- Page 1 Wiring KGW3204/KPS3204Serial Protocol Converters Hardware Installation Manual Publication date:2017/10 Version V1.0...
- Page 2 All permissions reserved: The copyright of this manual belongs to Beijing Dongtu Technology Co., Ltd. Without the written permission of the copyright owner, No unit or individual may extract, reproduce, reproduce, translate or distribute for commercial purposes in any way. Infringement must be investigated. Copyright © 2017 Kyland Technology Co., Ltd.
- Page 3 Wiring Safety Instructions This product has good and reliable performance within the design range, but it is necessary to avoid human damage or damage to the equipment. Before using the device, please read this manual carefully to ensure the safety of the user and the device. Please keep this manual in a safe place after reading it. For future reference. Our company is not responsible for personal injury or equipment damage caused by violating the safety instructions.
- Page 4 Wiring • The device is broken or the case is cracked. • The device is not working abnormally or its performance has changed. • The device produces odors, smoke, or unusual noises. • The equipment should be installed in a suitable place, and if the equipment is not used correctly according to the requirements of the company, the protective measures provided by the equipment will be affected.
-
Page 5: Table Of Contents
Wiring Table of contents product description............................ 1 Structure and Interface ..........................2 2.1 Front panel..............................2 2.2 Top cover..............................3 Install................................4 3.1 Dimensions..............................4 3.2 Installation method and steps………………………………………………………………………………………………….4 3.2.1 Mounting rails ............................. 5 3.2.2 Removal of card rails. -
Page 6: Product Description
1 Product description KGW3204/KPS3204 It is our company for factory automation, wind power, distribution network automation, subway PIS, electricity SCADA, Protocol converters developed in sewage treatment, metallurgy, intelligent transportation, rail transportation and other industries, support Modbus Gateways and Serial Servers model selection. -
Page 7: Structure And Interface
Wiring structure and interface 2 Structure and interface Notice: In order to keep the interface clean and ensure the operation performance of the device, it is recommended that the user order the interface dust cover separately according to the interface type of the device. 2.1 Front panel Picture 1 Front panel callout... -
Page 8: Top Cover
Wiring structure and interface Table 2 Front panel label description Label serial Panel identification Description number PWR1 Power supply1indicator light PWR1 Power supply2indicator light Device running indicator 10/100Base-T(X)Ethernet interface connection status indicator (green light) 10/100Base-T(X)Ethernet interface speed indicator (yellow light) E1/E2 10/100Base-T(X)Ethernet interface Sn-T... -
Page 9: Install
Install 3 Install 3.1 Dimensions Picture 3 KGW3204/KPS3204 Installation dimension drawing (unit: mm) Notice: • The case of the device is part of the cooling system of the whole machine. During normal operation, the case will heat up. Do not cover the case when the device is working. -
Page 10: Mounting Rails
Wiring Install 3.2.1 Card rail installation Step 1, select the installation location of the equipment, and ensure that the installation space is sufficient and the heat dissipation is smooth (dimensions (W×H×D): 54mm×135mm×106mm). Step 2, snap the upper part of the caliper seat on the DIN On the card rail, apply a little upward force on the lower end of the device, and press the arrow in the figure below. -
Page 11: Mounting Clearance
Wiring Install 3.2.3 Installation clearance The installation clearance needs to be taken into consideration when the product is installed. Recommended installation clearance: • Top and bottom: 30 mm • Both sides: 20 mm • Front: 30 mm... -
Page 12: Wiring
Wiring wiring 4 Wiring 4.1 10/100Base-T(X)Ethernet interface 10/100Base-T(X)Ethernet interface adopts standardRJ45connector, with self-adaptive function, can be automatically configured to 10M/100Mstatus and full-duplex/half-duplex mode of operation, and supports cable MDI/MDI-X Self-identification function, i.e. and the end device and the network device can be connected using a straight-through network cable or a cross-over network cable. -
Page 13: Rs-232/Rs-422/Rs-485Interface
Wiring wiring Picture 7 10/100Base-T(X) RJ45 Connector straight line, cross line interconnection Note: RJ45 Connector wiring as standard 568B (1-orange white, 2-orange, 3-green and white, 4-blue, 5-blue and white, 6-green, 7-brown and white, 8-brown). 4.2 RS-232/RS-422/RS-485interface RS-232/RS-422/RS-485 The interface adopts the standard DB9 male interface, RS-232 Interface support RTS/CTS. -
Page 14: Power Terminals
Wiring wiring Ground before disconnecting the grounding wire after power off. The upper cover of the device has a ground screw (see fig.2), that is, the ground wire of the chassis, called "chassis ground". Connect one end of the ground wire After being crimped with the cold-pressed terminal, fix it at the "chassis ground"... -
Page 15: Dip Switch
Wiring PWR2: - PWR2: + • Wiring and Installation Step 1, according to4.3Steps Ground the "chassis ground" of the device well. Step 2, remove the power terminal plug from the device. Step 3, place one end of the power cord and ground wire according to the meter5Requires insertion into the power terminal plug and secures the power cord and ground Wire. - Page 16 Wiring wiring Picture 9 DIP switch Table 7 DIP switch function description DIP switch State Function description enable serial portS1ofRS-485Termination resistor Disable serial portS1ofRS-485Termination resistor enable serial portS2ofRS-485Termination resistor Disable serial portS2ofRS-485Termination resistor enable serial portS3ofRS-485Termination resistor Disable serial portS3ofRS-485Termination resistor enable serial portS4ofRS-485Termination resistor Disable serial portS4ofRS-485Termination resistor...
-
Page 17: Reset
Wiring Reset Reset The reset button is located on the upper cover of the device and has the function of restoring the default configuration. Keep pressing the reset button for more than5seconds and let go to restore the default configuration (including IP address) and reboot, the default IP address is E1: 192.168.0.249, E2: 192.168.1.249. -
Page 18: Led Indicator Status
Wiring ledlight status LED light status Table 8 Description of Front Panel Indicators Description State input power1connected and running Bright Power supply 1 Indicator -PWR1 fine input power1Not connected or running extinguish abnormally input power2connected and running Bright Power supply 2 Indicator -PWR2 fine input power2Not connected or running extinguish... -
Page 19: Access
Wiring Access Access The device can be accessed in the following two ways. 7.1 Telnet access Step 1, connect with a network cable PC The network port and the Ethernet interface of the device. Step 2, in the Start → Run dialog box, enter "telnet IP-address”. For example, equipment IP address is 192.168.0.249time (device default IP address), enter "telnet 192.168.0.249”. -
Page 20: Basic Performance And Specifications
Wiring Basic Performance and Specifications 8 Basic Performance and Specifications Power supply Power identification Input maximum voltage range Input rated voltage range 24VDC 12-48VDC Access terminal 4 pin 5.08mm Spacing Terminals Rated power 3.2W rated power Mechanical structure aluminum, fanless Chassis Protection class IP40... - Page 21 Wiring Customer service hotline: +7 (495) 723 33 33 Tel/fax: +7 (499) 969 81 21 URL: http://www.kyland.ru Email: services@kyland.ru about KYLAND For more product information, please visit the website: http://www.kyland.ru...
