  • Page 1 Hydro Brush 36 Model Owner/Operator Manual 926518 – Hydro Brush 36 12V Návod k obsluze (SN 000101 +) Betriebsanleitung Instruktionsbog Manual del propietario/operador Käyttöohjekirja Manuel du propriétaire/utilisateur Manuale del proprietario/operatore Gebruikshandleiding Brukerhåndbok Instrukcja obslugi / operatora Instruktionsbok • 9/15 04956600A...
  • Page 2 PRZEPISAMI EC WYDANA PRZEZ PRODUCENTA – EG-DEKLARATIONEN OM ÖVERENSSTÄMMELSE UTFÄRDAD AV TILLVERKAREN We the undersigned, ARIENS COMPANY, certify that: Wij, de ondergetekende, ARIENS COMPANY, certificeren dat: My, nížepodepsaní, ARIENS COMPANY, prohlašujeme, že: Der Unterzeichnete, ARIENS COMPANY, bescheinigt, dass: Undertegnede, ARIENS COMPANY, attesterer, at: Nosotros, los abajo firmantes, ARIENS COMPANY, certificamos que: Allekirjoittanut, ARIENS COMPANY, vakuuttaa, että: Nous,...
  • Page 3 Garantie (Bewaarder van Technische Fiche) / Päivämäärä – Date – Správce shody výrobku a záruky (správce technické Data – Datum – Dato – Ariens Company dokumentace) / Director Product Conformance & Data – Datum Brillion, WI 54110-1072 Warranty (Archivar der technischen Akte) / Direktør for produktoverholdelse &...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS WELCOME ..... . 1 STORAGE ..... . . 20 Short Term.

  • Page 5: Welcome

    WELCOME Original Instructions. Congratulations on your purchase and welcome to the Ariens family! Every power brush in the Ariens lineup is designed for long-lasting and unsurpassed performance. We are confident your machine will be part of your family for many years to come.

  • Page 6: Safety

    WILL RESULT in death or penalties. Emission controls and components serious injury. can only be adjusted by an Ariens Company dealer or an authorized engine 2. Warning manufacturer's service center. Contact your Ariens Company Equipment Retailer...

  • Page 7: Safety Decals

    SAFETY DECALS Keep people away from unit The safety decals on your unit are visual while operating. Keep reminders of the important safety information children out of work area in this manual. All messages on your unit and under watchful care of a must be fully understood and carefully responsible adult.

  • Page 8: Safety Rules

    NEVER allow children to operate or play on or near the equipment. NEVER allow adults NEVER use your hands to to operate the equipment without proper clear blockages. instruction. Keep the area of operation clear of all persons, particularly small children. Be alert and shut off unit if children enter area.
  • Page 9 Handle fuel with care; it is highly flammable. DO NOT touch parts which might be hot from operation. Allow parts to cool before • Use an approved fuel container. attempting to maintain, adjust or service. • NEVER add fuel to a running engine or hot engine.
  • Page 10 Disengage attachment when not in use and Keep unit free of ice or other debris. Clean when traveling from one work area to up oil or fuel spills. another. ALWAYS keep protective structures, guards, Disengage power to the attachment when and panels in good repair and secured in unit is transported or not in use.
  • Page 11 Fuel Accessories Remove fuel before separating brush attachment from frame. Ensure unit is Use only Ariens Company-recommended secure and will not tip during maintenance. attachments or accessories that are designed for your unit and that are DO NOT run engine in an enclosed area.

  • Page 12: Controls & Features

    CONTROLS & FEATURES Figure 3 1. Traction Drive Clutch Lever 12. Choke Control Lever 2. Attachment Clutch Lever 13. Throttle Control Lever 3. Speed Selector Lever 14. Fuel Valve 4. Brush Lock Trigger 15. Engine Key 5. Brush Guard 16. Oil Fill/Dipstick 6.

  • Page 13: Engine Key

    THROTTLE CONTROL LEVER WARNING: Read and See Figure 7. understand the Safety section Controls engine speed. before proceeding. See Figure 3 for all controls and features locations. ENGINE KEY See Figure 4. Controls power to the engine. The key cannot Idle be removed when in run position.

  • Page 14: Traction Drive Clutch Lever (Left Side)

    TRACTION DRIVE CLUTCH OPERATION LEVER (LEFT SIDE) See Figure 10. Allows unit to travel forward and in reverse. WARNING: AVOID INJURY. Read and understand the Safety section before proceeding. IMPORTANT: All references to left, right, front or rear are given from the perspective of operator in operator’s position, facing the direction of forward travel.

  • Page 15: Operate Unit

    SET BRUSH HEIGHT 5. Gradually turn choke off as engine warms. CAUTION: AVOID INJURY. If Manual Start brush height is too low, brush 1. Turn fuel valve to on position can drive machine rearward 2. Move choke control lever to on position. when attachment clutch is 3.

  • Page 16: Set Brush Angle

    2. Raise brush: a. Remove lynch pins from caster shaft tops. b. Remove desired amount of height adjuster clips from caster shaft tops and install onto lower caster shaft ends. c. Turn height adjuster clips so they DO NOT align with flat side of caster shafts.

  • Page 17: Transport Unit

    6. Disconnect brush lock cable from J-clamp WARNING: Read and on engine mount. understand the Safety section before proceeding. Your Ariens dealer can provide service and adjustments to keep your unit operating at peak efficiency. Contact an authorized engine manufacturer’s service center for engine service.
  • Page 18 See Figure 18. 7. Remove hardware securing brush lock trigger to handlebar and allow trigger to rest on brush attachment. 1. Machine Screw 2. Lock Washer 1. Hex Head Screw 3. Brush Lock Trigger 2. Mount Rod Figure 18 3. Mount Bracket Figure 19 WARNING: ALWAYS support unit frame and brush attachment...

  • Page 19: Return Unit To Operating Position

    3.2 mm (1/8") Figure 21 9. Reinstall belt cover and tighten hardware. 10. Reinstall brush lock trigger onto 1. Bottom Cover handlebars and route brush lock cable 2. Attachment Sheave through J-clamp on engine mount. 3. Engine 11. Adjust attachment clutch. See Adjust Attachment Clutch on page 18.

  • Page 20: Maintenance Schedule

    Use a clip-on chuck and extension SERVICE PARTS hose long enough to allow you See your Ariens dealer to purchase service to stand to one side. parts for your unit. • DO NOT mount a tire without...

  • Page 21: Lubricate Unit

    See Figure 23. high ambient temperatures, dusty conditions or airborne debris). LUBRICATE UNIT Ariens recommends using Ariens Hi-Temp Grease or equivalent (see Service Parts on page 16) to lubricate fittings. Lubricate each season or every 25 hours of operation. IMPORTANT: Wipe each fitting clean before and after lubrication.

  • Page 22: Adjustments

    9. Reinstall hairpin in trunnion. 10. Tighten jam nut against trunnion. 11. Lower unit to ground. 1. Bell Crank Figure 25 2. Hairpin 3. Trunnion 3. Return unit to operating position. See 4. Shift Rod Return Unit to Operating Position on 5.

  • Page 23: Adjust Traction Drive Clutch

    Check Belt Finger Clearance See Figure 29. With the attachment clutch and traction clutch engaged, the belt finger located opposite the belt idler must be less than 3.2 mm (1/8") from belts, but must not touch the belts. To adjust belt finger: 1.

  • Page 24: Storage

    Add the stabilizer to the frame. See Figure 31. container before adding fuel. a. Add Ariens fuel stabilizer (see Service Parts on page 16) or equivalent according to manufacturer's instructions to the fuel tank and any fuel containers with remaining fuel.

  • Page 25: Start-Of-Season Fuel Preparation

    Before opening the fuel valve for the first time after long-term storage, add fresh, stabilizer- treated fuel to the fuel tank and any fuel containers with remaining fuel. ACCESSORIES See your Ariens dealer for a complete list of compatible accessories and attachments for your unit. Description Part No.

  • Page 26: Troubleshooting

    Move choke control lever to off position. and start engine. See Move Unit Manually on page 12. Engine is faulty. See your Ariens dealer or authorized engine manufacturer’s service center. Fuel mixture is too rich. Move choke control lever to off position.
  • Page 27 See your Ariens dealer. Attachment drive belt is loose or Replace belt or adjust attachment control damaged. cable. See your Ariens dealer. Belt squeals Attachment clutch needs See Adjust Attachment Clutch on continuously. adjustment. page 18.

  • Page 28: Specifications

    SPECIFICATIONS Model Number 926518 Engine Engine Model Subaru EX30 287 (17.52) Displacement – cc (in Maximum RPM – No Load 3800 ± 100 Starter 12V Electric and Recoil Fuel Refer to Engine Manual Tank Capacity – L (qt) 6.1 (6.3) Brush Clearing Width –...

  • Page 29: Warranty

    Chore ® ® Performing Equipment Limited Warranty Warranty Ariens Company (Ariens) warrants to the original purchaser that Ariens, Gravely, Parker, and Countax ® ® brand chore performing equipment (including Sno-Thro and Sno-Tek equipment) purchased on or after 1/1/2015 will be free from defects in material and workmanship for the time period noted in the chart below.
  • Page 30 Register the product immediately at the time of sale. If the dealer does not register the product, the customer must complete the product registration card in the literature package and return it to Ariens Company, or register the unit online at www.ariens.com, www.gravely.com, www.countax.com or www.parkersweeper.com.
  • Page 31 Exclusions – Items Not Covered by This Warranty • Parts that are not genuine Ariens, Gravely, Parker or Countax service parts are not covered by this warranty and may void the warranty. • Damages resulting from the installation or use of any part, accessory, or attachment which is not approved by the Ariens Company for use with product(s) identified herein are not covered by this warranty.
  • Page 32 655 West Ryan Street Brillion, WI 54110 ariensstore.com ariens.custhelp.com...
