Revolution Micro Avici 750 Owner's Manual

Avici Integrated LED Lighting System
120/240/277v or 347v
Owner's Manual June 1, 2022
Congratulations on your new Avici 750. The Avici combines an array of
Osram LEDs with our custom-designed drivers for one amazing,
programmable spectrum, computer-controlled grow lighting system.
This manual will tell you how to hang, connect and operate your new Avici.
The Box Contains
Avici 750 Integrated LED Lighting System
Power Cord (NEMA 6-15P standard)
Two (2) RJ-14 Data Cables
RJ-14 Dual Splitter
Two custom wire light hangers

Installing and Powering Up

1
Remove the protective cap from the power socket.
.
2
.
The bars need to be arranged in the following pattern so
the power flows through one bar to the next. The ends of the
bar are labeled either IN or OUT, and should be alternated with
consideration for how it will be wired.
IN
OUT
3
. Use the two provided
metal hangers to attach
the Avici 750 to your ceiling
or racking system by
hooking them through
the two metal tabs.
4
.
Align the sections on the
socket with those on the
power cable. They'll only
fit together one way.
info@revmicro.com
OUT IN
IN OUT
