- Page 1 Power Brush 36 With Hydrostatic Drive Operator’s Manual Manuel du Utilisateur Models 926075 – Hydro Brush 36 12V (SN 000101 +) ENGLISH • 05175500B 12/19 FRANÇAIS Printed in USA...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WELCOME ..... . 1 Transport Unit ....13 Adjust Engine Air Cleaner . -
Page 3: Welcome
WELCOME Congratulations on your purchase and welcome to the Ariens family! Every machine in the Ariens lineup is designed for long-lasting and unsurpassed performance. We are confident your machine will be part of your family for many years to come. -
Page 4: Safety
• OBEY THE MESSAGE! penalties. Emission controls and components can only be adjusted by an Ariens dealer or SIGNAL WORDS an authorized engine manufacturer's service The safety alert symbol above and signal center. Contact your Ariens Equipment... -
Page 5: Safety Decals
4. Notice Safety Decal Descriptions NOTICE: Indicates information or procedures 1. WARNING! that are considered important but not hazard related. If not followed, property damage could result. WARNING! 5. Important IMPORTANT: Indicates general reference information worthy of special attention. SAFETY DECALS NEVER direct discharge towards persons or property The safety decals on your unit are visual... -
Page 6: Safety Rules
SAFETY RULES The following safety instructions are based on the B71.3 specifications of the American Be sure to engage the National Standards Institute in effect at the traction drive clutch first. time of production. Engaging the attachment clutch before traction drive Training clutch can cause the unit to Read, understand and follow all instructions... - Page 7 Handle fuel with care; it is highly flammable. DO NOT touch parts which might be hot from operation. Allow parts to cool before • Use an approved fuel container. attempting to maintain, adjust or service. • NEVER add fuel to a running engine or hot engine.
- Page 8 Disengage attachment when not in use and Keep unit free of ice or other debris. Clean when traveling from one work area to up oil or fuel spills. another. ALWAYS keep protective structures, guards, Disengage power to the attachment when and panels in good repair and secured in unit is transported or not in use.
- Page 9 Use a slow speed to avoid stops or shifts on Towing/Transporting slopes. Avoid starting or stopping on a ALWAYS stop engine, remove key and close slope. DO NOT park unit on a slope unless fuel valve or drain fuel when transporting absolutely necessary.
-
Page 10: Controls & Features
CONTROLS & FEATURES Figure 3 1. Traction Drive Clutch Lever 12. Choke Control Lever 2. Attachment Clutch Lever 13. Throttle Control Lever 3. Speed Selector Lever 14. Fuel Valve 4. Brush Lock Trigger 15. Ignition Key 5. Brush Guard 16. Oil Fill/Dipstick 6. -
Page 11: Engine Key
CHOKE CONTROL LEVER WARNING: Read and See Figure 6. understand the Safety section Controls airflow to the engine. before proceeding. See Figure 3 for all controls and features locations. IGNITION KEY See Figure 4. Controls power to the engine. The key cannot be removed when in run position. -
Page 12: Speed Selector Lever
SPEED SELECTOR LEVER TRACTION DRIVE CLUTCH LEVER (LEFT SIDE) See Figure 8. Controls the speed of forward and reverse See Figure 10. travel. Allows unit to travel forward and in reverse. Figure 10 BRUSH LOCK TRIGGER See Figure 11. Figure 8 Unlocks and locks brush to change clearing ATTACHMENT CLUTCH LEVER angle. -
Page 13: Operation
E85 blended fuels; the engine is not E20 / E30 / E85 compatible. The maximum NOTICE: Stop brush when traveling between recommended ethanol content is 10%. Ariens work areas. recommends using a quality fuel stabilizer in NOTICE: When the unit is turned left or right, all fuel. -
Page 14: Set Brush Height
SET BRUSH HEIGHT c. Install spacers onto caster shaft tops and reinstall lynch pins. 2. Raise brush: CAUTION: AVOID INJURY. If brush height is too low, brush a. Remove lynch pins from caster shaft can drive machine rearward tops. when attachment clutch is b. -
Page 15: Move Unit Manually
TRANSPORT UNIT 1. Stop engine, remove key and close fuel valve. 2. Secure unit chassis to transport vehicle. NOTICE: NEVER secure from rods or linkages that could be damaged. For Best Sweeping Results • Run in an overlapping series of paths. •... -
Page 16: Maintenance
Safety section while operating in normal temperatures. before proceeding. Normal Position Your Ariens dealer can provide service and adjustments to keep your unit operating at peak efficiency. Contact an authorized engine manufacturer’s service center for engine service. - Page 17 1. Machine Screw 2. Lock Washer 3. Brush Lock Trigger Figure 20 WARNING: ALWAYS support 1. Belt Finger unit frame and brush attachment 2. Hex Bolt when loosening hardware 3. Locking Washer holding them together. 4. Flat Steel Washer 5. Attachment Drive Belt IMPORTANT: Support tractor / frame so it will 6.
-
Page 18: Return Unit To Operating Position
See Figure 22. 6. Reinstall belt finger and secure with two flat steel washers, two locking washers and two hex bolts. Tighten hardware. CAUTION: AVOID ENGINE DAMAGE. Do not leave unit in 7. Torque hardware installed in step 4 to service position for longer than 36.6 N•m –... -
Page 19: Maintenance Schedule
Drive Clutch on page 21. Refer to the Service Manual for your unit for more information SERVICE PARTS about clutch repairs. See your Ariens dealer to purchase service CHECK TIRE PRESSURE parts for your unit. Keep tires inflated to pressure listed on tire Description Part No. -
Page 20: Clean Battery
LUBRICATE UNIT Ariens recommends using Ariens Hi-Temp Grease or equivalent (see Service Parts on page 17) to lubricate fittings. Lubricate each season or every 25 hours of operation. IMPORTANT: Wipe each fitting clean before and after lubrication. -
Page 21: Adjustments
ADJUSTMENTS WARNING: Read and understand the Safety section before proceeding. ADJUST SPEED SELECTOR LEVER See Figure 27. 1. Stop engine, remove key and wait for all moving parts to stop and for hot parts to cool. 2. Place unit on blocks with wheels off the ground. -
Page 22: Adjust Attachment Clutch
1. Bell Crank 2. Hairpin 3. Trunnion 1. Attachment Clutch Cable 4. Shift Rod 2. Cable Adjustment Barrel 5. Jam Nut 3. Jam Nut Figure 27 Figure 28 ADJUST ATTACHMENT CLUTCH 6. With the attachment clutch disengaged, check that the attachment idler arm lightly WARNING: AVOID INJURY. - Page 23 Check Attachment Idler Arm Check Belt Finger Clearance Clearance See Figure 31. See Figure 30. With the attachment clutch and traction clutch engaged, the belt finger located opposite the 1. Place unit in service position and remove belt idler must be less than 3.2 mm (1/8") bottom cover.
-
Page 24: Adjust Traction Drive Clutch
ADJUST TRACTION DRIVE CLUTCH See Figure 32. 1. Stop engine, remove key and wait for all moving parts to stop and for hot parts to cool. 2. Disconnect spark plug wire. 3. Remove hardware retaining left side of belt cover. 4. -
Page 25: Troubleshooting
Engine on page 11. Battery is not charged or is faulty. Charge or replace battery. Engine will not crank / start. See your Ariens dealer or authorized engine manufacturer’s service center. Engine is faulty. See your Ariens dealer or authorized engine manufacturer’s service center. - Page 26 TROUBLESHOOTING Problem Probable Cause Correction Attachment clutch not adjusted Adjust attachment clutch. See Adjust properly. Attachment Clutch on page 20. Debris is caught in brush. Stop engine, remove key and wait for all moving parts to stop and for hot parts to cool.
-
Page 27: Storage
ACCESSORIES SHORT TERM 1. Tighten all hardware to correct See your Ariens dealer for a complete list of specifications. compatible accessories and attachments for 2. Inspect unit for visible signs of wear or your unit. -
Page 28: Specifications
SPECIFICATIONS Model Number 926075 Engine Engine Model Kohler CH395 Gross Torque* – N•m (lb-ft) 18.8 (13.9) 277 (16.9) Displacement – cm Maximum RPM – No Load 3750 ± 100 Starter 12V Electric and Recoil Fuel Refer to Engine Manual Tank Capacity – L (qt) 7.0 (7.4) -
Page 29: Warranty
“Commercial Use.” If any product is rented or leased, then the duration of these warranties shall be 90 days after the date of purchase. An authorized Ariens dealer will repair any defect in material or workmanship, and repair or replace any defective part, subject to the conditions, limitations and exclusions set forth herein. Such repair or replacement will be free of charge (labor and parts) to the original purchaser;... - Page 30 Exclusions – Items Not Covered by This Warranty • Parts that are not genuine Ariens service parts are not covered by this warranty and may void the war- ranty if the parts result in premature wear or damage to the product.
- Page 31 Parts and Accessories Service replacement parts and non-serialized accessories are warranted for 90 days from date of purchase. Parts and accessories must be installed by an authorized Ariens dealer to be covered. Labor is not included. Customer Responsibilities Register the product immediately at the time of sale. If the dealer does not register the product, the customer must register the unit on-line at www.ariens.com.
- Page 32 Disclaimer AriensCo may from time to time change the design of its products. Nothing contained in this warranty shall be construed as obligating the AriensCo to incorporate such design changes into previously manufactured products, nor shall such changes be construed as an admission that previous designs were defective. Limitation of Remedy and Damages AriensCo liability under this warranty, and under any implied warranty that may exist, is limited to repair of any defect in workmanship, and repair or replacement of any defective part.
- Page 33 655 West Ryan Street Brillion, WI 54110 www.ariens.com parts.ariens.com...
