DORC 1100 Instruction Manual

Micro diathermy system
Hide thumbs Also See for 1100:

Advertisement

Quick Links

MICRO
DIATHERMY
SYSTEM
Type 1100
INSTRUCTION
MANUAL
D.O.R.C. International b.v.
Scheijdelveweg 2
3214 VN Zuidland
The Netherlands
Phone
Fax
E-mail
: (+31) (0) 181 45 80 80
: (+31) (0) 181 45 80 90
:
mailto@dorc.nl
30300300C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DORC 1100

  • Page 1 MICRO DIATHERMY SYSTEM Type 1100 INSTRUCTION MANUAL D.O.R.C. International b.v. Scheijdelveweg 2 3214 VN Zuidland The Netherlands Phone : (+31) (0) 181 45 80 80 : (+31) (0) 181 45 80 90 E-mail mailto@dorc.nl 30300300C...
  • Page 2: Table Of Contents

    D.O.R.C. MICRO DIATHERMY SYSTEM Contents Section 1 Introduction ............1 Section 2 General Instructions .
  • Page 3: Section 1 Introduction

    D.O.R.C. MICRO DIATHERMY SYSTEM Section 1 Introduction The D.O.R.C. Micro Diathermy System is designed primarily for retinal detachment procedures (scleral diathermy and release of subretinal fluid). The instrument is also used for glaucoma procedures (cryclo diathermy and cauterization of lips of sclerotomy). The destruction of skin and intraocular tumors, hemostasis, epilation and trichiasis.
  • Page 4: Section 2 General Instructions

    D.O.R.C. MICRO DIATHERMY SYSTEM Section 2 General Instructions. Standard components of the Micro Diathermy System.. The standard components of the Micro Diathermy system are: - Ophthalmic diathermy 13.56 MHz complete with power cord and foot switch. - Diathermy with transillumination. - Under water diathermy for both vitreous and anterior chamber surgery.
  • Page 5: Operating Instructions

    D.O.R.C. MICRO DIATHERMY SYSTEM Operating instructions. Check if the electrical supply the unit needs is correct (at the back-side). Plug the unit into the AC source outlet. C.1. Assembling accessories : The electrodes (1102-1111) are inserted into the handle assembly (1101) after unscrewing the chuck cap approximately one-half turn counterclockwise.
  • Page 6: Theory Of Operation

    D.O.R.C. MICRO DIATHERMY SYSTEM Theory of operation Diathermy is used in operations for retinal detachment to produce a burn of the pigment epithelium. This burn is obtained by the applications of localized RF current on the sclera. A. Why High Frequency 13.56 MHz Power ? The following consideration resulted in the selection of the 13.56 MHz : Clinical tests have established that this frequency produces optimum burns of the pigment epithelium with the least possible damage to adjacent tissue such as the sclera and choroid.
  • Page 7 D.O.R.C. MICRO DIATHERMY SYSTEM C. Factors affecting a Diathermy burn : Several factors affect the nature of a burn obtained in scleral diathermy applications : 1. Voltage The intensity of the burn is proportional to the voltage level for any given frequency.
  • Page 8: Section 3 Cleaning Instructions

    D.O.R.C. MICRO DIATHERMY SYSTEM Section 3 Cleaning and Sterilizing Instructions for Accessories Reusable Accessories The device is provided non-sterile. The device must be sterilized prior to first use. It requires decontamination and re-sterilization between patient procedures. The device may be sterilized using either EtO or Steam.
  • Page 9 D.O.R.C. MICRO DIATHERMY SYSTEM Unwrapped items (“flash sterilization”): Temperature 270EF (132EC) Exposure time 4 minutes Here are some recommended guidelines for steam sterilization: • Never sterilize the accessories using dry air sterilization. • Handle the accessories gently. They are precision instruments. •...
  • Page 10 D.O.R.C. MICRO DIATHERMY SYSTEM Decontamination of Reusable Accessories All reusable components must be thoroughly cleaned before resterilization. Sterilization should then be performed using the instructions provided above. Caution !!! The effectiveness of sterilization methods other than those specified above is unknown and should be validated by the user.
  • Page 11: Section 4 Service Instructions

    D.O.R.C. MICRO DIATHERMY SYSTEM Section 4 Service Instructions Replacing the Fuses Turn off the power switch on the back of the unit. Unplug the power cord. The fuses are located on the rear of the unit, inside the black box at the point where the power cord is attached.
  • Page 12: Returning The Unit For Service

    D.O.R.C. MICRO DIATHERMY SYSTEM Returning the Unit for Service Before returning the unit to D.O.R.C. International b.v. for service, please contact the Service Department: Service Department D.O.R.C. International b.v. Scheijdelveweg 2 3214 ZG Zuidland The Netherlands Tel: 31-181-458080 Fax: 31-181-458090 Please try to protect the unit as much as possible during shipping.
  • Page 13: Section 5 Optional Instructions

    D.O.R.C. MICRO DIATHERMY SYSTEM Section 5 Optional Accessories 1101 Electrode handle with cable. (the on/off switch on the handle will only work in combination with a Mira diathermy unit), with the D.O.R.C. unit this handle can be operated by means of the foot switch. 1102 Electrode, buff, 2 mm.
  • Page 14 D.O.R.C. MICRO DIATHERMY SYSTEM 1122 As 1121, but with 45E curved tip. 1124 Endodiathermy probe with tapered tip. 1281-D Flute needle with the capability of retrograd flushing and endo diathermy. New instrument for aspiration of blood as well as coagulation of the bleeding spot and flushing back unwanted tissue.
  • Page 15: Section 6 Specifications

    D.O.R.C. MICRO DIATHERMY SYSTEM Section 6 SPECIFICATIONS GENERAL: Apparatus MICRO DIATHERMY SYSTEM Type Type 1100 Weight 5,5 Kg Dimensions 13 x 22,5 x 29 cm. MAINS INPUT: Mains supply 100-110 VAC (50/60 Hz) 230-240 VAC (50/60 Hz) Fuses 2x at 100/110VAC...
  • Page 16 D.O.R.C. MICRO DIATHERMY SYSTEM AMBIENT CONDITIONS: Operating temperature : 15-40EC Humidity 85% Max. The D.O.R.C. Diathermy system complies with the safety standards as described in the international norm IEC601-1, Type BF, Class 1 14/16 30300300C...
  • Page 17: Section 7 Warnings

    D.O.R.C. MICRO DIATHERMY SYSTEM Section 7 Warnings A warning indicates a potentially harmful situation to yourself or others. Electric shock hazard This unit contains high voltage circuits. After performing any repair, calibration procedure performs a final electrical safety check and leakage current test.
  • Page 18: Section 8 Warranty

    D.O.R.C. MICRO DIATHERMY SYSTEM Section 8 Warranty D.O.R.C. International b.v. warrants that all possible care was used in the choice of materials and manufacture of its products. D.O.R.C. International b.v. shall not be liable for any incidental or consequential loss, damage or expense, arising from abuse of its products.
