OVER OSENSOR Manual page 2

MODEL
PRODUCT CODE
CERTIFICATIONS
SIZE
WEIGHT
POWER SUPPLY
BUS COMMUNICATION
CURRENT DRAW
PROGRAMMABLE ANALOG INPUT
PROGRAMMABLE ANALOG OUTPUT
OTHER INTERFACES
OPERATING TEMPERATURE
WAREHOUSING TEMPERATURE
TEMPERATURE (T)
HUMIDITY (H)
ATMOSPHERIC PRESSURE (P)
CARBON DIOXIDE (CO2)
TOTAL VOLATILE ORGANIC
COMPOUNDS (TVOC)
CARBON MONOXIDE (CO)
FORMALDEHYDE (CH2O)
PARTICULATE MATTER
(PM1, PM2,5, PM10)
2
DATA SHEET
OSENSOR
OSN
RoHS, CE
UAE RoHS, ECAS
95x35mm
140g
12÷15 Vdc
EDS
max 50mA
0-10Vdc o 4-20mA
0-10Vdc
2 programmable digital interfaces:
• Digital inputs,
• Digital outputs (open collector, maximum voltage
min -20°C
max +60°C
min -40°C
max +125°C
SENSORS
RANGE
-20 ÷ +65 °C 0.1°C
20 ÷ 80 % RH 1%
300 ÷ 1100 hPa 1 hPa
400 ÷ 5000 ppm 2 ppm
0 ÷ 5500 ppb 2 ppb
1 ÷ 500 ppm 1ppm
0 ÷ 5000 ppb 10 ppb
1 ÷ 999 μg/m³ 1 μg/m³
48Vdc, maximum current 250mA)
RESOLUTION
± 0,3 °C
± 3 % RH
± 1 hPa
±50 ppm + 3%
± 20%
± 10%
± 20%
1-100 μg/m³: ± 5μg/m³ + 15%
101-999 μg/m³: ±15%
Version 1.4 - Subject to change without notice
ACCURACY
