- Page 1 USER MANUAL BPE PowerDepot 5.12kWh Wall Mounted Lithium Battery...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION General Safety Personal Safety Electrical Safety Environment Safety PRODUCT INFORMATION Battery Overview Apperance Front Panel Dimensions Capacity Options Parallel Communication Recommended Settings WARNINGS SPECIFICATIONS... -
Page 3: Safety Information
1 - SAFETY INFORMATION 1.1 General Safety Please fully read the safety precautions in this document and observe all the safety instructions on the equipment. The “DANGER”, “WARNING”, and “NOTICE” statements in this document do not cover all the safety instructions. They are only supplements to the safety instructions. In order to ensure human safety and equipment functionality, use the appropriate symbols below to identify any potential issues with the equipment. -
Page 4: Electrical Safety
Personal Safety DANGER Do not install the battery in a location accessible to children or animals. » Do not touch the battery when charging as it may be hot. » Do not touch the battery terminals. » Do not stand, lean or sit on the battery. »... - Page 5 Electrical Safety DANGER Before installation, ensure that the equipment is intact or electric shock/fire » may occur. Do not connect or disconnect power cables when the battery is switched on as » this may cause electric arcs and sparks which can lead to fire or personal injury. Before connecting a power cable, check the positive and negative connectors »...
-
Page 6: Environment Safety
NOTICE Please use appropriate insulated tools for install and maintenance. » Please make sure all batteries are switched off when connected in parallel. » Please check the LED light sequence when the battery is switched on. » Please make sure the BMS communication cable is connected correctly between »... -
Page 7: Product Information
2 - PRODUCT INFORMATION 2.1 Battery Overview The BPE 5.12kWh Wall Mounted battery is a lithium battery pack which consists of long life LiFePO4 battery cells and integrated BMS. It can store and release electric energy based on the requirements of the inverter. It is mainly for home energy storage system. -
Page 8: Front Panel
2.3 Front Panel 1. Wall mount - Please mount bracket on the wall with six M8 bolts. Then lift the battery and attach to the bracket. 2. Wiring block - 2P (1P positive and 1P negative) power interface, printed by “+” and “-”, front mounted wiring method, positive and negative terminals are insulated by thermoplastic polyester (PBT) insulating sheets. - Page 9 CAN communication interface definition: 5. RS485 COMM to parallel battery - The BMS has RS485 communication for multiple battery pack connections and the baud rate is 19200bps. RS485 communication interface adopts 8P8C network cable interface. RS485 pin interface definition (RJ45-8P8C) Version 2: RS485/RS485 6.
- Page 10 7. RS485 COMM to parallel battery - The BMS has RS485 communication for multiple battery pack connections and the baud rate is 9600bps. RS485 commu-nication interface adopts 8P8C network cable interface. RS485 pin interface definition (RJ45-8P8C) 8. LED Indicators System Status Definition Sleeping...
- Page 11 9. Red alarm indicator with an audible alarm signals a fault. 10. SOC indicator, four green LED lights to display the real-time SOC capacity of the lithium battery pack. Status Charge Discharge 0 - 25% Flashing 25 - 50% Flashing 50 - 75% Flashing >75%...
-
Page 12: Dimensions
2.4 Dimensions 2.5 Capacity Options The battery can be connected in parallel for increasing power(kW) and energy(kWh). WARNING The maximum power (kW) is limited by the main cables from master battery to » inverter. Maximum number of batteries that can communicate in parallel is 4. »... -
Page 13: Parallel Communication
Lithium batteries function differently to lead-acid batteries, therefore the device in which you connect to the battery for charging and discharging, such as an inverter, MPPT charger controller or UPS should implement the recommended settings below. Setting BPE-LFP-5.12-WM Max. Charging Voltage 58.4V Floating Charging Voltage 58.4V Max. -
Page 14: Specifications
If the battery is not to be used for a long period, the battery pack needs to be charged to more than 80%, » turn off the power switch, and store it in a ventilated and dry environment. 4 - SPECIFICATIONS BPE-LFP-5.12-WM Model Usable Capacity 5.12kWh Voltage 51.2V... - Page 15 4.1 - Packing list Item Description Quantity Battery Pack 5.12kWh Battery pack 2m Power cables to Inverter Power Cables Earth cable Earth Cable Comms Cable 2m Ethernet cable Wall Bracket Wall Bracket and fixings Paralle Cables Included...
- Page 16 Badger Power Electronics Manchester Science Park Enterprise House Lloyd Street N Manchester M15 6SE United Kingdom Tel: +44 (0) 161 771 2377 E: hello@badgerpowerelectronics.com www.BadgerPowerElectronics.com...
