QX Stand
Quick StArt Guide
AttAchAble
QX Stand
SKU# AC4076-1538 P/N 9010-01538

Advertisement

Table of Contents
loading

Related Manuals for Socket QX Stand

Summary of Contents for Socket QX Stand

  • Page 1 QX Stand Quick StArt Guide AttAchAble QX Stand SKU# AC4076-1538 P/N 9010-01538...

  • Page 2: Package Contents

    Thank you for choosing Socket Mobile! Let’s get started! © 2015 Socket Mobile, Inc. All rights reserved. Socket, the Socket logo, and Sock- etScan are registered trademarks or trademarks of Socket Mobile, Inc. The Blue- tooth word mark and logo are registered trademarks of the Bluetooth SIG, Inc.

  • Page 3: Assembly Overview

    ASSEMBLY OVERVIEW CONNECTING THE SCANNER HOLDER TO THE POST B. (Front view) B. (Bottom view) A. Holder Cushion Crown A. Flip the holder upside down and insert the cushion crown into the Base Pem Cap / Camera Mount* bottom of the holder. C.
  • Page 4 INSERTING THE USB CABLE THROUGH THE BASE UNIT CONNECTING THE USB CABLE TO THE HOLDER Base (Bottom View) Back Base (Top View) A. Remove Micro USB cover. Insert Micro USB connector into port and fit usb cable into the cord keeper. Front C.

  • Page 5: How To Unlock

    CONNECTING THE SCANNER HOLDER TO THE POST HOW TO UNLOCK To unlock, find the small latch on the bottom of the base. Pull the latch back and turn the post clockwise aligning the marker with the unlock icon. Base (Bottom View) Small latch Insert the post into the top of the base lining up the marker on the post to the unlock icon.
  • Page 6 QX STAND OPERATIONS QX STAND OPERATIONS When charging the scanner, make sure the charging pins on the stand and the scanner make con- tact with each other and the red LED on the stand is illuminated. “Beep 4-6 inches Beep”* (10 - 15 cm) *CHS 7Qi &...
  • Page 7 “Auto Mode” Drill Template. 1. Place the QX Stand on the Drill Template and situate these onto the desired location of your surface. Rotate the Stand so that it aligns with the solid Notch (not the dotted Notch) on the Template.

  • Page 8: Command Barcodes

    OPTIONAL CONFIGURATION WHEN USING A CAMERA MOUNT COMMAND BARCODES QX Stand Modes Mobile Mode - Normal (default)* Scanning this bar code will enable the scanner to enter mobile mode. It will always be in manual trigger mode even when placed in the stand or cradle.

  • Page 9: Auto Mode

    AUTO MODE AUTO MODE (CONTINUED) Auto Mode (in the Stand) 1. Pair and connect the 7Qi/7Xi to your device prior to placing the scan- ner in Auto Mode. The Scanner is not discoverable when in Auto Mode Notification and in the Stand. This facilitates a fast connection to the current Action Behavior Beep Pattern...

  • Page 10: Product Specifications

    Holder Width 1.80 in (46 mm) Warranty checker: http://warrantychecker.socketmobile.com/ Holder Length 5.50 in (140 mm) Socket Mobile developer Program: Base Diameter 5.75 in (146mm) Learn more at: http://developer.socketmobile.com total Weight Series 7 User’s Guide (full installation and usage instructions) and Com-...

  • Page 11: Compliance Statement

    COMPLIANCE STATEMENT CE MARKING AND EUROPEAN UNION COMPLIANCE The unit under test was found compliant with all the applicable Directives, 2004/108/EC and 2006/95/EC. WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT The WEEE directive places an obligation on all EU-based manufacturers and importers to take-back electronic products at the end of their useful life.
