  • Page 1 User manual...
  • Page 2 Índice Unpacking and assembly 10. Display operation LCD C300S 1. Box contents 11. Operation of the throttle 2. Introduction of the set (optional) (opcional) handlebar 3. Packed in original box Folding & Unfolding Start up 12. Unfolding the bike 4. Handlebar adjustment 13.

  • Page 3: Box Contents

    Unpacking and assembly Box contents The assembly of your Flebi Supra ECO is very easy and fast! - Take your Supra ECO out of the box - Remove the protections - Unfold the bike (see 12) - Insert the handlebar assembly (see 2)
  • Page 4 Unpacking and assembly Introduction of the set handlebar To install the assembly made up of the handlebar and the telescopic seatpost that allows you to adjust the height, you have to insert it into the handlebar stem before placing it in its natural position, following the guides that you will find.
  • Page 5 Unpacking and assembly Packed in original box If you have to repackage your bike in its original box to send it to Flebi’s technical service, we recommend that you follow these steps: - Cover the parts with protections - Remove the seat post...

  • Page 6: Handlebar Adjustment

    Start up Handlebar adjustment You can adjust the height of the handlebar to accommodate your height. To do this, open the telescopic closure and place the seatpost in the desired position, taking care not to exceed the safety mark. Then tighten the clasp firmly so it doesn't move.

  • Page 7: Saddle Adjustment

    Start up Saddle adjustment You can also adjust the height of the saddle to perfectly adapt it to your height. To adjust the hardness you must tighten the thread according to your tastes. Check that it is not too loose or the seatpost will move.

  • Page 8: Brake Adjustment

    Start up Brake adjustment If your Flebi Supra ECO had a loose brake pad, must make approximation of it to place it. It is done by manually pressing the brake so that it goes to its initial position, seeking the greatest contact without rubbing the tire.

  • Page 9: Tire Inflation

    Start up Tire inflation To check the amount of air in the tires, remember that the Supra ECO has 3.5 bar of pressure, so it is convenient to use an inflator with a pressure gauge. The Supra ECO is very comfortable,...
  • Page 10 Start up Chain placement To return the chain of your Flebi Supra ECO to its natural position. You have to the chain to the pinion and pay attention to the pulley, carrying the crowns in the exact way that we tell you in the explanatory video.

  • Page 11: Battery Recharge

    Electrical operation Battery recharge The Supra ECO battery is inside the frame, for which you will have to plug the charger into the mains, and the charger connector battery recharge connector. The charging point is located in the lower part of the frame, under a rubber cover that must be removed to access the connector.
  • Page 12 Electrical operation Display operation LCD C300S El The display is activated by pressing the power button located in the center of it (M). Once turned on, you will see several indicators: remaining battery level, pedal assistance level (1-6), speed accumulated km. If you press the minus button in any of the levels, the “Walking Mode”...
  • Page 13 Electrical operation Operation of the throttle (optional) Unlike the PAS (Pedal Assist System), the accelerator makes the motor work without the need to pedal. In order for the trigger-type accelerator to work, you must turn on the display and set the assistance level to 0. From this state, you must press the –...
  • Page 14 Folding & Unfolding Unfolding the bike The steps to deploy your Flebi Supra ECO are: - Place the seat post inside the frame - Unfold the frame, tighten the front closure and place the safety (see 17) - Raise the stem of the handlebar, close the...

  • Page 15: Folding The Bike

    Folding & Unfolding Folding the bike The steps to fold your Flebi Supra ECO are: - Release the swingarm by pressing the lever located on the frame next to the seat post. - Fold the pedals (see 16) - Remove the safety and release the front...

  • Page 16: Swingarm Operation

    Folding & Unfolding Swingarm operation One of the main advantages of the Supra ECO is its comfortable and effective folding mechanism, since with a simple movement you can semi-fold and reduce its length by half, very practical for easy transport. To do this, you just have to act on the folding lever located on the frame next to the seat post.
  • Page 17 Folding & Unfolding Opening/Closing the frame To open or close the front of the frame, you just have to remove the safety in case of opening it and put it in case of closing it. And release the lever of the fold out to open it, and press it inward to close it.
  • Page 18 Folding & Unfolding Folding/Unfolding the pedals To fold or unfold each pedal you must press the control outwards and, at the same time, fold the pedal inwards (folded) or outwards (unfolded) until the blockage is noticed. Video: https://youtu.be/9l71mLApJq8...
  • Page 19 Folding & Unfolding Handlebar folding mechanism First make sure that the cables are not tangled or too tight due to fixed handlebar height. To fold the handlebar stem, you must remove the lever lock and open it by pressing outwards to then lower the stem.
  • Page 20 Folding & Unfolding Quick fold easy-folding This folding system is an alternative to the conventional one, which has the advantage of being faster (2 steps instead of 3), and reducing the width of the folded bike as much as possible, sacrificing length.
