Shark NAVIGATOR LIFT-AWAY NV391 Quick Start Manual

Please be sure to read the enclosed Shark® Owner's Guide prior to using your unit.
QUICK START GUIDE
WHAT'S INSIDE
A Handle E
B Motorized Floor Nozzle F
C Wand G
D Crevice Tool H

ASSEMBLY

1
(Click)
B
Place the pod
onto floor nozzle.
3
(Click)
Slide accessory
holder onto
extension wand.
NAVIGATOR
LIFT-AWAY ®
Wide Upholstery Tool
Dusting Brush
Pet Power Brush
Multi-Angle Dusting Brush
C
2
(Click)
Slide wand into
base of pod.
A
4
(Click)
Insert handle into top of
wand, then attach hose
connector on back of pod.
™

MAINTENANCE

Empty dust cup after each use
To remove the Hold dust cup
over a trash bin
dust cup, undo
the latches on the and press the
sides by lifting empty-release
them up and latch on the
outwards. bottom.

Cleaning Filters

Foam filter
Felt filter
HEPA filter
Pre-Motor (foam and felt):
With the dust cup removed, take out the foam and felt filters
and rinse them with water. Tap loose dirt off filters between
washes as needed.
Post-Motor (HEPA):
To access the HEPA filter, reach under the grill, pull the tab
forward and pull the grill away from the vacuum. Remove
and rinse the HEPA filter.

Easy brushroll maintenance

Use a coin to open the 2
locks on the bottom of the
floor nozzle.
Press top dust
cup release latch
to access dust
screen and remove
built-up debris
as required.
TIP:
Wash filters every
3 months to keep
the suction strong.
Rinse filters and allow
to air-dry completely.
Tap loose dirt from
foam filters as needed
between washes.
Remove any string, carpet
fibers, or hair that may
be wrapped around the
brushroll.
