Assembly Instructions
1-person assembly
24"
PH #2
Model #
Finish
MC0405
Brushed Walnut
Thank you for choosing Grain Wood Furniture, it is an honor to be in your home!
If you have any questions, feedback, or need replacement parts please contact us at:
grainwoodfurniture.com/help or
support@grainwoodfurniture.com
Mid Century
2-Drawer Nightstand
Made in Brazil
REV - 06/2021
page 1/11
Advertisement
Related Manuals for Grain Wood Furniture MC0405
Summary of Contents for Grain Wood Furniture MC0405
- Page 1 Model # Finish MC0405 Brushed Walnut Thank you for choosing Grain Wood Furniture, it is an honor to be in your home! If you have any questions, feedback, or need replacement parts please contact us at: grainwoodfurniture.com/help or support@grainwoodfurniture.com Mid Century...
- Page 2 PLEASE READ BELOW BEFORE BEGINNING ASSEMBLY Enlist help from a friend or family member as most items require two Ÿ people for proper assembly. Choose a spacious, open area near where the piece will be located once Ÿ assembled. It is easier to move parts than to relocate the furniture after it is fully assembled.
-
Page 3: Hardware List
HARDWARE LIST 4,0x30 10x10 4 + 1 3,5x14 2 + 1 M4x25 6 + 1 4,0x45 1/4’’x40 16 + 1 6,0x10 26 + 2 8,0x30 4 + 1 ATTENTION 5/16"x24x2 RIGHT Before starting assembly Side please verify the hardware 330mm - 13" set is complete. - Page 4 Qty. Description Part # Right side Left side Base Foot Fixed shelf Back panel Drawer front Drawer right side Drawer Left side Drawer bottom Drawer back Hardware page 4/11...
- Page 5 Tip : Use a hammer in case dowels are hard to install by hand. 8,0x30 RIGHT LEFT Side Side 2 E14 330mm - 13" 330mm - 13" 6,0x10 page 5/11...
- Page 6 G8+B25 G8+B25 G8+B25 G8+B25 1/4"x40 5/16"x24 Attention: There are no predrilled holes for the A1 screws on part 01. 4,0x30 page 6/11...
- Page 7 Attention: There are no predrilled holes for the A1 screws on parts 02 and 03. 4,0x30 Attention: There are no predrilled holes for the A40 screws on parts 02 and 03. 4,0x45 page 7/11...
- Page 8 Make sure back panels are perfectly aligned with side panels and top and there are NO gaps. û ü ü 10x10 û ü 10x10 page 8/11...
- Page 9 G1 G1 10x10 3,5x14 page 9/11...
- Page 10 Attention: There are no predrilled holes for the A1 screws on part 08. 4,0x30 Flip the assembled drawer upside down to install glides. 6,0x10 Drawer RIGHT 330mm - 13" Drawer LEFT 330mm - 13" page 10/11...
- Page 11 M4x25 page 11/11...
