FCC ID : BEJFB990G
APPENDIX G :
USER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for LG BEJFB990G

Summary of Contents for LG BEJFB990G

  • Page 1 FCC ID : BEJFB990G APPENDIX G : USER’S MANUAL...

  • Page 2: Canadian Doc Notice

    Regulatory Information FCC Compliance Statement CE Conformity Notice (for Europe) This equipment has been tested and found to comply within Products with the “CE” Marking comply with the EMC the limits of a Class B digital device pursuant to Part 15 of Directive(89/336/EEC) and LOW VOLTAGE Directive the FCC Rules.
  • Page 3 Regulatory Information cont. scheme, which provides for international environmental Lead can be found in picture tubes, display screens, solder, labelling of personal computers. The labelling scheme was and capacitors. Lead damages the nervous system and in developed as a joint effort by the TCO (The Swedish higher doses causes lead poisoning.
  • Page 4 Regulatory Information cont. TCO99 The energy requirements include a demand that the computer and/or display, after a certain period of inactivity, shall reduce its power consumption to a lower level in one or more stages. The length of time to reactivate the computer shall be reasonable for Congratulations! the user.
  • Page 5 (U.S.A only) is a set of power-saving guidelines NERGY issued by the U.S. Environmental Protection Agency(EPA). As an ENERGY STAR Partner LG Electronics U.S.A.,Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency. EPA POLLUTION PREVENTER...

  • Page 6: Important Precautions

    Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential eletrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this monitor, observe the following basic rules for its installation, use, and servicing.
  • Page 7 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the monitor where the power cord is subject to damage. Do not use this monitor near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.

  • Page 8: Connecting The Monitor

    Connecting the Monitor Before setting up the monitor, ensure that the power is turned off to the monitor, computer system, and other attached devices. Carefully set the monitor face-down with the underside facing you. Connecting the Tilt/Swivel stand Align the hooks on the tilt/swivel stand with the matching slots in the base of the monitor.

  • Page 9: Using The Computer

    Connecting the Monitor Using the Computer Connect the signal cable. When mated, tighten the thumbscrews to secure the connection. Connect the power cord into a properly power outlet that is easily accessible and close to the monitor. NOTE This is a simplified representation of the rear view. This rear view represents a general model;...

  • Page 10: Control Panel Functions

    Control Panel Functions Front Panel Controls Control Function Power Button Use this button to turn the monitor on or off. This Indicator lights up green when the monitor Power (DPMS) operates normally. If the monitor is in DPM Indicator (Energy Saving) mode, this indicator color changes to amber.

  • Page 11: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the monitor is quick and easy with the On Screen Display Control system. A short example is quick and easy given below to familiarize you with the use of the controls.

  • Page 12: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub menu Reference To adjust the brightness and Brightness contrast of the screen Contrast BRIGHTNESS/ CONTRAST V Position To adjust the position of the screen H Position...

  • Page 13: To Adjust The Brightness And Contrast Of The Screen

    On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. NOTE The order of icons may differ depending on the model (A8~A11).

  • Page 14: To Adjust The Size Of The Screen

    On Screen Display(OSD) Selection and Adjustment To adjust the size of the screen OSD Adjust Description Vertical Size To adjust image height. Horizontal Size To adjust image width. To adjust the shape of the screen OSD Adjust Description Tilt To correct image rotation. Side Pincushion To correct a concave or convex bowing of the image.

  • Page 15: To Customize The Color Of The Screen

    On Screen Display(OSD) Selection and Adjustment To customize the color of the screen OSD Adjust Description PRESET 6500K/ 9300K Select the screen color. • 6500K: Slightly reddish white. • 9300K: Slightly bluish white. TEMP Select the screen temperature which you prefer among reddish or bluish or any color in between.
  • Page 16 On Screen Display(OSD) Selection and Adjustment To improve the clarity and stability of the screen OSD Adjust Description DEGAUSS To manually demagnetize the screen to avoid showing incorrect images or colors. RECALL You can use this function to reload the modified parameters for screen display operation, as specified by the user after purchase: Position, Size, Side Pincushion,...

  • Page 17: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears Is the power cord of the Check and see if the power cord is connected properly to monitor connected? the power outlet. Is the power indicator light Press the Power button. Is the power on and the Adjust the brightness and the contrast.
  • Page 18 Troubleshooting The screen color is not normal. Do you see basic Set the color depth to 256 colors or higher: use ' C ontrol discoloration (16 colors)? Panel' ' D isplay' ' S ettings' ' C olor Palette' Is the screen color unstable Check the connection of the signal cable.

  • Page 19: Specifications

    Specifications Picture Tube 19 inches (18.0 inches viewable) Perfect Flat Tube 90 degree deflection 0.24mm Slot pitch ARAS(Anti-Reflective Anti-Static) coating Sync Input Horizontal Freq. 30 - 98kHz (Automatic) Vertical Freq. 50 - 160Hz (Automatic) Input Form Separate TTL, Positive/Negative CompositeTTL, Positive/Negative Signal Input 15 pin D-Sub Connector Video Input...

  • Page 20: Preset Modes (Resolution)

    Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 43.269 VESA 640 x 480 VESA 53.674 800 x 600 VESA 68.677 1024 x 768 91.146 VESA 1280 x 1024 VESA 93.750 1600x 1200...

  • Page 21: Making Use Of Usb (Universal Serial Bus)

    Making use of USB (Universal Serial Bus) USB (Universal Serial Bus) is an innovation in connecting your different desktop peripherals conveniently to your computer. By using the USB, you will be able to connect your mouse, keyboard, printer, and other peripherals to your monitor instead of having to connect them to your computer.

  • Page 22: Usb Specifications

    Making use of USB (Universal Serial Bus) USB Specifications Rev. 1.1 complied Self-powered hub USB standard 500mA for each (MAX) Downstream power supply Communication speed 12 Mbps (full), 1.5 Mbps (low) 1 Upstream port / 2 Downstream ports USB port IMPORTANT: These USB connectors are not designed for use with high-power USB devices such as a video camera, scanner, etc.
