- Page 1 Manual for HE-XRZ2 2.4GHz Modem COM Module...
- Page 2 PAGE 2 19 MAR 2007 MAN0943-01 MAN0943-...
- Page 3 PAGE 3 PREFACE This manual explains how to use the HE-XRZ2 XLe 2.4GHz Modem COM Module. Copyright (C) 2006 Horner APG, LLC., 59 South State Avenue, Indianapolis, Indiana 46201. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in...
-
Page 4: Limited Warranty And Limitation Of Liability
It is the sole responsibility of the system designer utilizing the HE-XRZ2 XLe 2.4GHz Modem COM Module to appropriately design the end system, to appropriately integrate the HE-XRZ2 XLe 2.4GHz Modem COM Module and to make safety provisions for the end equipment as is usual and customary in industrial applications as defined in any codes or standards which apply. -
Page 5: Table Of Contents
MAN0943-01 19 MAR 2007 PAGE 5 Table of Contents LIMITED WARRANTY AND LIMITATION OF LIABILITY ............. 4 CHAPTER 1: SAFETY / COMPLIANCE ..................6 Safety Warnings and Guidelines ..................6 CHAPTER 2: INTRODUCTION ..................... 8 Overview ..........................8 Technical Support Contacts ....................8 CHAPTER 3: INSTALLATION PROCEDURE ................ -
Page 6: Chapter 1: Safety / Compliance
PAGE 6 19 MAR 2007 MAN0943-01 CHAPTER 1: SAFETY / COMPLIANCE Safety Warnings and Guidelines When found on the product, the following symbols specify: Warning: Consult user documentation. Warning: Electrical Shock Hazard. WARNING: This equipment is approved only for mobile and base station transmitting devices. Antenna(s) used for this transmitter must be installed to provide a separation distance of at least 30 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. - Page 7 • immediately if defective. 1.2 FCC Compliance The HE-XRZ2 contains a MaxStream OEM RF module FCC ID: OUR-XBEEPRO The enclosed device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (i.) this device may not cause harmful interference and (ii.) this device must accept any interference, including interference that may cause undesired operation.
-
Page 8: Chapter 2: Introduction
HE-XRZ2 deactivates the MJ1 serial port. However, support is provided to select which device is currently active through ladder control. The HE-XRZ2 is provided connection to the internal handshake lines of RTS and CTS. As such, the OPEN function block handshake parameter of hardware is functional if the HE-XRZ2 is programmed appropriately. -
Page 9: Chapter 3: Installation Procedure
MAN0943-01 19 MAR 2007 PAGE 9 CHAPTER 3: INSTALLATION PROCEDURE Installation Procedure Disconnect all power from the XLe unit including I/O power. Remove the four screws on the back of the XLe unit and remove the back cover. The back cover can be discarded or saved, but it will be replaced with the extended back cover that ships with the communication add-on. -
Page 10: Chapter 4: Operation
Failure to set HEXRZ2 in the I/O Configuration when attempting to download an application that uses an OPEN function block set to Radio generates a download error. Even if the HE-XRZ2 is not used by the application, the HEXRZ2 must still be set in the I/O Configuration to prevent an I/O Configuration error on the XLe. - Page 11 HE-XRZ2. The factory default setting of these parameters are 9600, 8, N, and 1. It is possible to program the HE-XRZ2 for a different baud rate and frame protocol and save those values to non-volatile memory; however, it is left to the user to record those values and set the OPEN function block appropriately.
