- Page 1 Owner’s Manual LED Monitor* * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 24GS60F 27GS60F www.lg.com Copyright © 2022 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS LICENSE ........3 USER SETTINGS ....... 16 - Activating the Main Menu ........16 ASSEMBLING AND PREPARING 4 Main Menu Features - Supported Drivers and Software ......4 - User Settings ...............18 - Product and Button Description......5 Menu Settings How to Use the Joystick Button TROUBLESHOOTING .... -
Page 3: License
LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. -
Page 4: Assembling And Preparing
The power cord provided may differ depending upon the region. • It is recommended that use the supplied components. • If you use generic cables not certified by LG, the screen may not display or there Supported Drivers and Software may be image noises. •... -
Page 5: Product And Button Description
Product and Button Description How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with your finger. Basic Functions Press the joystick button once with Power on your finger to turn on the monitor. -
Page 6: Moving And Lifting The Monitor
Moving and Lifting the Monitor When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation, regardless of its shape or size. • Place the monitor in the original box or packing material before attempting to move it. -
Page 7: Installing On A Table
Installing on a Table • If you use the monitor panel without the stand base, its joystick button may cause the monitor to become unstable and fall, resulting in damage to the monitor or • Lift the monitor and place it on the table in an upright position. Place the monitor human injury. -
Page 8: Adjusting The Angle
Adjusting the Angle CAUTION Place the monitor mounted on the stand base in an upright position. • Unplug the power cord before moving or installing the monitor. There is risk of Adjust the angle of the screen. electric shock. The angle of the screen can be adjusted forward or backward from -5° to 15° for a •... - Page 9 Tidying up Cables (27GS60F) WARNING Arrange the cables using the cable holder as shown in the illustration. • To avoid injury to the fingers when adjusting the screen, do not hold the lower part of the monitor’s frame as illustrated below. •...
-
Page 10: Using The Kensington Lock
Using the Kensington Lock Installing the Wall Mount Plate The connector for the Kensington security system is located at the bottom of the This monitor meets the specifications for the wall mount plate or other compatible monitor. devices. For more information on installation and usage, refer to the Kensington lock owner’s Place the screen face down. -
Page 11: Installing On The Wall
A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to the use of non- standard screws. 100 mm (3.94 inches) - Page 12 • Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Use an authorized LG wall mount and contact Back of the the local dealer or qualified personnel.
-
Page 13: Using The Monitor
USING THE MONITOR Connecting to a PC • This monitor supports the *Plug and Play feature. • Illustrations in this manual may differ from the actual product. * Plug and Play: A feature that allows you to add a device to your computer without Press the joystick button, go to Menu →... -
Page 14: Displayport Connection
Connecting AV Devices DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. HDMI Connection HDMI transmits digital video and audio signals from your AV device to the monitor. NOTE • There may be no video or audio output depending on the DP (DisplayPort) version of the PC. -
Page 15: Connecting Peripherals
Connecting Peripherals Connecting Headphones Connect peripherals to the monitor via the headphones port. NOTE • Peripheral devices are sold separately. • If you use angled earphones, it may cause a problem with connecting another external device to the monitor. Therefore, it is recommended to use straight earphones. Angled Straight (Recommend) -
Page 16: User Settings
USER SETTINGS Button Menu Status Description Main menu disabled Enables the main menu. Enters the Menu feature. NOTE (Holding down the button to turn off the monitor. You can Main menu enabled • Your monitor’s OSD (On Screen Display) may differ turn off the monitor this way at any time, including when the slightly from that shown in this manual. -
Page 17: Main Menu Features
Main Menu Features Main Menu Description : Power Off Turns off the monitor. : Input Sets input mode. : Game Mode Sets the game mode for gaming. : Menu Configures the screen settings. : Exit Exits the main menu. -
Page 18: User Settings
User Settings Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Menu. Move the joystick up/down and left/right to set the options. To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it. - Page 19 Game Mode on SDR(Non-HDR)signal. Menu > Game Mode Description Gamer 1 In this mode, users can customize elements including game-related options. Gamer 1 and Gamer 2 picture modes allow you to save two sets of customized display settings, including game-related setup Gamer 2 options.
- Page 20 Game Mode on HDR signal. Menu > Game Mode Description Gamer 1 In this mode, users can customize elements including game-related options. Gamer 1 and Gamer 2 picture modes allow you to save two sets of customized display settings, including game-related setup Gamer 2 options.
- Page 21 Menu > Game Adjust Description Provides seamless and natural images by synchronizing the vertical frequency of the input signal with that of the output signal. CAUTION • Supported Interface: DisplayPort (Adaptive-Sync), HDMI (FreeSync) • Supported Graphic Card : A graphic card that supports AMD’s FreeSync is necessary. FreeSync / Adaptive- •...
- Page 22 Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use Fast. For a fast-moving picture, it is recommended that you use Faster. Once Faster Mode is selected, Motion Blur may occur depending on the content. Response Time Faster Sets the response time to Faster.
- Page 23 Menu > Picture Adjust Description Brightness Adjusts the brightness of the screen. Contrast Adjusts the contrast of the screen. Sharpness Adjusts the sharpness of the screen. Mode 1, Mode 2, The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter the image becomes.
- Page 24 Adjusts the brightness automatically according to the screen. Disables the DFC feature. Do you want to reset your picture settings? Picture Adjust Picture Reset Cancel the select. Returns to the default settings.
- Page 25 Menu > Input Description Input List Selects the input mode. Adjusts the aspect ratio of the screen. Full Wide Displays the video in widescreen, regardless of the video signal input. Original Displays video according to the aspect ratio of the video signal input. Aspect Ratio Input NOTE...
- Page 26 Menu > General Description Language Sets the menu screen to the desired language. User-defined Key 1 You can customise the main menu to access your preferred menu easily. User-definded Key 1 and User-definded Key 2 appear at the left/right of the main menu. User-defined Key 2 High Saves energy using the high-efficiency SMART ENERGY SAVING feature.
- Page 27 Please set the Input Compatibility Version to match the version of the connected external device. 2.0/1.4 HDMI Input Compatibility If you want to use the HDR, select the Input Compatibility Version to 2.0. Version 1.4/1.2/1.1 DisplayPort If you want to use the HDR, select the Input Compatibility Version to 1.4. This feature lets you set the sound generated from Buzzer when your monitor powers on.
-
Page 28: Troubleshooting
Have you installed the display driver? • Be sure to install the display driver from our web site: http://www.lg.com. • Make sure to check if the graphics card supports Plug and Play function. Some features are disabled. - Page 29 The screen retains an image. Does image sticking occur even when the • Displaying a still image for a prolonged time may cause damage to the screen, resulting in the retention of the image. monitor is turned off? • To extend the lifetime of the monitor, use a screensaver. Screen display is unstable and shaky.
- Page 30 The display color is abnormal. Does the display appear discolored • Set the color to 24 bit (true color) or higher. In Windows, go to Control Panel > Display > Menu > Color Quality. (The settings (16 colors)? may differ depending on the operating system (OS) you use.) Does the display color appear unstable or •...
-
Page 31: Product Specification
PRODUCT SPECIFICATION 24GS60F LCD Screen Color Depth 8-bit color is supported. Resolution Max Resolution 1920 x 1080 @ 180 Hz Recommended Resolution 1920 x 1080 @ 180 Hz Power Sources Power Rating 19 V 1.6 A AC/DC Adapter ADS-45SQ-19-3 19032E type, manufactured by SHENZHEN HONOR ELECTRONIC Or ADS-45FSQ-19 19032EPG-1 type, manufactured by SHENZHEN HONOR ELECTRONIC Or ADS-45FSQ-19 19032EPK-1 type, manufactured by SHENZHEN HONOR ELECTRONIC Or ADS-45FSQ-19 19032EPCU-1 type, manufactured by SHENZHEN HONOR ELECTRONIC... - Page 32 Dimensions Monitor Size (Width x Height x Depth) With Stand 540.8 x 408.9 x 180.5 (mm) 21.2 x 16 x 7.1 (inches) Without Stand 540.8 x 323.8 x 42.8 (mm) 21.2 x 12.7 x 1.6 (inches) Weight (Without Packaging) With Stand 4.0 kg (8.8 lbs) Without Stand 3.5 kg (7.7 lbs)
- Page 33 PRODUCT SPECIFICATION 27GS60F LCD Screen Color Depth 8-bit color is supported. Resolution Max Resolution 1920 x 1080 @ 180 Hz Recommended Resolution 1920 x 1080 @ 180 Hz Power Sources Power Rating 19 V 2.0 A or 19 V 1.7 A AC/DC Adapter ADS-45SN-19-3 19040G type, manufactured by SHENZHEN HONOR ELECTRONIC Or ADS-45SQ-19-3 19040E type, manufactured by SHENZHEN HONOR ELECTRONIC...
- Page 34 Environmental Conditions Operating Conditions Temperature 0 °C to 40 °C (32 °F to 104 °F) Humidity Less than 80 % Storing Conditions Temperature -20 °C to 60 °C (-4 °F to 140 °F) Humidity Less than 85 % Dimensions Monitor Size (Width x Height x Depth) With Stand 614.2 x 454.2 x 224.8 (mm) 24.1 x 17.8 x 8.8 (inches)
-
Page 35: Factory Support Mode
Factory Support Mode HDMI Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.940 800 x 600 37.879 60.317 1024 x 768 48.363 60.004 1280 x 1024 79.976 75.025 1920 x 1080 67.500 60.000 Recommended Timing 1920 x 1080 67.500 60.000... - Page 36 Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.940 800 x 600 37.879 60.317 1024 x 768 48.363 60.004 1280 x 1024 79.976 75.025 1920 x 1080 67.500 60.000 1920 x 1080 67.500 60.000 1920 x 1080 84.364 74.990...
-
Page 37: Hdmi Timing (Video)
HDMI Timing (Video) Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Remarks 480P 31.5 720P 1080P 67.5 1080P Only HDMI 2.0 and HDMI Freesync Power LED Mode LED Color On Mode Red (For a few seconds) Sleep Mode (Standby Mode) Off Mode... -
Page 38: Beep Guide
Beep Guide Menu Location Menu Location Menu Location Game Mode 3 2 1 Game Adjust - Response Time Picture Adjust - Contrast Slider Game Mode - Gamer1 Game Adjust - Response Time - Faster 2 4 1 Picture Adjust - Sharpness Game Mode - Gamer2 Game Adjust - Response Time - Fast 2 4 2... - Page 39 Menu Location Menu Location Menu Location 3 6 3 Picture Adjust - Black Level - Low 3 8 2 General - Language - Swedish 5 1 6 Picture Adjust - R/G/B - Blue Slider Picture Adjust - DFC General - Language - Finnish 5 1 7 Picture Adjust - Six Color Picture Adjust - DFC - On...
- Page 40 Menu Location Menu Location General - User-defined Key 2 - Game General - Input Compatibility 5 3 2 5 8 1 Mode Version(HDMI) - 2.0 General - Input Compatibility General - User-defined Key 2 - Crosshair 5 3 3 5 8 2 Version(HDMI) - 1.4 General - User-defined Key 2 - Black 5 3 4...
-
Page 41: Limited Warranty (Usa)
The notice must provide your name, address, and telephone number; identify the product that is the subject of the claim; and describe the nature of the claim and the relief being sought. If you and LG are unable to resolve the dispute within 30 days, either party may proceed to file a claim for arbitration. - Page 42 Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar days from the date of the first consumer purchaser’s purchase of the product by either: (i) sending an e-mail to optout@lge.
- Page 43 You may only opt out of the dispute resolution procedure in the manner described above (that is, by e-mail or telephone); no other form of notice will be effective to opt out of this dispute resolution procedure. Opting out of this dispute resolution procedure will not affect the coverage of the Limited Warranty in any way, and you will continue to enjoy the full benefits of the Limited Warranty.
-
Page 44: Limited Warranty (Canada)
The notice must provide your name, address, and telephone number; identify the product that is the subject of the claim; and describe the nature of the claim and the relief being sought. If you and LG are unable to resolve the dispute within 30 days of LG’s receipt of the Notice of Dispute, the dispute shall be resolved by binding arbitration in accordance with the procedure set out herein. - Page 45 Agreement to Binding Arbitration and Class Action Waiver. Upon failure to resolve the dispute during the 30 day period after LG’s receipt of the Notice of Dispute, you and LG agree to resolve any claims between you and LG only by binding arbitration on an individual basis, unless you opt out as provided below, or you reside in a jurisdiction that prevents full application of this clause in the circumstances of the claims at issue (in which case if you are a consumer, this clause will only apply if you expressly agree to the arbitration).
- Page 46 (i) on the product; or (ii) online by accessing https://www.lg.com/ca_en/findmodel_serial/ ). In the event that you “Opt Out” , the law of the province or territory of your residence shall govern this Limited Warranty and any disputes between you and LG except to the extent that such law is preempted by or inconsistent with applicable federal or provincial/territorial law.
- Page 47 Supplier’s Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. Address 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ 07632 E-mail lg.environmental@lge.com The model and serial number of the product are located on the back and on one side of the product.
