Collomix Service Instruction
CSI 026 – Door adjustment VIRO neo / TORO neo
1.
General Information
These Instructions are directed toward trained specialized staff. The basic safety information in
the operating manual has to be followed.
1.1
Instruction for installation
No special installation instructions.
1.2
Work schedule
The working time is approximately 20 minutes. The working time can vary depending on the condition and
equipment of the machine.
1.3
Material
Pcs.
Ref. No.
1.4
Tools
Pcs.
Size
1
PH2
1
7 mm
1
TX25
1
4mm
1.5
Preliminary Tasks
•
Provide sufficient working space in front of the machine..
Description
Description
Screwdriver
Combination spanner
Screwdriver Torx
Allen key
E: 2018-08-06 / michael schmidt |Ü: 2018-08-06 / 1 / michael schmidt |D: 2018-08-06 / michael schmidt
2018-08-06
Seite 1/3
CSI026_EN_Adjustment of the door.docx
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Collomix VIRO neo
Summary of Contents for Collomix VIRO neo
- Page 1 Collomix Service Instruction 2018-08-06 Seite 1/3 CSI 026 – Door adjustment VIRO neo / TORO neo General Information These Instructions are directed toward trained specialized staff. The basic safety information in the operating manual has to be followed. Instruction for installation No special installation instructions.
- Page 2 Collomix Service Instruction 2018-08-06 Seite 2/3 Work procedure Adjustment at the loading shelf On the loading shelf, the parallelism of the door to the loading shelf and the cover can at the top be adjusted. To do this, slightly loosen the four screws and slide the loading shelf to the left or right to find the best possible position of the door.
- Page 3 Collomix Service Instruction 2018-08-06 Seite 3/3 If necessary, the actuator can be carefully bent inwards with a screwdriver, approx. 1 mm is sufficient. DANGER Danger of death by dangerous voltage • Turn off on the main switch. Disconnect the system from the power supply.
