You Have Just Purchaseda Mini Power Mixer; Switching On The Appliance; Advice On Electrical Connections; Operating The Appliance - Robot Coupe Mini MP 170 V.V. Manual

YOU HAVE JUST PURCHASED
A MINI POWER MIXER
The new Mini MP 170 V.V. and Mini MP 220 V.V.
models are the latest additions to Robot-Coupe's
range of power mixer. They have been specially
designed for processing smaller quantities. They are
fitted with a foot, blades and an emulsifying disc
which can be entirely dismantled, and their tubes
measure 170 and 220 mm long respectively.
These power mixer are tools which are totally adapted
to the needs of professionals. They will enable you
to make soups, vegetables purées and cereal
preparations without any effort.
The variable-speed function will enable you to
adjust the speed to suit each preparation and to
start the processing at a lower speed in order to
reduce splashing.
The simple design of these appliances allows the
assembly and dismantling of the moving parts in no
time at all, to ease maintenance and cleaning.
These instructions contain important information
that will enable you to extract the greatest return on
your investment.
We therefore strongly advise you to read these
instructions carefully before using the appliance.
SWITCHING ON
THE APPLIANCE

• ADVICE ON ELECTRICAL CONNECTIONS

This class II appliance (double insulation) requires
a single-phase alternating current but does not
need an earthed socket. The universal-type motor
is fitted with an interference suppressor.
6
The power supply must be protected by a
differential circuit breaker and a 10 A fuse.
Check that you have a standard 10/16 A
single-phase socket.
Make sure that the voltage of your power supply
matches that shown on the identification plate of
your appliance.
Robot-Coupe supplies these models with different
types of motors:
230 V / 50 Hz for power supplies
of : 220 à 240 V.
120 V / 60 Hz
220 V / 60 Hz
The power mixer is supplied with a single-phase
plug connected to a power cord.

OPERATING THE APPLIANCE

• STARTING AND STOPPING
1. Plug your appliance
into the mains, making
sure you do not press
the button (BC).
2. Insert the foot into
the preparation.
3. Press the control
button (BC), and the
power mixer will start
up.
4. To stop the power
mixer, release the
control button (BC).

• VARIABLE-SPEED OPERATION

Follow steps 1 to 4 above, then:
5. Change the speed of the motor by turning the
variable speed button (MV) towards the maximum
or minimum as required.
Variable-speed : Speed between 2000 and
12500 rpm.
With the self-regulating speed system, once you
have selected a speed, it will remain constant, even
if the consistency of your mixture changes.

WORKING POSITION

For a more ergonomic
approach, we recom-
mend that you hold the
handle of the appliance in
one hand and the contai-
ner in the other. It is a
good idea to lean forward
slightly, making sure that
the bell does not touch the
bottom of the container.
Always make sure that the
bell is sufficiently immersed to avoid splashing and
that the air vents of the motor unit does not come into
contact with any liquid.
For optimum efficiency, two thirds of the foot should
be immersed in the preparation.
