- Page 1 APOLLO BATHING SYSTEM SERENITY™ Owners Manual and Operators Guide PO Box 219 450 Main St Somerset, WI 54025 800-247-5490 or cservice@apollobath.com...
- Page 2 FORWARD Thank You Thank you for purchasing the Serenity™ Whirlpool tub from the Apollo Corporation. The Serenity™ is designed and built to provide you with the innovation and dignity. System Operating Guide Objectives The primary purpose of this operating guide is to introduce the key information and features of the Serenity™...
-
Page 3: Table Of Contents
The Serenity™ System Operating Guide Table of Contents Table of Contents ………………………………………...3 Introducing the Serenity™………………………………..4 Key Features……………………………………….5 Critical Warnings…………………………………………6 Warning/Caution…………………………………..6 Electrical current warning…………………………6 Hot water warning…………………………………6 Wet floor warning………………………………….6 Infection/Disease warning…………………………6 Watch for legs and fingers………………………..6 Important Note……………………………………..6 Prior to Operating the Serenity™………………………..7 Understanding the Bathing Process………………………8 The Bathing Process……………………………….8 The Showering Process……………………………8... -
Page 5: Introducing The Serenity
System Operating Guide The Serenity™ Introducing the Serenity™... -
Page 6: Key Features
Serenity™ Whirlpool tub is a cut above the typical assisted living whirlpool tubs on the market. The Apollo Corporation is confident that once you’ve used the Serenity™ Whirlpool tub, you will agree that it is not only the top choice, but the only choice which includes all the features and benefits only available with the Serenity™. -
Page 7: Critical Warnings
To realize the maximum benefits from your bathing system, it is important that you read and understand all of the infor- mation in this manual. If you do not understand or require additional infor- mation, please contact the Apollo Corporation at (800) 247-5490. -
Page 8: Prior To Operating The Serenity
If a comfortable bathing temperature can not be reached or main- tained, immediately contact a qualified maintenance person, the manufacturer of the mixing valve, or if it is Apollo’s valve, the Apollo Corporation. ■... -
Page 9: Understanding The Bathing Process
Understanding the Bathing Process Apollo Serenity™ Whirlpool tub is meant to be a relaxing, pleasurable experience. By following these steps, you will receive the most possible enjoyment out of the bathing process. The Bathing Process 1. With the door open, sit on the built-in seat, then pivot your body until you are completely inside the tub. -
Page 10: Cleaning & Disinfecting Background
Power Clean™ is a heavy duty cleaner formulated to be compatible and enhance all disinfectants. Apollo’s Power Clean™ is recom- mended and safe for pre-cleaning soiled (bath scum) surfaces on all whirlpool bath tubs and shower walls. -
Page 11: Cleaning & Disinfecting Procedures
System Operating Guide The Serenity™ Cleaning & Disinfecting Procedures Without Automatic Disinfecting Option CAUTION Clean & Disinfect between each bath 1. Close door and thoroughly wash all inside surfaces of the tub Disinfectants are and door with Power Clean™ to remove all bath scum residue. hazardous and can be harmful to your health. -
Page 12: Cleaning And Disinfecting With "The Remedy
The Serenity™ System Operating Guide Sanitizing/Disinfecting Procedures for the Automatic Clean and Disinfect Option Including “The Remedy™” 1. Close the drain and door, set the selector knob to “Tub Cleaner” and turn on/off valve to on. NOTE 2. When cleaning solution has begun to flow out of whirlpool intake and Be sure to into the tub, turn on the whirlpool pump. - Page 13 Serenity™ Parts Manual APOLLO Corporation P.O. Box 219 Somerset, WI 54025 (715) 247-5625 / (800) 247-5490 Fax: (715) 247-3424 cservice@apollobath.com...
- Page 14 Table of Contents Tub Section: Page Outer Panels ..................1 Tub Shell Inner ..................2 Whirlpool ..................... 3 Controls and Drain ................4 Door ..................... 5 Air Section: Air System ................... 6 Single Solenoid ..................7 Double Solenoid................... 8 Electrical Section: Electrical Box Location ...............
- Page 15 Tub Section...
- Page 22 Air Section...
- Page 26 Electrical Section...
- Page 31 Control Panel Section...
- Page 35 Check circuit breaker and make sure it is not tripped. c. Check 24 volt box on front of tub to see if the power (pwr) LED5 is lit up. d. If all these items check to be ok, call Apollo customer service at 715-247-5625 for further assistance.
- Page 36 24 volt box. There should be only a maximum of ¾” between sensors on the tub and the sensor on the top bar frame. i. If all these items check to be ok, call Apollo customer service for further assistance. 4. WHIRLPOOL PUMP DOES NOT START WHEN BUTTON IS PUSHED.
- Page 37 Make sure LED6 and LED7 are lit up on the PC Board. d. Make sure there is power to the unit. Check GFI and all circuit breakers. e. If all these items check to be ok, call Apollo customer service for further assistance at 715-247-5625.
- Page 38 Drain the water out of the tub. Using the air bleeder valve, hold down the valve until all the air is bled from the system. Then the door can be pushed down by hand. Call Apollo customer service for further assistance at 715-247-5625.
- Page 39 The tub door and gasket are permitted to leak into the drip pan approximately 10 gallons per hour. However, the gasket is designed not to leak, and should be replaced if it is leaking excessively. Call Apollo customer service for further assistance at 715- 247-5625.
