Product and Cut-out Dimensions
Sealed Gas Cooktop
KM3484G / KM3484LP
KM3485G / KM3485LP
Location Codes
E -
6 foot -110 Volt - 15 Amp (NEMA 5-15)
3-wire power supply connects rear
middle bottom.
G -
Gas connects rear right bottom.
MUST USE REGULATOR.
Notes
• Please specify Natural Gas or LP unit
when ordering.
• All installations must be done in
accordance with local codes.
G
E
1 1/2" min.
NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 010405
