Logic board replacement kit

Advertisement

Quick Links

APPLICATION REQUIREMENTS:
WARNING
Model FDCL operator with charge circuit board incorporating
firmware versions 06-FDCL-500.
CAUTION
FUNCTION:
Replacement of the logic board in an FDCL.
REMOVE AC AND DC POWER
1. Disconnect AC power to the operator.
2. Open operator cover.
3. Remove DC power by disconnecting the battery connection.
REMOVE EXISTING BOARD
1. Match replacement logic board dip switch settings to the
current logic board. Refer to page 7, if needed.
2. Reference page 2 for mechanical assembly details. Remove all
the ends of the wires connected to the existing board and
neatly lay them over the side of the electrical box. Leave
jumper wires located on the board connected until new logic
board wiring.
3. Remove the nylon nuts (7) holding the logic board to the
electrical box and hold for reassembly of new board.
4. Remove the screw holding the heat sink to the electrical box
and hold for reassembly of new board.
5. Remove logic board from the box, leaving the existing
standoffs in place.
INSTALL NEW BOARD
1. Install the new logic board in the electrical box using the old
standoffs. Be sure to install in the same configuration as it was
removed.
2. Secure logic board in place with the nylon nuts (7) removed in
step 3.
3. Secure the heat sink to the electrical box with the screw
removed in step 4.
NOTE: For any additional help, refer to assembly drawing on
page 2.
I N S T A L L A T I O N I N S T R U C T I O N S
MODEL K79-13493-2
WARNING
To prevent possible SERIOUS INJURY or DEATH from
electrocution or fire, BEFORE proceeding:
WARNING
• Disconnect AC power at the fuse box.
• Disconnect DC power at the battery connection.
LOGIC BOARD WIRING
1 PHASE OPERATORS
Follow wiring directions on page 3, for additional help refer to the
wiring diagram on page 4.
3 PHASE OPERATORS
Follow wiring directions on page 5, for additional help refer to the
wiring diagram on page 6.
PROGRAM SETTINGS
Follow instructions on page 7 for optional control settings.
CONTROL CONNECTIONS
Follow instructions on page 8 for optional control settings.
HOW TO ORDER REPAIR PARTS
OUR LARGE SERVICE ORGANIZATION SPANS AMERICA
Installation and service information
are available 6 days a week
Call our TOLL FREE number:
1-800-528-2806
Monday through Friday 5 a.m. to 6 p.m. (MST)
Saturday 7 a.m. to 7:30 p.m. (MST)
www.liftmaster.com
1
Logic Board
Replacement Kit

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LiftMaster PROFESSIONAL K79-13493-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Chamberlain LiftMaster PROFESSIONAL K79-13493-2

  • Page 1 MODEL K79-13493-2 Logic Board Replacement Kit APPLICATION REQUIREMENTS: WARNING WARNING Model FDCL operator with charge circuit board incorporating firmware versions 06-FDCL-500. To prevent possible SERIOUS INJURY or DEATH from electrocution or fire, BEFORE proceeding: CAUTION WARNING FUNCTION: • Disconnect AC power at the fuse box. Replacement of the logic board in an FDCL.
  • Page 2 L O G I C B O A R D R E P L A C E M E N T A S S E M B LY Existing Screws Existing Nylon Nuts New Logic Board Existing Standoff...
  • Page 3 S I N G L E P H A S E W I R I N G NOTE: For additional help with wiring, refer to the wiring diagram on next page. EXISTING WIRES JUMPER WIRES MOTOR NOTE: Remove jumpers from original board and install them on NOTE: Steps 1 and 2 affect motor run direction.
  • Page 4 S I N G L E P H A S E W I R I N G D I A G R A M NOTES: 1. See Owner’s Manual for Dip Switch Functions and Programming Procedures. INTERNAL 230V - 1PH MOTOR CONNECTION 2.
  • Page 5 T H R E E P H A S E W I R I N G NOTE: For additional help with wiring, refer to the wiring diagram on next page. EXISTING WIRES JUMPER WIRES INFRARED SENSOR AND BATTERY INDICATORS NOTE: Remove jumpers from original board and install them on 1.
  • Page 6 T H R E E P H A S E W I R I N G D I A G R A M NOTES: INTERNAL 460V - 3 PH MOTOR CONNECTION • Place a jumper between J2-3 and J2-6 when 24 tooth door sprocket is used. •...
  • Page 7 O P T I O N A L C O N T R O L S E T T I N G S OPTIONAL CONTROL SETTINGS (0 SECOND DELAY) NOTE: All functions are independent of each other and do not require other control settings to be set at any certain configuration.
  • Page 8 24V Strobe IMPORTANT: All inputs must be contact only! This includes: Alarm Inputs, Control Inputs, Sensing Edges and Sensing Devices. For any other devices not mentioned, please consult the factory. © 2005, The Chamberlain Group, Inc. 01-32777 All Rights Reserved...
