SECHRIST 21465 Service Manual

Hydraulic and standard stretchers
Hide thumbs Also See for 21465:
Table of Contents

Advertisement

Quick Links

Download this manual
SECHRIST INDUSTRIES, INC.
Service Manual
Hydraulic and Standard Stretchers
Hydraulic Models:
P/N 21465
P/N 21266
Standard Models:
P/N 21502
P/N 21464
Standard Model without Siderails:
P/N 21487
4225 E. La Palma Avenue
Anaheim, California 92807 USA
Phone: 714−579−8400 Fax: 714−579−0814
USA & Canada 800−SECHRIST (732−4747)
Website: www.sechristind.com
E−mail: info@sechristind.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 21465 and is the answer not in the manual?

Questions and answers

Related Manuals for SECHRIST 21465

Summary of Contents for SECHRIST 21465

  • Page 1 Hydraulic Models: P/N 21465 P/N 21266 Standard Models: P/N 21502 P/N 21464 Standard Model without Siderails: P/N 21487 4225 E. La Palma Avenue Anaheim, California 92807 USA Phone: 714−579−8400 Fax: 714−579−0814 USA & Canada 800−SECHRIST (732−4747) Website: www.sechristind.com E−mail: info@sechristind.com...

  • Page 2: Table Of Contents

    Table of Contents Preventative Maintenance Checklist ............Cleaning .
  • Page 3 Table of Contents Sechrist Industries Declares that the medical devices described hereafter: Gurney System for the following models: 21465 21266 21502 21464 21487 are in conformity with the essential requirements and provisions of Council Directive 93/42/EEC. Conformity has been achieved under Annex VII.

  • Page 4: Preventative Maintenance Checklist

    Ground chain intact I.V. pole intact and operating properly Oxygen bottle holder intact and operating properly Head rest operates and latches properly (on Stretcher P/N’s 21464, 21465) No rips or cracks in mattress cover Lubricate where required Accessories and mounting hardware in good condition and working properly HYDRAULIC STRETCHERS (P/N’S 21465, 21266):...

  • Page 5: Cleaning

    Cleaning Hand wash all surfaces of the stretcher with warm water and mild detergent. Dry thoroughly. DO NOT STEAM CLEAN, PRESSURE WASH, HOSE OFF OR ULTRASONICALLY CLEAN. Using these methods of cleaning is not recommended and may void this product’s warranty. In general, when used in those concentrations recommended by the manufacturer, either phenolic type or quaternary type disinfectants can be used.

  • Page 6: Service Information

    Service Information CASTER COVER INSTALLATION AND REMOVAL Double Prongs Looking through the larger of the two side cut−outs, align the cover with the axle nut or bolt head, as shown. Single Prong Push down on the opposite side of the cover until the single prong engages the caster horn.

  • Page 7: Brake Rod Removal

    Service Information BRAKE ROD REMOVAL Required Tools: Hammer 7/32” Punch String or Bungee Cords 1. Pump the litter up to full height. 2. Lift the base hood and support it from the litter using string or bungee cords. 3. Remove the hex head cap screws connecting the brake rod supports to the base frame. 4.

  • Page 8: Brake Ring Removal

    Service Information BRAKE RING REMOVAL Required Tools: 9/16” Socket w/Extension 3/8” Drive Ratchet Needle−Nose Pliers String or Bungee Cord 1. Pump the litter up to full height. 2. Lift the base hood and support it from the litter using string or bungee cords. 3.

  • Page 9: Siderail Latch Adjustment

    Service Information SIDERAIL LATCH ADJUSTMENT Required Tools: 1/8” Hex Allen Wrench WARNING The siderail latches are preset at the factory, and do not normally need adjustment. If adjustment must be done, it is important to follow the procedure below. If adjustment is not done properly, injury to the patient or user could occur.

  • Page 10: Fixed Height Base Assembly

    Fixed Height Base Assembly with Standard Brakes Assembly part number 0720−600−210 (reference only) 0720−133−025 0720−660−021 0720−665−022 0720−800−030 Item Part No. Part Name Qty. 0023−288−000 Hex Washer Hd, Screw 0023−305−000 Hex Washer Hd, Screw (page 10) Standard Brake Assembly (page 14) Fifth Wheel Assembly 0753−006−148 Cam Bearing...

  • Page 11: Base Assembly With Standard Brakes

    Base Assembly w/Standard Brakes Assembly part number 0753−003−005 (reference only)
  • Page 12 Base Assembly w/Standard Brakes Item Part No. Part Name Qty. 0005−039−000 Step Bolt 0011−262−000 Washer 0016−035−000 Nylock Hex Nut 0016−049−000 Nylock Hex Nut 0023−288−000 Hex Washer Hd. Screw 0027−012−000 Hitch Pin 0028−037−000 External Retaining Ring 0038−439−000 Extension Spring 0081−272−000 Roller Bearing 0753−001−001 Base Frame (page 12)

  • Page 13: Brake Rod Assembly

    Brake Rod Assembly Assembly part number 0753−003−001 (reference only) Item Part No. Part Name Qty. 0026−067−000 Slotted Spring Pin 0753−003−004 Brake Rod Support (page 13) Drive Link Assembly 0753−003−014 Brake Rod 0753−003−015 Nyliner 0753−003−099 Butterfly “V” Pedal (page 13) Drive Link Assembly 1210−201−335 Red Brake Label 1210−201−336...

  • Page 14: Drive Link Assembly

    0753−003−010 Drive Link Assembly Item Part No. Part Name Qty. 0753−003−011 Brake Rod Drive Link 0753−003−061 Brake Cam Drive Link 0753−003−098 Flat Hd. Semi−Tubular Rivet 0753−003−102 Brake Cam 0753−006−135 Drive Link Assembly Item Part No. Part Name Qty. 0753−003−011 Brake Rod Drive Link 0753−003−098 Semi−Tubular Rivet 0753−006−122...

  • Page 15: Fifth Wheel Assembly

    0753−006−130 Fifth Wheel Assembly...
  • Page 16 0753−006−130 Fifth Wheel Assembly Item Part No. Part Name Qty. 0003−083−000 Hex Hd. Cap Screw 0016−035−000 Nylock Hex Nut 0023−288−000 Hex Washer Hd. Screw 0025−050−000 Rivet 0753−006−074 Torsion Spring 0753−006−075 Torsion Spring 0753−006−097 Drive Shaft Bearing 0753−006−106 Dampener 0753−006−108 Thrust Washer 0753−006−115 Bearing 0753−006−120...

  • Page 17: Caster Assembly

    0753−010−020 8” Caster Assembly Item Part No. Part Name Qty. 0715−002−025 Wheel 0003−099−000 Hex Hd. Cap Screw 0753−010−021 Caster Horn w/Bearing 0016−060−000 Centerlock Nut...

  • Page 18: Push Bar Gurney Assembly

    Push Bar Gurney Assembly Assembly part number 0720−565−010 (reference only) Item Part No. Part Name Qty. 0003−093−000 Hex Hd. Cap Screw 0003−017−000 Hex Hd. Cap Screw 0011−004−000 Washer 0016−011−000 Flexlock Nut 0016−028−000 Fiberlock Nut 0037−010−000 Square Hole Plug 0720−500−017 0720−565−034 Upper Tower Assembly 0720−565−040 Push Arm Weldment...

  • Page 19: Fixed Height Base Labeling Assembly

    Part Name Qty. 0004−057−000 But. Hd. Cap Screw 0016−027−000 Kep Nut 0753−010−043 Hood 0946−001−108 I.V. Clip 0946−421−005 Grommet 0720−560−051 Sechrist Serial No. Label 0720−560−052 Sechrist Spec. Label 0720−560−054 Gray Stripe Label 0753−010−410 Gray Brake/Steer Label, Head 0753−010−391 Gray Brake/Steer Label, Foot...

  • Page 20: Fixed Height Base Labeling Assembly − Pushbar Gurney

    Base Labeling Assembly − Pushbar Gurney Assembly part number 0720−665−050 (reference only) Item Part No. Part Name Qty. 0753−010−046 Hood 0946−421−005 Grommet 0720−560−052 Sechrist Logo Label 0720−560−051 Sechrist Spec. Label 0921−001−252 Serial No. Label 0753−010−400 Gray Brake/Steer Label, Foot 0753−010−410 Gray Brake/Steer Label, Head 1...

  • Page 21: Hydraulic Base Assembly

    Hydraulic Base Assembly Assembly part number 0721−660−020 (reference only) 0023−288−000 0753−003−004 Insert spring hook thru slot in pump pedal and into notch in jack tower as shown Insert pump ram into keyhole slot on both ends. Lower pump connecting rod weldment onto pump ram as shown...
  • Page 22 Hydraulic Base Assembly 0753−006−130 See Detail A Insert item ”AC” into keyhole in item ”AD” and push down to assemble DETAIL A Insert spring hook thru hole in pump connecting rod. Attach other hook to return spring as shown Insert spring hook onto hook on release pedal.
  • Page 23 Hydraulic Base Assembly See Detail C DETAIL B See Detail B Insert head end release rod into release valve assembly as shown DETAIL C Insert foot end release rod into release valve assembly as shown...
  • Page 24 Hydraulic Base Assembly Right Hand Left Hand Run the cable assemblies thru the release rod bracket. Pull cables toward the foot end of the base to remove slack. Run the cable from the right hand pedal on the outside of the jack mounting plate Run the cable from the left hand pedal thru the hole...
  • Page 25 Hydraulic Base Assembly Item Part No. Part Name Qty. 0011−023−000 Washer 0014−071−000 Washer 0023−288−000 Hex Washer Hd. Screw 0025−079−000 Dome Head Rivet 0027−031−000 Hair Pin Cotter 0038−497−000 Extension Spring (page 25) Release Pedal Assembly 0753−004−014 Head End Release Rod 0753−004−015 Foot End Release Rod 0753−004−030 Foot End Release Cable...

  • Page 26: Release Pedal Assembly

    Release Pedal Assembly Assembly part number 0721−660−022 (reference only) Item Part No. Part Name Qty. 0025−079−000 Rivet 0721−660−023 Release Pedal Weldment 0753−004−035 Release Pedal Bumper Strip 0753−004−036 Release Pedal Bushing 0753−004−121 Release Pedal Mtg. Plate...
  • Page 27 Foot End Release Pedal Assembly Assembly part number 0753−004−123 (reference only) Item Part No. Part Name Qty. 0026−132−000 Clevis Pin 0753−004−024 Release Pedal, Foot End, Left 0753−004−025 Release Pedal, Foot End, Right 0753−004−028 Release Pedal Return Spring 0753−004−322 Release Pedal Mtg. Plate 0027−022−000 Rue Ring Cotter...

  • Page 28: Pump Pedal Assembly

    0753−005−173 Foot End Pump Pedal Assembly Item Part No. Part Name Qty. 0026−343−000 Groove Pin 0715−001−140 Clear Vinyl Tubing 0753−005−044 Pump Pedal Bushing 0753−005−171 Foot End Pedal Weldment 0715−201−126 Plastic Pump Pedal...

  • Page 29: End Control Base Labeling Assembly

    0946−001−108 I.V. Clip 1040−010−134 Bellows 0720−560−052 Sechrist Logo Label 0720−560−054 Gray Stripe Label 0721−560−051 Sechrist Serial No. Label 0753−010−052 Foot End Pump Pedal Label 0753−010−053 Foot End Release Pedal Label 0921−001−252 Bar Code Label 0753−010−410 Head End Brake/Steer Label 0753−010−400...
  • Page 30 Litter Assembly − Fixed Height Stretcher Assembly part number 0720−560−010 (reference only)
  • Page 31 Litter Assembly − Fixed Height Stretcher...
  • Page 32 Corner Cover, Hole Only 1 0037−074−000 Hole Plug 1010−700−045 Siderail Bumper 0038−220−000 Compression Spring 1210−800−008 Patent Label 0003−078−000 Hex Hd. Cap Screw (page 38) Push Handle Assembly 0720−560−013 Handle Soc. Wldmt., Lt. 0721−560−019 Sechrist Support Wldmt. 2 0720−560−014 Handle Soc. Wldmt., Rt.
  • Page 33 Litter Assembly − Hydraulic Stretcher Assembly part number 0721−660−010 (reference only)
  • Page 34 Litter Assembly − Hydraulic Stretcher SIDERAIL LATCH DETAIL...
  • Page 35 Litter Assembly − Hydraulic Stretcher...
  • Page 36 Litter Assembly − Hydraulic Stretcher Item Part No. Part Name Qty. Item Part No. Part Name Qty. 0003−355−000 Hex Hd. Cap Screw 0721−026−069 Upright Sleeve 0003−356−000 Hex Hd. Cap Screw 0721−026−074 Lock Handle 0003−359−000 Hex Hd. Cap Screw (page 36) Siderail Assembly, Right 0004−135−000 But.

  • Page 37: Folddown Siderail Assembly

    Siderail Assembly, Right & Left Assembly part numbers 0721−026−096 (Right) 0721−026−097 (Left) (Left Side Shown) Item Part No. Part Name Qty. 1010−026−015 Top Rail 1010−026−083 Upright 1010−026−084 Upright, Bent 1010−026−082 Spacer 0025−106−000 Semi−Tubular Rivet 1010−026−010 Round Hole Plug 1010−026−085 Upright, Latch 1010−026−012 Bent Spindle Stop...

  • Page 38: Litter Release Rod Assembly

    0721−560−015 Litter Release Rod Assembly Item Part No. Part Name Qty. 0721−560−021 Short Link 0721−560−022 Litter Release Rod 0721−560−023 Turn Buckle 0015−012−000 Jam Nut...

  • Page 39: Push Handle Assembly

    1211−351−010 Push Handle Assembly Item Part No. Part Name Qty. 1010−354−024 Stop Link 1211−151−018 Sleeve Assembly 0026−118−000 Roll Pin...

  • Page 40: Transfer Dolly Assembly

    Transfer Dolly Assembly HEAD Item Part No. Part Name Qty. Litter Assembly HB−233 Latch HB−274 Machine Screw HB−275 Washer HB−276 Machine Screw HB−279 Machine Screw HB−284 Machine Screw HB−305−16 Washer HB−601−05 Track Guide HB−601−07 Track Cap HB−801−02 Rear Crossbrace HB−801−03 Front Crossbrace HB−801−04 Dolly Track...

  • Page 41: Pole Assembly

    0390−025−000 Standard, Removable I.V. Pole Assembly Item Part No. Part Name Qty. 0024−023−000 Plastic Knob 0390−003−053 Double I.V. Ass’y 0393−003−043 Tube Assembly 0004−496−000 Soc. Hd. Cap Screw...

  • Page 42: Warranty

    Any authorization for repair or alter- ation by buyer must be in writing from SECHRIST to prevent the voiding of this warranty. In the event SECHRIST or its representatives render any technical advice or service of any kind to buyer or anyone else in connection with the equipment or products covered by this warranty, the buyer hereby releases SECHRIST from all liability of any kind whatsoever as a result thereof;...
  • Page 43 MDD 93/42/EEC EU Authorized Representative Sechrist Industries Inc. AR−MED, Ltd. (Company 3154742) 4225 E. La Palma Avenue Runnymede Malthouse Anaheim, CA 92807 Egham, Surrey TW20 9BD (714) 579−8400 United Kingdom DH 12/03 0721−660−191 REV A...
