range
88 to 860 MHz
U P S T R E A M
Modulation
8***, 16, 32***, 64***, 128**** QAM or QPSK
Maximum Channel Rate** 30 Mbps (64 QAM at 5.120 Msym/s)
Bandwidth
200 kHz, 400 kHz, 800 kHz, 1.6 MHz, 3.2 MHz, 6.4*** MHz
Symbol Rates 160, 320, 640, 1280 and 2560 and 5120*** ksym/s
Operating Level Range
A-TDMA +8 to +54 dBmV (32 QAM, 64 QAM)
+8 to +55 dBmV (8 QAM, 16 QAM)
+8 to +58 dBmV (QPSK)
S-CDMA +8 to +53 dBmV (all modulations)
75 Ω (nominal)
Output Impedance
Frequency Range 5 to 42 MHz (edge to edge)
E N V I R O N M E NTA L
Operating Temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature –30 °C to 80 °C (–22 °F to 176 °F)
Operating Humidity
5 to 95% R.H. (non-condensing)
* Actual speeds will vary, and are often less than the maximum possible. Data transmission speed is approximate and depends on the configuration and capacity of your network, as well as the
amount of traffic on the network.
** Actual data throughput will be less due to physical layer overhead (error correction coding, burst preamble, and guard interval).
*** With A-TDMA or S-CDMA enabled CMTS.
**** With S-CDMA enabled CMTS.
Motorola, Inc. 101 Tournament Drive, Horsham, Pennsylvania 19044 U.S.A.
www.motorola.com
MOTOROLA and the Stylized M Logo are registered in the U.S. Patent and Trademark Office. Microsoft and Windows are registered
trademarks of Microsoft Corporation. Windows Me and Windows XP are trademarks of Microsoft Corp. DOCSIS is a registered
trademark of Cable Laboratories, Inc. Macintosh is a registered trademark of Apple Computer, Inc. Linux is a registered trademark of
Linus Torvalds. UNIX is a registered trademark of The Open Group in the United States and other countries. All other product or service
names are the property of their respective owners. ©Motorola, Inc. 2006.
533176-001 5702–0606–0K
Power
Receive
Send
Online
PC/Activity
Standby
