3 Operation

After installation of the Automatic Document Feeder is complete, power up the
computer and the scanner, then start up the scanner software.

Paper Loading

Before loading the Automatic Document
Feeder, check to see if the transparent
guide flap is firmly attached in place and
if the protective film is removed as
described in Chapter 2. If the film has
not been removed, scanned documents
will jam against the base of the feeder,
rather than being moved into the output
tray.
To load documents:
1. Pull the paper support up. This
2. Place the documents in the input tray
3. Make sure the pages are aligned in
prevents the paper sheets from
bending down.
with the side to be scanned facing
down. The document on the top will
be scanned in first.
the center with the two guide arms.
If the documents are less than 8 1/2"
wide, use the sliding guide arms to
hold the stack in place.
Automatic Document Feeder Installation and Operation Manual
Pulling the paper
support up
Guide Arm
Sliding the two
Guide Arms
