Revolution Micro Avici V Owner's Manual

Integrated led lighting system
Hide thumbs
1
2
3

Advertisement

Table of Contents

Avici V Integrated LED Lighting System
240v, 277v, 347v or 480v
Owner's Manual May 18, 2022
Congratulations on your new Avici. The Avici combines an array of
Osram LEDs with our custom-designed drivers for one amazing,
programmable spectrum, computer-controlled grow lighting system.
This manual will tell you how to hang, connect and operate your new Avici.
The Box Contains
Avici V Integrated LED Lighting System
Power Cords
Custom Lighting Hangers

Installing The V Series

1
To assemble a light in the
.
V Series, you will need a
4.5mm Allen wrench.
2
Screw the red hanger
.
onto the metal tab on
the front and back of
the Avici V Bars.
3.
The bars need to be arranged in the following pattern so the
power flows through one bar to the next. The ends of the bar
are labeled either IN or OUT, and should be alternated with
consideration for how it will be wired.
IN
OUT
OUT
IN
info@revmicro.com
SCREWS
IN
OUT
OUT
IN
404/334-9788

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Avici V and is the answer not in the manual?

Questions and answers

Related Manuals for Revolution Micro Avici V

Summary of Contents for Revolution Micro Avici V

  • Page 1 Installing The V Series Avici V Integrated LED Lighting System 240v, 277v, 347v or 480v To assemble a light in the V Series, you will need a Owner's Manual May 18, 2022 4.5mm Allen wrench. Congratulations on your new Avici. The Avici combines an array of...
  • Page 2 Installing The V Series Continued Attach the top of the wire rack to the location within racking system Align the sections on the or ceiling, and the ends to the mounting holes shown below. socket with those on the power cable. They’ll only fit together one way.
  • Page 3 Blinking LEDs What Your Avici Is Telling You Blinks Once A Second – Over Temperature Flickers Briefly Once a Second – External Control If the Avici internal heatsink reaches a programmed over The RLC1 and TouchMi Room Controller can control 512 Revolution temperature point, it's way too hot and it will shut off with the lights in two zones.
